GAOTek -LRD-164 User Manual

Heavy lift uav long range delivery drone
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Table of Contents
1.
Introduction ......................................................................................................................................................3
2.
The composition of the remote-control model and its representative meaning ...............................................4
Based in New York City & Toronto, GAO Tek Inc. is ranked as one of the top 10 global B2B technology suppliers. GAO ships overnight
within the U.S. & Canada & provides top-notch support thanks to its 4 decades of experience.
Product Name
Product SKU
Product URL
Contact us:
GAOTek Heavy Lift UAV long Range
Delivery Drone
GAOTek-LRD-164
https://gaotek.com/product/gaotek-heavy-
lift-uav-long-range-delivery-drone/
sales@gaotek.com
P a g e | 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GAOTek-LRD-164 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GAOTek GAOTek-LRD-164

Summary of Contents for GAOTek GAOTek-LRD-164

  • Page 1 P a g e | 1 GAOTek Heavy Lift UAV long Range Delivery Drone Product Name Product SKU GAOTek-LRD-164 https://gaotek.com/product/gaotek-heavy- Product URL lift-uav-long-range-delivery-drone/ Contact us: sales@gaotek.com Table of Contents Introduction ..............................3 The composition of the remote-control model and its representative meaning ..........4 Based in New York City &...

  • Page 2: Table Of Contents

    21. Cleaning and maintenance requirements .......................28 22. Pesticide use regulations ..........................28 GAOTek Agricultural Drone User Manual Based in New York City & Toronto, GAO Tek Inc. is ranked as one of the top 10 global B2B technology suppliers. GAO ships overnight...
  • Page 3 To the fullest extent permitted by law, you (and not GAOTEK) bear all costs for all necessary services, repairs, and corrections. GAOTEK shall not be liable for any loss caused by the user's failure to use the Product in accordance with this document and the Product User Manual. GAOTEK shall...
  • Page 4 P a g e | 4 2. The composition of the remote-control model and its representative meaning H12 remote control Note: Failure to follow the instructions may result in property damage and injury. Failure to follow the instructions may result in property damage, major accidents, and serious injuries. Take off and landing steps.
  • Page 5 P a g e | 5 Safe landing steps: Agricultural drone needs to land away from people. Packing to prevent damage to agricultural drones during transportation. Place the drone in a dry and ventilated place (place high to prevent children from touching). Meaning of each key Meaning Meaning...
  • Page 6 P a g e | 6 Meaning of each key Meaning Meaning 2.4G 3dB bantenna USB2/charge/data transmission Return flight Key D Height-location-automatic Key C Left stickX1、Y1 Seeding switch Reserved switch (no function yet) Key B Right stick X2、Y2 Two-axis camera control Power switch AB modes USB1/Image output...
  • Page 7 P a g e | 7 Meaning of each key Meaning Meaning 2.4G 3dB bantenna On-off key USB/Image output AB modes Right stick X2、Y2 Height-location-automatic Two-axis camera control Thumb wheel D Left stick X1、Y1 Return flight Power indicator light USB2/charge/data transmission Water pump Note: Open the antenna of the remote control T10 at a 45-degree angle during flight Based in New York City &...

  • Page 8: Download Software And Real-Name Authentication Steps

    P a g e | 8 3. Download software and real-name authentication steps Take out the Android phone -- find the software Housekeeper -- scan the QR code of the APP -- download and install the "Dr Assistant" APP Open the "Dr assistant" APP -- select "Register" -- enter the mobile phone number, verification code, enter the password to be set -- click confirm -- re-enter the mobile phone number, login password -- click confirm -- select the bottom right "My"...
  • Page 9 P a g e | 9 1). After the battery is off the machine, it cannot be charged immediately. The surface temperature of the battery should drop to 45°C or normal temperature before charging. 2). The battery cannot be charged if it is swollen (expansion rate > 8%), deformed, damaged in appearance, or the minimum voltage of a cell is less than 2.75V.

  • Page 10: Introduction Of Various Spare Parts Of The Drone And Explanation Of Error-Prone Points

    P a g e | 10 10). When lifting the battery, the battery handle should be lifted. Do not lift the power cord. 11). It is forbidden to stack, randomly place or pile up batteries, keep away from power sources and other flammable objects.

  • Page 11: Training On Remote Control Calibration, Accelerometer Calibration,Magnetic Compass Calibration, Gps Calibration Operation

    P a g e | 11 5.3 Whether the motor rotation is normal, whether there is any noise. 5.4 The sleeve of the folding part should be tightened. 5.5 The silicone sleeve of the air inlet hole of the pesticide box cover needs to be opened. 5.6 How to discharge the air from the nozzle;...
  • Page 12 P a g e | 12 1).Turn on the remote controller—power on the drone, and put it in a horizontal position to stay still. 2).Click to enter the "Dr Assistant " APP, click "Execute Operation", click the three dots in the upper right corner, click the drone icon, - click the sensor, click "Magnetic Compass Calibration", click "Start Calibration".

  • Page 13: Training On Drone Motor Startup And Shutdown Operation

    P a g e | 13 Conditions that require recalibration 1).The compass data is abnormal, and the drone status indicator light flashes red and yellow alternately. 2).The flight site is far from the site where the compass was last calibrated. 3).The mechanical structure of the drone has changed.

