USE AND MAINTENANCE MANUAL
SPRING TINE CULTIVATOR CR7
.
Power
Model
Weight
Tooth
Working
Working width
depth
HP
KW
KG LBS
N°
CM
INCH
CM
INCH
18-24
13-18
CR7
75
170
7
15
6
98
38,5
CR7-EN-R2021.01 Use and maintenance manual : CR7
Advertisement
Table of Contents
Summary of Contents for Del Morino CR7
- Page 1 I-52033 Caprese Michelangelo AR Italy Ph: +39-575-791059 Fax: +39-575-791210 E.mail: export@del-morino.it http://www.del-morino.it USE AND MAINTENANCE MANUAL SPRING TINE CULTIVATOR CR7 Power Model Weight Tooth Working Working width depth KG LBS N° INCH INCH 18-24 13-18 38,5 CR7-EN-R2021.01 Use and maintenance manual : CR7...
- Page 2 PREFACE This manual is an integral part of the machine. It must always accompany the machine and be kept within reach of the operator. The enclosures mentioned are on integral part of this manual. The purpose of this manual. This manual gives information for the correct and safe use of the machine. The owner must read this manual carefully before work with the machine.
-
Page 3: Function Of Use
DESCRIPTION FUNCTION OF USE The spring tine cultivator works on the ground without overturning it. It works at a certain depth and separates the surface crust from the deeper layer, so in this way it increases the capacity of moisture retention, aerates the ground and makes uprooting of grass. It is advantageously used in place of spring plowing especially for row crops . -
Page 4: Safety Information
SAFETY INFORMATION GENERAL REGULATIONS In this section you find the potential hazards and precautions to limit the potential risks. • Only work in daylight or with good artificial lighting • Never use the tool near other persons, specially children and animals. •... -
Page 5: Safety Signs On The Machine
SAFETY SIGNS ON THE MACHINE In this section, the safety signs on the machine are reproduced and explained. CAUTION 1. Read Use and maintenance manual. The safety signs on the machine must always be legible. In case of damage, the labels of the signs must be substituted. In the case of the substitution of machine parts that have safety signs, the signs must be replaced. - Page 6 PROCEDURES AND GENERAL INSTRUCTIONS Upon receipt of the machine. Checks before work. Attachment to the tractor. Reaching the working area. Setting work parameters. Commissioning. Start tractor with the lowered lifter. End of Work. At the end of work raise the lifter. Cleaning after work.
-
Page 7: Maintenance Information
MAINTENANCE INFORMATION ORDINARY MAINTENANCE This paragraph indicates the maintenance that does not require special technical skills and can be performed by each user. Check the tightening of the screws. Lubrication of the adjustment screws and mechanical joints. Teeth maintenance. Anti-rust protection at the end of the season. Apply an anti-rust product, that is easy to remove, on unpainted metal parts. -
Page 8: Information On Demolition
TRANSPORT Outside of working operations, the machine is carried by the tractor in the raised position. STORAGE Store the machine in a dry place. <WARNING>: Store the machine in a secluded place, protecting the cutting parts to prevent accidental collisions. INFORMATION ON DEMOLITION At the end of its working life, the machine must be sent to be demolished and that can only be done by an authorized authority, in accordance with the national laws in force... - Page 9 WORK AND MAINTENANCE SHEET Every user should register on this sheet the facts about the life of the machine (both work and maintenance), so as to attest its conditions. DATE WORKING MAINTENACE NOTE USER HOURS...
- Page 10 SPARE PARTS CR7...
- Page 11 SPARE PARTS LIST CR7 Pos. DESCRIPTION COD. Q.ty 1 ATTACHMENT CR001D 2 FRAME CR002D 3 TIE ROD CR003D 4 BUSH CR004D 5 HITCH PIN I° CAT. SRM220D 6 WHEEL BRACKET CR005D 7 LITTLE WHEEL 000002VD 8 CLAMP FOR WHEEL BRACKET CR006D 9 NUT M24 P.F.UNI 5588...
- Page 12 THAT IS EASY TO REMOVE ON UNPAINTED METAL PARTS PROCEDURES AND MAINTENANCE INSTRUCTIONS ............7 STORAGE ..........................8 AUXILIARY SERVICES ......................8 WARRANTY ..........................8 WORK AND MAINTENANCE SHEET ..................9 SPARE PARTS CR7 ....................... 10 SPARE PARTS LIST CR7 ....................... 11...
