Summary of Contents for KAMLAM QY-FSD034
- Page 1 CEILING FAN LIGHT OWNER’ S MANUAL PLEASE READ THIS OWNER’ S MANUAL THOROUGHLY BEFORE OPERATING AND KEEP IT HANDY FOR REFERENCE AT ALL TIMES.
-
Page 2: Table Of Contents
CONTENT INTRODUCTION ……………… …… …………………………… ………………1 INSTALLATION ………………… …………………………………………………2 REMOTE CONTROLLER SETTING ………………… ………………………4 CELLPHONE APP SETTING ………………… …………………………………5 CLEANING AND MAINTENANCE ………………… ………………………6 TECHNICAL SPECIFICATIONS ………………… ……………………………7 PRODUCT FEATURES … ………………… ………………………………………7 SAFETY PRECAUSTIONS ………………… ……………………………………8 TROUBLESHOOTING ………………… …………………………………………9 TECHNICAL SUPPORT ………………... -
Page 3: Introduction
INTRODUCTION THIS KAMLAM EILING FAN LIGHT IS MANUFACTURED WITH GREAT CARE, AND UTILIZES THE LATEST IN TECHNOLOGY. WE ARE CONFIDENT THAT YOU WILL BE FULLY SATISFIED WITH IT'S PERFORMANCE AND RELIABILITY. IT PROVIDES EXACT INSTRUCTIONS FOR INSTALLATION, OPERATION AND MAINTENANCE, AND ALSO SUPPLIES SOME USEFUL HINTS. -
Page 4: Installation
INSTALLATION 1. Open the package, take out the fan lamp, press down the base, and rotate to remove the base; 2. Take off the safety steel rope. 3. Base installation Fix the lamp base on the ceiling mounting base with screws, and confirm that the base is firmly installed. - Page 5 4. Buckle up the safety steel rope 5. Wiring Use wiring caps to connect the L/N/Ground wires. (Make sure the power is OFF before wiring) Hold the edges of both sides of the lamp body with both hands, align with the base, gently push both sides upward and rotate clockwise at the same time.
-
Page 6: Cleaning And Maintenance
CLEANING AND MAINTENANCE 1. Remove the safety screw on the side of the lamp body, hold the fan lamp with both hands, push it upward and rotate it counterclockwise to remove the fan lamp body. 2. Remove the wiring caps, disconnect the wires, and remove the safety steel rope. - Page 7 WIFI OPERATION INSTRUCTION 1.1. Download and install App Use your phone to scan the QR code below or search "Smart Life" in application market to download and install the App. For the first use, you need to use your mobile phone number or Email address to register and log 1.2.
- Page 8 4 After the App scans the device, click Add to bind the device;...
- Page 9 REMOTE CONTROL INSTRUCTIONS 2.1. Pair code Connect the device to the power supply and confirm that the device can work normally (the light turns on slowly); Turn off the power of the device for 5~10 seconds and then turn on the power again; Long press Button 1 until the device flashes 3 times quickly, then let go;...
- Page 10 Button 1: All off, short press to turn off the main light & color light & fan; Button 2: Fan mode, short press to switch between natural and comfortable wind; Button 3: Fan direction, short press to switch between forward and reverse; Button 4: fan rocker switch, only some models support this function;...
-
Page 11: Technical Specifications
TECHNICAL SPECIFICATIONS Product: Modern ceiling fan light Model: QY-FSD035 Input: 100-240V,50/60HZ Fan wattage: 15W Light wattage: 24(2900k)-48W(6500K) (9 6 x 1W/LED module) Total Wattage:60W Light color Rage: 2900K-6500K Supportive system: Android 4.4 or iOS 9.0 and newer versions. Wireless connection: Wi-Fi IEEE 802.11b/g/n 2.4GHz, Alexa Voice, Google Assitant PRODUCT FEATURES COLOR ADJUSTMENT... -
Page 12: Safety Precaustions
SAFETY PRECAUSTIONS 1. Please confirm whether the voltage meets the working voltage of the product before use. Using inappropriate voltage may damage the product and cause potential safety hazards; 2. The light source of this lamp is a non user replacement light source, and the light source in this lamp shall be replaced by the manufacturer or its service agent or a person with similar qualification;... -
Page 13: Troubleshooting
TROUBLESHOOTING IF YOU FEEL YOUR CEILING FAN LIGHT IS NOT OPERATING PROPERLY, CHECK THESE POSSIBLE CAUSES: PROBLEM POSSIBLE CAUSES CEILING FAN DOES NOT Has a house fuse blown or circuit breaker OPERATE tripped? Check whether the power switch out of order. LIGHT IS ON, BUT THE The remote’... - Page 14 We want to hear your voice! Feel free to touch base if you encounter any issue whenusing our product(s) or want to know more about our brandWe will be more than happy to provide top-notch pre-sales & after-sales service 24/7 Email:support@Kamlam.com...
