solarcentre SHAWFORD SC2218 User Manual

SHAWFORD
SOLAR SECURITY FLOOD LIGHT
W E
S
Ensure your solar
panel is South facing
or as near as possible
Thank you for choosing the Shawford Solar Security Flood Light. Please read these instructions
Important notes
Always take care when installing your light. If you are at all unsure, please contact your retailer or a professional trades person for
advice.
Installation
Remove all packaging and put to one side. Please carefully consider where you wish to install your light before making alterations
to your property. It's particularly important that the solar panel receives as much sunlight as possible. Ensure that it is not
obstructed by buildings, fences, trees, sheds, etc, or the shadows that these create. If the solar panel is installed in a poor
location, it may not perform to the best of its ability.
To maximise the battery capacity, the lights should be charged in direct sunlight for at least 12
hours, where possible, before being used for the �rst time. Failure to do so can shorten the
battery life or performance of the light.
The lights will turn ON/OFF automatically when left in the on position. Please note it is completely
normal for the lights to come on at di�erent times as it depends on how fast they charge in their
location.
Box contents:
Clean your solar
panel from time
to time
carefully before using your light.
How to install:
1. Install the expansion screw
columns into the wall
stick the rubber pad to
the bracket
3. Adjust the angle of the
lamp and bracket, then �x the
bracket with screws
USER GUIDE
Do NOT place your
solar panel in shaded
areas.
2. Install the bracket
4. Adjust the angle of the
light board and �x the screws
on both sides
Do NOT charge
behind glass