  • Page 14: Detailed Operation Of Drone Plot Planning

    P a g e | 14 8. Detailed operation of drone plot planning Open the phone's "Dr Assistant" APP—click on the planning plot—click on adding a plot—click on (GPS) management— input the name of the plot— click on "Finish" — click on "OK" — pull the remote control to attitude (manual) Mode—place all joysticks in the middle—after confirming that the surrounding environment is safe —...

  • Page 15: Obstacle Avoidance Radar On And Off

    P a g e | 15 tuning is adjusted for the entire operation area— the operation area can be adjusted by moving up, down, left, and right— After the route data parameters are adjusted—Confirm the settings— Click on the execution job in the lower right corner— Jump out a bullet box—Set flight parameters Spray mode—Select linkage spray in the spray mode—Water pump opening—Flight speed can be adjusted from 1m/s to 10m/s—Terrain following button is turned on—...

  • Page 16: Explanation And Training Of Maximum Flight Speed, Return Altitude, Course Speed, Work Completion Behavior, U-Turn, And Nose Orientation While Return

    P a g e | 16 12. 12. Explanation and training of maximum flight speed, return altitude, course speed, work completion behavior, U-turn, and nose orientation while return 12.1. Turn on the remote control—power on the drone, put it in a horizontal position and keep still— open the "Dr Assistant"...

  • Page 17: Explanation And Training Of Voltage Setting Of Battery Primary Alarm And Secondary Alarm

    P a g e | 17 Turn on the remote control (short press for 1 second, then long press the power switch for 3 seconds to turn on the remote control)—power on the drone, put it in a horizontal position and stay still—click to enter the "Dr Assistant"...

  • Page 18: How To Manually Take Over Operation After Out-Of-Control Protection, Pesticide Off Protection, And Work Completion Execution

    P a g e | 18 For 14S batteries, the first-level alarm voltage is recommended to be set to 51.8V, and the second-level alarm voltage is recommended to be set to 50.4V. Note: There is a risk of crash when flying below the level 2 alarm voltage. How to manually take over operation after out-of-control protection, pesticide off protection, and work completion execution When the drone is performing automatic flight operations, if there are behaviors such as out-of-control return,...

  • Page 19: Safe Operation Precautions

    P a g e | 19 16.13. It is strictly prohibited to choose far away obstacles as obstacle avoidance objects when testing obstacle avoidance function. Choose closer obstacle avoidance objects, which should not exceed 50 meters, and the line of sight is controllable. When testing the obstacle avoidance function, if the drone is 6 meters away from the obstacle and does not avoid the obstacle, it should be pulled high in time to prevent a crash or the propeller hitting the obstacle.
  • Page 20 P a g e | 20 1). Obstacle survey in the work area: During field planning, carefully observe the internal and edge obstacles, measure the obstacles, and avoid collisions between agricultural drones and obstacles. 2). Surrounding planting conditions: Before operation, observe the planting conditions of surrounding crops to see if there are sensitive plants, to avoid floating operation accidents, and to work only after confirming safety, so as to avoid economic losses.
  • Page 21 P a g e | 21 7). It is forbidden for the operator not to stand behind the drone to take off, so as to avoid the operation error of the operator, and the agricultural drone will fly in the wrong direction, causing the agricultural drone to collide with the ground crew.
  • Page 22 P a g e | 22 5). Operators should wear long clothes, long trousers and stockings, and carry floral water and mosquito repellent water to avoid exposing the skin and causing mosquito bites. 6). It is mandatory to carry a flashlight or headlamp for walking at night. 7).

  • Page 23: List Of Dangers And Hazards And Solutions

    P a g e | 23 3). When working in a high-temperature environment, you should pay attention to keeping drinking water. Keep a small amount of water for multiple times, preferably 200ml each time,at the same time, try to choose light salt water, in order to subsidize electrolytes, avoid the body lack of electrolytes and heat exhaustion.
  • Page 24 P a g e | 24 drone crashed in a collision. Please return as soon as possible when Fly when the the remote control sends a low power Please return as soon as possible when the battery is low warning, otherwise the drone cannot remote control sends a low power warning return or is lost due to lack of power.
  • Page 25 P a g e | 25 Bad weather such as strong wind and Please do not use the drone in bad weather rainstorm will affect the flight stability such as strong wind and heavy rain. If the Flying in or damage the performance of the drone meets strong wind and heavy rain bad weather drone, and eventually lead to crash of...

  • Page 26: Installation Troubleshooting

    P a g e | 26 The power plug of the If the drone's power supply plug turns The power supply plug of the drone should drone is black and becomes abnormally hot, it be replaced regularly. If the plug is found to black and will cause the drone to lose power, be black and abnormally hot, it should be...

  • Page 27: Package And Transport

    P a g e | 27 It is necessary to control the drone as much as possible and choose a safe place White light Drone out of control to land. The green light flashes The return point position is Normal quickly when taking off successfully recorded The drone will return to the take-off...

  • Page 28: Cleaning And Maintenance Requirements

    P a g e | 28 21. Cleaning and maintenance requirements The drone spraying system must be cleaned with clean water 3-5 times a day after operation. Due to the strong corrosion of pesticides, the service life of the aging liquid pump of the pesticide pipe will be short and the nozzle will be blocked.
