Installa on Instruc on for Undermount Sink
Unpack and inspect your sink upon delivery to avoid costly contractor delays
• Materail: High quality T304 stainless steel
• Outer Dimensions: 23-1/4"(length) x 14"(width) x 9"(depth)
• Sound Insula on: Rubber dampening pads and an -condensa on coa ng
• R10 round corner for cleaning easily; X channel grooves for draining water quickly
• Accessories Included: Basket strainer, rinser and all moun ng hardware
It is highly recommended that this sink should be installed by professionals.
18"
10"
Product Features
This sink is intended only for undermount installa ons of
solid-surface composite or natural stone countertops.
Sink Dimensions (mm)
16"
R10
R10
30"
28"
3.5" Dia
Model: AS1514XSS/AS1514XGB
Advertisement
Related Manuals for AguaStella AS1514XSS
Summary of Contents for AguaStella AS1514XSS
- Page 1 Installa on Instruc on for Undermount Sink Model: AS1514XSS/AS1514XGB Unpack and inspect your sink upon delivery to avoid costly contractor delays Product Features • Materail: High quality T304 stainless steel • Outer Dimensions: 23-1/4"(length) x 14"(width) x 9"(depth) • Sound Insula on: Rubber dampening pads and an -condensa on coa ng •...
- Page 2 Installa on Cutout Size: 545 x 310mm Description Picture Kitchen Sink Undermount Clips Cutout Template Step 1: Countertop Cutout Step 3: Install the Nuts Cutout the perimeter of the template Step 4: Install the Kitchen Sink Step 2: Align the Nut Holes as Shown Below Hole Size : 10mm with depth 15mm Apply the silicon Official Site: www.aguastellausa.com...
