- Page 1 Operating Instructions Infrared Paint Dryer ILT 1 ILT 1...
-
Page 2: Table Of Contents
12 Spare parts............14 Indications regarding the copyright 12.1 Spare parts order..........14 Copyright © 2017 Stürmer Maschinen GmbH, Hallstadt, 12.2 Spare parts drawing ILT 1 ......15 Germany. 13 Electrical wiring diagram ........15 14 EC Decleration of Conformity ......16 The contents of these operating instructions are the sole property of the company Stürmer. -
Page 3: Introduction
This combination of symbol and signal words indicates an imminently dangerous situation which may lead to death or severe injuries if they are not avoided. ILT 1 | Version 1.04... -
Page 4: Responsibility Of The Operator
Therefore, the following applies: - The operator must ensure that the maintenance in- tervals described in this manual are observed. - The operator must have all safety equipment regu- larly checked for functionality and completeness. ILT 1 | Version 1.04... -
Page 5: Personal Requirements
Certain work may only be carried out by specialist personnel of the manufacturer. Other personnel are not authorized to carry out this work. To carry out the work, contact our customer service. ILT 1 | Version 1.04... -
Page 6: Safety Information
3.2 Residual risks Even if all safety regulations are adhered to, the remai- The paint dryer ILT 1 is exclusively for use in the auto- ning risks described in the operation of the paint dryer re- motive and engineering industry. It is suitable for drying main. -
Page 7: Technical Data
Packing components made of cardboard are shredded for waste paper collection. Fig. 2: Type plate ILT 1 The foils are made of polyethylene (PE), the upholstery parts made of polystyrene (PS). You can hand over these substances to a recycling center or to the disposal company responsible for you. -
Page 8: Device Description
Description of device 6.3 Dimensions 6.1 Illustration Illustrations in this manual may differ from the original. Fig. 3: Infrared Paint Dryer ILT 1 1 Column 2 Control panel on the back of the radiant heater cassette 3 Clamping lever for pivoting the radiant heater cassette Fig. -
Page 9: Assembly
Screw the disk to the swivel head (Fig. 7, 2). tighten the column with the screws and was- d) Adjust the setting angle of the radiant heater hers on the chassis. cassette. Fig. 6: Mounting the radiant heater cassette ILT 1 | Version 1.04... -
Page 10: Electrical Connection
- To reduce smoke build-up during heating, it is ad- visable to clean the surfaces (eg surfaces that are soiled by lubricants or thinners). - Only work in well-ventilated areas. ILT 1 | Version 1.04... -
Page 11: Care, Maintenance And Repair
Step 8: Store the device in a safe place to prevent da- The following maintenance work can be performed by mage to the heating tubes. the operator of the device. - Check the supply cable. - Change the radiant heater cassette ILT 1 | Version 1.04... -
Page 12: Replace Radiant Heater
Step 4: Remove the clips on both sides of the radiant heater cassette Step 5: Loosen the screws and the cable connection. The radiant heater can then be replaced Step 6: Insert new radiant heater. Step 7: Reassemble device parts in reverse order. ILT 1 | Version 1.04... -
Page 13: Disruptions, Possible Causes And Measures
Step 2: If necessary, dismantle the devices into manage- able and usable components and components. Step 3: The device components and operating materials must be routed to the appropriate disposal rou- tes. ILT 1 | Version 1.04... -
Page 14: Spare Parts
Risk of injury through use wrong spare spare parts drawing. parts! Dangers may result for the user and damages as well - Type of device: Infrared Paint Dryer ILT 1 as malfunctions may be caused by using wrong or - item number: 6205001 damaged spare parts. -
Page 15: Spare Parts Drawing Ilt 1
Electric wiring diagram ILT 1 12.2 Spare parts drawing ILT 1 In case of service, the following statement will help to identify the necessary spare parts. If necessary, send a copy of the marked components to your authorized dealer. Name... -
Page 16: Ec Decleration Of Conformity
To ensure consistency, the following harmonized standards and national standards and provisions have been applied: EN 60204-1:2007-06 Safety of machinery - Electrical equipment of machinery - Part 1: General requirements (IEC 60204-1:2005) Responsible for documentation: Engineering department, Dr.-Robert-Pfleger-Str. 26, D-96103 Hallstadt Hallstadt, 29.01.2016 ______________________ Kilian Stürmer CEO, Director ILT 1 | Version 1.04... - Page 17 Notes 15 Notes ILT 1 | Version 1.04...
