RF302E
RF302PLUS
Thank you for choosing our products.Please read the instructions carefully before installation and
keep it available for future maintenance or reference.
Our company reserves the right of final interpretation for this manual.
The manual is subject to change without notice.
Customer Service：info@runfinegroups.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Runfine RF302E
- Page 1 RF302E RF302PLUS Thank you for choosing our products.Please read the instructions carefully before installation and keep it available for future maintenance or reference. Our company reserves the right of final interpretation for this manual. The manual is subject to change without notice.
-
Page 2: Table Of Contents
Content Important Safeguards Technical specification List of materials Technical drawings Parts identification Installation of ceramic toilet Previous preparation Auto lid open/close Daily maintenance 1.Main unit care and maintenace 2.Spray nozzle maintenance and care Emergency troubleshooting 1.Electricity and water supply cut-off 2.Failure of remote control 3.When the product is left unused for long time Function keys description... -
Page 3: Important Safeguards
IMPORTANT SAFEGUARDS When using electrical products, especially when children are present, basic safety precautions should always be followed, including the following: 1.The appliance is not to be used by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction. - Page 4 IMPORTANT SAFETY INSTRUCTIONS CAUTION – Indicates that failure to follow the instruction may cause body injury or property damage. 1. Do not install or use the product in wet places as steam room etc. 2. It is recommended to use water-proof electrical outlet which should be lnstalled in the place where is not easily got wet.
-
Page 5: Technical Specification
Technical Specification Rating pressure 110V-120V,50/60Hz Rating power 1200W-1400W Main Unit Water pressure Minimum water pressure 0.07MPa (20L/min. flow). range Maximum water pressure 0.8MPa (Hydrostatic pressure) Electrical wire length is about 1.8m Flush volume 1.6/1.1Gpf(6.0/4.1Lpf) Flushing mode Siphonic jet Toilet Hole distance 305mm Outlet outside ≤100mm... - Page 6 Surface 6 different level adjustment temperature Heating power Open and close Quiet soft-closing device,Auto open and close(Only for device model RF302PLUS) Heated seat Heated burning The seat temperature will automatically lower to level protection 1 in 10 minutes after using Seat sensor, Temperature sensor, Bimetallic thermostat, Safety device Temperature fuse...
-
Page 7: List Of Materials
ENERGY NOZZLE SAVER CLEANING SAVER CLEANING FLUSH FLUSH RF302E RF302PLUS Main Unit Remote controller components RF302E RF302PLUS Thank you for choosing our products.Please read the instructions carefully before installation and keep it available for future maintenance or reference. Our company reserves the right of final interpretation for this manual. -
Page 8: Technical Drawings
Technical drawing The product shape chart is for reference only, and we reserve the right to modify the appearance of the product. -
Page 9: Parts Identification
Parts identification Bumper Left side Power indicator Energy saving indicator Human body sensing window Remote sensing window Human body sensing window Rear cleaning button Seat Drying button Power button Ceramic toilet Flush button Front cleaning button Water discharging Nozzle baffle Drying baffle Half flush button Rear... -
Page 10: Installation Of Ceramic Toilet
Installation of ceramic toilet 1.Water supply angle valve installation 3.Mounting bracket installation Assemble the mounting bracket with bolts and Draw drain outlet centerline on the floor, then install them to the pre-installed flange Install angle valve at proper position on plate on the ground and lock tight with nuts. - Page 11 5.Installation of hose Fixing sleeve Screw Connect water inlet and angle valve by new Decorative cap hose. Put the screw through the fixing sleeve and then install it through the holes(on both sides of the toilet ceramic) to the mounting bracket on the ground, and lock tight with a tool;...
-
Page 12: Previous Preparation
Previous preparateion 1. Turn on the angle valve Check thread connection,make sure no leakage is found. Angle valve 2.Switch the power supply Insert electric leakage protection plug into power socket. Indicator light Electric leakage test button Protection switch 3.Self-inspection... -
Page 13: Auto Lid Open/Close
Auto lid open/close If you purchase the intelligent toilet with auto lid open/close function, the product can achieve the function of auto lid open/close. The factory default of this function is on closed situation, so please start the auto lid open/close function by using remote controler. -
Page 14: Daily Maintenance
Daily maintenance Spray nozzle maintenance and care Main unit care and maintenace 1.Shut off power supply at maintenance. 1.Nozzle self-cleaning Press “nozzle cleaning” button and nozzle will move forward and self-clean. 2.Spray nozzle disassemble 2.Turn the seat upward open, When the wand moves forward,the nozzle press down the button located can be disassembled to clean. -
Page 15: Emergency Troubleshooting
Emergency Troubleshooting 1. Power failure Manually press button of full/half flush to perform the toilet flushing. Operation panel 2.Water failure Put around 8L water into a barrel and flush the bowl of ceramic. Note:Avoid water spilling from bowl. Barrel Newspaper... -
Page 16: Failure Of Remote Control
Emergency Troubleshooting When the product is left unused for Failure of remote control long time 1.Operate the panels on ebidet seat to perform. Especially in winter season,the water inside the tank should be discharged to avoid freezing. To discharge water 1.Turn off the water supply angle valve 2.Cut off the electricity 3.Discharge water... -
Page 17: Function Keys Description
The illustration of main unit keys 1. Long press "power" button to enter standby mode; and then quick press "power" button to restore functional mode. Power 2. When people sit, press "power" button to stop the function of rear, front cleaning or drying. When no one sits, press "power" button to switch between function mode and power save mode. -
Page 18: Troubleshooting Guide
Troubleshooting Guide Problem Cause Solution Water supply hose buckling Solve the buckling causes block No flushing Turn on the fill valve Fill valve is off Connect water supply and Water supply is cut off wait for the water Water supply hose buckling Solve the buckling causes partial block Fill valve is not fully... - Page 20 ASVFAD051400000A-1.0...
