Summary of Contents for Eteros TRIMINATOR SHREDMASTER
- Page 1 SHREDMASTER USER GUIDE V1.1 ©2024 Eteros Technologies inc. All rights reserved. | thetriminator.com...
-
Page 2: Table Of Contents
WARRANTY................................8 UNLOADING/UNPACKING..........................9 ELECTRICAL INSTALLATION..........................9 START-UP PROCEDURE........................... 10 CLEARING A JAM............................... 11 SHUT-DOWN PROCEDURE..........................11 MAINTENANCE & LUBRICATION........................12 CUTTER STACK ADJUSTMENT.........................14 TROUBLE-SHOOTING............................15 GREASE FITTINGS............................. 18 MACHINE ASSEMBLY............................18 CUTTER HEAD ASSEMBLY..........................19 CONTROL PANEL LAYOUT..........................20 Triminator ShredMaster User Guide... -
Page 3: Introduction
INTRODUCTION Congratulations on your selection of the Triminator ShredMaster! We want to help you to get the best results from your new trimmer and to operate it safely. This User Guide contains the information on how to do that; please read it carefully before you set up and use your trimmer. -
Page 4: Warning Labels
Damage Prevention Messages - You will also see other important messages that are preceded by the word NOTICE. This word means: NOTICE Your trimmer or other property can be damaged if you don’t follow instructions. Triminator ShredMaster User Guide... -
Page 5: Safety Warnings
● NEVER remove material from cutter heads while power is on. ● NEVER attempt to remove debris from input chute after material has begun to move toward cutter head. ● NEVER hold forward button in the depressed position. Triminator ShredMaster User Guide... -
Page 6: General Safety Precautions
DON’T FORCE THE EQUIPMENT It will operate optimally and safely at the rate for which it was designed. USE THE RIGHT TOOL Don’t force the device to do a job for which it was not designed. Triminator ShredMaster User Guide... - Page 7 Any damaged part including guards should be properly repaired or replaced. ALWAYS WEAR EYE PROTECTION Safety goggles can protect your eyes from fast-moving debris. ALWAYS WEAR EAR PROTECTION Wear ear muffs or earplugs when operating loud machinery. Triminator ShredMaster User Guide...
-
Page 8: Service And Repairs
SERVICE AND REPAIRS Repairs may only be carried out by Eteros Technologies or a designated authorized agent (service technician). Should the need arise, please notify us: Eteros Technologies 6175 South Sandhill Road, Unit 600, Las Vegas, NV 89120 www.eteros.com www.thetriminator.com service@thetriminator.com... -
Page 9: Warranty
WARRANTY Thank you for your purchase of the Triminator ShredMaster. The Triminator Triminator ShredMaster is covered by our manufacturer’s warranty as follows: ● Warranty coverage for one (1) year or 1,000 operating hours, whichever occurs first, on motors, electrical components, and the remainder of machine components. -
Page 10: Unloading/Unpacking
Record the nameplate information in the space below. 3. Install receptacle to properly protect building’s circuit. Select appropriate wire size and current protection to accommodate current requirements as shown on nameplate. Plug in power cable. Triminator ShredMaster User Guide... -
Page 11: Start-Up Procedure
The operator will soon be able to judge the efficiency of the operation and feed material accordingly. It is nearly inevitable that during this learning process the machine will jam. A jam condition will automatically change the rotation of the cutters to the reverse rotation for Triminator ShredMaster User Guide... -
Page 12: Clearing A Jam
SHUT-DOWN PROCEDURE 1. Allow conveyors to clear all material before shut down if applicable. 2. Depress E-Stop pushbutton. Remove power cable from receptacle. 3. Clean any remaining debris from the machine and from the immediate area. Triminator ShredMaster User Guide... -
Page 13: Maintenance & Lubrication
● Repeat steps from monthly lubrication. ● Drain oil from cycloidal reducer and refill with Shell Omala S2-GX synthetic industrial gear oil. Less than 1 gallon total will be needed (refer to Sumitomo manual in Appendix 1 for details). Triminator ShredMaster User Guide... - Page 14 200+Hrs gallon total (Refer to Appendix Chain Monthly Monthly Brush on Bearing Spur Gears Monthly Grease(Lithium) High-temperature #2 Lithium Weekly or every 20Hrs, Main Roller Bearings (4) based Grease 1-2 Pumps Per whichever is less Bearing Triminator ShredMaster User Guide...
-
Page 15: Cutter Stack Adjustment
Securely tighten any that are loose. 4. A circular plate with bolts are used to evenly tighten each stack. Tighten each bolt a small amount at a time to ensure that even pressure is being applied to the stack. Triminator ShredMaster User Guide... -
Page 16: Trouble-Shooting
Reconnect and tighten loose wires to proper location on 6. STOP button stuck “in”. strip. 7. Loose wire in panel. Check block for continuity. If bad, replace. 8. Defective contact block on STOP button. Triminator ShredMaster User Guide... - Page 17 MACHINE WILL NOT RUN IN Check and reconnect. FORWARD BUT WILL RUN IN Disconnected wire on current REVERSE relay. Clean relay. Free up center spool. Check continuity. If bad, Current relay stuck open. consult factory for replacement relay. Triminator ShredMaster User Guide...
- Page 18 Cutters are dull with rounded New Sharp Cutters are needed. edges. Check voltage at power supply. Low voltage. Consult factory before making SHREDDING CAPACITY IS LOW any adjustments. Current relay set too low. Tighten Stackpusher Bolts Cutter Stack is Loose Triminator ShredMaster User Guide...
-
Page 19: Grease Fittings
● Ball Bearing Grease Fitting Locations (4 Grease Fittings) ● Grease Every week – 1 to 2 Pumps of Grease (See Lube Schedule pg.7) ● Appendix 1 at the end of this manual for oil quantities and oil type. MACHINE ASSEMBLY Triminator ShredMaster User Guide... -
Page 20: Cutter Head Assembly
CUTTER HEAD ASSEMBLY Triminator ShredMaster User Guide... -
Page 21: Control Panel Layout
CONTROL PANEL LAYOUT Triminator ShredMaster User Guide...
