Greenbroz M1 Assembly Instructions Manual

Dry trimmer
Hide thumbs Also See for M1:

Advertisement

Quick Links

Download this manual
M1
DRY TRIMMER
Assembly Instructions
GREENBROZ.COM
INFO@GREENBROZ.COM
(844) DRY - TRIM

Advertisement

loading
Need help?

Need help?

Do you have a question about the M1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Greenbroz M1

Summary of Contents for Greenbroz M1

  • Page 1 DRY TRIMMER Assembly Instructions GREENBROZ.COM INFO@GREENBROZ.COM (844) DRY - TRIM...
  • Page 2 NOTE The M1 dry trimmer does not require any tools, it is held together by tension. During assembly of the dry trimmer, there will be steps that require the assembler to pull or push on a component to ensure a snug and tight fit.
  • Page 3 PANELS PARTS TOP DOWN VIEW RIGHT SIDE PANEL INSTALL TRIM CATCH MOUNT INSTALL LEFT SIDE PANEL INSTALL Slide the center and rear tab of the Slide the center and rear tab of the Slide front tab onto frame at arrow left side panel into slots labeled right side panel into slots labeled Flex together and pass though slots...

  • Page 4: Right Side View

    TRIM CATCH PARTS TRIM CATCH INSTALL Angle trim catch as shown. studs Ensure pass through holes as shown in diagram at points Press firmly at point labeled and compress the trim catch to fit into the top of the cart. NOTE: SIDE PANELS ARE NOT SHOWN TO INCREASE VISIBILITY.
  • Page 5 BUD CHUTE PARTS CHUTE COVER CHUTE RAMP BUD CHUTE ASSEMBLY Hook chute cover into chute ramp at location labeled A4. Flex chute cover at points labeled A5. Ensure tabs of chute ramp pass through chute cover as shown in diagram at point BUD CHUTE INSTALL Press firmly down on bud chute assembly to slide...
  • Page 6 MOTOR PARTS MOTOR MOUNT INSTALL Slide motor mount into side panels and trim catch at labels P4, and as rotated as shown in diagram D4. Rotate motor mount until flat on side panels as shown in diagram D5. Ensure side panel tabs pass through inside of motor mount as shown in diagram and arrow A7.
  • Page 7 BARREL PARTS BARREL INSTALL Lower barrel onto motor mount at indicated angle at label A8. Ensure barrel fits into motor mount as shown in and at points labeled P9. diagram...

  • Page 8: Door Frame

    DOOR FRAME PARTS DOOR FRAME INSTALL Lower door frame down as shown at arrow A8. Fit door frame into area between the barrel and ramp cover as shown at arrow in diagram Compress door frame on both sides as indicated at arrow A10. Slide door frame down into slots labeled until tabs at arrow pass though slots.
  • Page 9 DOOR AND BOTTOM BLADE PARTS NOTE: TOP OF BOTTOM BLADE INDICATED BY TEFLON RING AND “S” SHAPE OF BLADE. BOTTOM BLADE INSTALL Lower bottom blade into barrel as shown at A12. Ensure bottom blade tab point fits through bud chute at arrow A14.
  • Page 10 TOP BLADE AND HUB PARTS NOTE: TOP BLADE CORRECT ORIENTATION IS INDICATED BY BLADE PATTERN IN A “REVERESE TOP BLADE S”, OPPOSITE OF BOTTOM GBZ�53�015 BLADE. NOTE: INSTALL DOOR PRIOR TO TOP BLADE INTALLATION FOR EASIER INSTALL. TOP BLADE INSTALL HUB KEY Lower top blade into barrel at indicated angle A18.
  • Page 11 CENTER FIN PARTS CENTER FIN INSTALL Hook point of center fin into barrel at arrow in orientation shown at arrow A20. Rotate center fin down to latch point of center fin onto point of barrel as shown in diagram D14. PARTS CENTER FIN LOCKING KEY INSTALL Slide center fin key into position shown at arrow A22.
