Zenith ZLI012100 User Manual

01/2024
User manual
Batterie Zenith Lithium
THESE INSTRUCTION CONCERN THE FOLLOWING MODELS: ZLI012100
IMPORTANT: the "General Warranty Conditions" in force and available on the website
www.unionbatteryservice.it are to be considered an integral part of this manual and binding.
INDEX
1. Introduction
2. Storage
3. Transport
4. Pre-installation
5. Installation
6. Use
7. Indicator instruction
8. Standard procedure for the management of the alarm status
9. Management of "the alarm status"
10. ON/OFF button mode
11. Low consumption mode
12. ZENITH LITHIUM DISPLAY
13. Maintenance
14. Repair
15. Disposal PROCED
1. INTRODUCTION
a.
The "ZENITH LITHIUM" series batteries are lithium
ion batteries identified with the ONU number
UN3480, class 9 (subsequently referred to as
"lithium batteries"). The legislation in object also
regulates the packaging methods, of product
identification as well as the directives for transport.
b.
They are complex devices and are mainly composed
of LiFeP04 type lithium ion cells (more commonly
referred to as LFP) and control electronics called
BMS (Battery Management System). The BMS
performs all and only the control functions to keep
the battery itself safe. When it detects anomalies,
it blocks the operation of the battery (during this
event no voltage value will be measured at the ends
of the battery output cables). In the following
paragraphs we will look at these aspects in more
detail.
c.
The batteries are equipped with an ON/OFF button
for turning the BMS on/o . In the OFF position, no
voltage value will be measured at the ends of the
battery output cables. The OFF position of the
button is not su cient to prevent any short circuits
(it could be accidentally pressed), it is therefore
always recommended to appropriately isolate the
terminals of the battery output cables.
d.
Before storing, transporting, installing and using
the battery, carefully read this manual, as well as
the general conditions of warranty and the
technical data sheet of the battery itself, available
on the website www.unionbatteryservice.it or
simply by framing the QR code printed on the upper
label. The data shown on the upper battery label
shows only the main technical information.
e.
For any doubts or questions, the technicians at
U.B.S. UNION BATTERY SERVICE are available to
provide adequate technical support.
01
02
02
02
03
03
04
05
05
05
06
06
06
06
06
01
