- Page 1 HARDWARE MANUAL PMA2 Ultra Performance 2021-31-08 | TR-PMA2-6801S...
-
Page 3: Regional Contacts
You will find the full list of addresses and phone numbers on the following webpage: https://evs.com/contact/offices. User Manuals on EVS Website The latest version of the user manual, if any, and other user manuals on EVS products can be found at the EVS download center, on the following webpage: https://download-area.evs.com. TR-PMA2-6801S | 2021-31-08 |... -
Page 5: Base Configuration
HARDWARE MANUAL Introduction This technical document provides an overview of the different hardware configurations and a brief description of the connectors. Commercial References Base Configuration • PMA2-6801S: PMA Application Processing Module 2U 'Ultra Performance' Front View without option Rear View without option Storage Options •... -
Page 6: Hardware Options
ESSFP-I-10G-SR: Intel 10 Gb Ethernet SFP+ module 10GBASE-SR (Short Reach) ◦ ESSFP-I-10G-LR: Intel 10 Gb Ethernet SFP+ module 10GBASE-LR (Long Reach) SFP+ modules from other manufacturers may be used, but EVS cannot guarantee full functionality. | PMA2 Ultra Performance 2U... -
Page 7: Power Supply & Consumption
(c) One module can be changed when the server is running, as long as the other module is still powered. In case of failure, please order a new PSU directly from EVS. If you order one housing, it will also include two modules. -
Page 8: Chassis Dimensions
Chassis Dimensions 481 18.94 b 465.20 18.31 88.20 3.47 44.45 1.75 21.48 0.85 f 427.40 16.83 g 666.00 26.22 h 607.00 23.90 54.00 2.13 j 447.00 17.60 | PMA2 Ultra Performance 2U... -
Page 9: Sound Power Level
HARDWARE MANUAL Weight 19.18 kg / 42.28 lb Sound Power Level • Idle: 63.2 dB • Load at 100%: 71.3 dB Hardware & Operating System Motherboard: Single CPU CPU: 1x 32-core CPU at 2.5 Ghz with HyperThreading RAM: 8x 8GB DDR4 ECC 3200 Storage: •... - Page 10 ) - Intel 2x Gigabit Ethernet ports (RJ45) (JFC ) - onboard card (used by default and for teaming) (not used for Teaming) 2x 10Gigabit Ethernet (SFP+) ports 3x mini Display ports (*) JFC: Jumbo Frame capable | PMA2 Ultra Performance 2U...
-
Page 11: Rack Mounting Instructions
HARDWARE MANUAL Rack Mounting Instructions The following or similar rack-mount instructions are included with the installation instructions: Elevated Operating Ambient If installed in a closed or multi-unit rack assembly, the operating ambient temperature of the rack environment may be greater than room ambient. Therefore, consideration should be given to installing the equipment in an environment compatible with the maximum ambient temperature specified on the apparatus.
