Quark-Elec AS09 Manual

Nmea 2000 rudder feedback sensor
Hide thumbs
1
Table Of Contents
2
3
4
5

Advertisement

Table of Contents

Quark-elec Manual
Features
 Engineered to withstand harsh marine environments, ensuring durability and longevity.
 Connect to the rudder via a mechanical linkage and continuously report actual rudder position,
facilitating easier yacht navigation.
 Directly connects to the NMEA 2000 network for straightforward and hassle-free installation.
 Compatible with most popular Autopilot systems.
 Offers 70° measurement range with a precision of ±0.5° , ensuring precise control and smooth
rudder operation.
 Enables smoother manoeuvres and helps avoid over-compensation.
https://www.quark-elec.com
V1.00
NMEA 2000 Rudder Feedback Sensor
1 of 5
AS09 Manual
2024

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AS09 and is the answer not in the manual?

Questions and answers

Related Manuals for Quark-Elec AS09

Summary of Contents for Quark-Elec AS09

  • Page 1 Quark-elec Manual AS09 Manual NMEA 2000 Rudder Feedback Sensor Features  Engineered to withstand harsh marine environments, ensuring durability and longevity.  Connect to the rudder via a mechanical linkage and continuously report actual rudder position, facilitating easier yacht navigation.

  • Page 2: Table Of Contents

    5-meter drop cable. This sensor converts the rudder's angular movement into a digital signal, which is then transmitted across the NMEA 2000 network. The data provided by the AS09 can be utilized by autopilot systems, https://www.quark-elec.com...

  • Page 3: Mounting

    (MFDs) to enhance navigation and control. Hosting a powerful 140° measurement range with a precision of ±0.5° the AS09 is an essential piece of equipment to aid in smoother sailing, precise movements and to prevent over-compensation when manoeuvring.

  • Page 4: Nmea 2000 Connection

    Figure 4: Pin NMEA 2000 male micro-fit connection After powering up, the AS09 will turn the physical rotation of the rudder arm into a digital signal which is read by the AS09 and transmitted along the NMEA 2000 network via PGN127245. This PGN can be used to display the rudder angle onto an MFD or chart plotter but to also integrate and function within an autopilot system.

  • Page 5: Limited Warranty And Notices

    Quark-elec warrants this product to be free from defects in materials and manufacture for one year from the date of purchase. Quark-elec will, at its sole discretion, repair or replace any components that fail in normal use. Such repairs or replacement will be made at no charge to the customer for parts and labour.
