KEYLESS ENTRY SYSTEM
AUTKL800BT
REMOTE OPERATION
1
2
*
#
3 4
Remote Transmitters*
*If your remotes look different than above, you may have an older kit (pre-2023).
Download instructions at InstructionsNow.com
CH1 REMOTE DOOR LOCKING
a. Press button 1. The parking lights will
flash once. The starter/ignition kill
circuit will be enabled and the lock
output will pulse for 1 second.
b. LED will begin flashing slowly.
CH2 REMOTE DOOR UNLOCKING
a. Press button 2. The parking lights will
flash twice. The starter/ignition kill
circuit will be disabled and the unlock
output will pulse for 1 second.
b. LED will be off.
STOP
THESE REMOTES ARE NOT PROGRAMMED!
See page 2 for programming instructions
©2023 The Hoffman Group International Ltd Co. All rights reserved.
The above instructions are for reference only. THG is not responsible for any inaccuracies in the above instructions. THGI is also not responsible for any property damage or personal injuries resulting from the above
instructions. Installation by qualified automotive professionals is highly recommended.
WWW.AUTOLOC.COM
8 channel system
7
5
6
*
#
8
CH3 OUTPUT
Press button 3 to output channel 3
for 1 second.
CH4 OUTPUT
Press button 4 to output channel 4
for 1 second.
CH5 OUTPUT
Press button 1+3 to output channel 5
for 1 second.
AUTKL800BT 07/03/2023 Page 1 of 11
Button Function
Enable starter/ignition
1
kill and lock door
LOCK
Disable starter/ignition
2 kill and unlock door
UNLOCK
3 3rd channel output
4th channel output
4
1+3 5th channel output
2+4 6th channel output
1+2 7th channel output
3+4 8th channel output
CH6 OUTPUT
Press button 2+4 to output channel 6 for 1
second.
CH7 OUTPUT
Press button 1+2 to output channel 7 for 1
second.
CH8 OUTPUT
Press button 3+4 to output channel 8 for 1
second.
Condition
Starter/ignition
kill enabled
Starter/ignition
kill disabled
Anytime
Anytime
Anytime
Anytime
Anytime
Anytime
