Casio 5059A Operation Manual

MA0906-EB
About This Manual
• The operational procedures for Modules 5059 (A) and 5059 (B) are identical. All of
the illustrations in this manual show Module 5059 (A).
• Button operations are indicated using the letters shown in the illustration.
• For the sake of simplicity, the sample displays in this manual do not show the analog
hands of the watch.
• Each section of this manual provides you with the information you need to perform
operations in each mode. Further details and technical information can be found in
the "Reference" section.
• Depending on the model of your watch, display text appears either as dark figures
on a light background or light figures on a dark background.
All sample displays in this manual are shown using dark figures on a light
background.
For indicators, "On" is indicated by a dark indicator on the positive (dark-on-light)
display, and by a light indicator on the negative (light-on-dark) display.
Module 5059 (A)
General Guide
• Press C to change from mode to mode.
• In any mode (except when a setting screen is on the display), press B to illuminate
the display.
Timekeeping Mode
Timekeeping
This watch features separate digital and analog timekeeping. The procedures for
setting the digital time and analog time are different.
• In the Timekeeping Mode, you can press D to change the display format as shown
below.
Seconds Day of the Week
Press
Seconds
Digital Time and Date
Use the Timekeeping Mode to set and view a digital display of the current time and date.
When setting the digital time, you can also configure settings for summer time
(Daylight Saving Time or DST), your Home City code (the code for the city where you
normally use the watch), the 12/24-hour format, and the illumination duration.
• This watch is preset with a number of city codes, each of which represents the time
zone where that city is located. When setting the digital time, it is important that you
select the correct city code for your Home City. If your location is not included in the
preset city codes, select the preset city code that is in the same time zone as your
location.
• Note that all of the times for the World Time Mode city codes are displayed in
accordance with the digital time and date settings you configure in the Timekeeping
Mode.
• After you correctly set your Home City time and date, you can set the watch up for
timekeeping with a different city code simply by changing the Home City code in the
Timekeeping Mode.
To set the digital time and date
Seconds
3. Press C to move the flashing in the sequence shown below to select the other settings.
Seconds DST
Illumination Duration
Operation Guide 5059 (A)(B)
Module 5059 (B)
World Time Mode Countdown Timer Mode
Press .
Month – Day
.
Day of week Month – Day
1. In the Timekeeping Mode, hold down A until the
seconds start to flash, which indicates the setting
screen.
2. Press C twice to move the flashing to the Home City
code setting (see the illustration below), and then use
B and D to select the code you want.
• Make sure you select your Home City code before
changing any other setting.
• For full information on city codes, see the "City Code
Table".
Home City Code Hour
Day Month Year 12/24-Hour Format
Stopwatch Mode
4. When the setting you want to change is flashing, use B and D to change it as
described below.
Screen To do this:
Reset the seconds to
Toggle between Daylight Saving Time (
and Standard Time (
Hour : Minutes
Change the Home City code
PM indicator Change the hour or minutes
Toggle between 12-hour (
(
Change the year
Change the month or day
Select one second ( ) or three seconds ( )
as the illumination duration
Hour : Minutes
5. Press A to exit the setting screen.
• Resetting the seconds only (without changing the DST, Home City code, hour, or
minute setting) causes the analog minute hand setting to be adjusted automatically.
• See "Digital Time Daylight Saving Time (DST) Setting" below for details about the
DST setting.
• The 12-hour/24-hour timekeeping format you select in the Timekeeping Mode is
applied in all modes.
• For details about illumination duration, see "Illumination".
Digital Time Daylight Saving Time (DST) Setting
Daylight Saving Time (summer time) advances the digital time setting by one hour
from Standard Time. Remember that not all countries or even local areas use Daylight
Saving Time.
To toggle the Timekeeping Mode digital time between DST and Standard Time
DST indicator
Minutes
Alarm Mode
00
ON )
OFF )
12H ) and 24-hour
24H ) timekeeping
1. In the Timekeeping Mode, hold down A until the seconds
start to flash, which indicates the setting screen.
2. Press C once to display the DST setting screen.
3. Press D to toggle between Daylight Saving Time (
displayed) and Standard Time (
4. Press A to exit the setting screen.
• The DST indicator appears on the Timekeeping, Alarm,
and Hand Setting Mode to indicate that Daylight Saving
Time is turned on.
Hand Setting Mode
Do this:
Press D.
Press D.
Use D (east) and B (west).
Use D (+) and B (–).
Press D.
Use D (+) and B (–).
Press D.
ON
OFF displayed).
