Evervue G60S PRO User Manual

2.4G & BT5.5 DUAL MODE WIRELESS VOICE AIR MOUSE
USER'S MANUAL
A
B
C J
Q
K
D
L
E
M
F
N
G
O
H
I
P
1 PRODUCT DIAGRAM
This is a wireless fidelity voice input air mouse with built-in gyroscope and gravity acceleration sensor;
It can perform the functions of a traditional remote control, computer mouse, and gaming motion
controller on android platform.
Plug and play micro receiver is compatible with personal computer, projector, TV box, Home theather,
Personal Computer, etc. Holding air mouse and rotating your wrist us converted into a movement of a
cursor across the screen and it allows you to control your computer; projector and other entertainment
equipment from a distance.
Ergonomics of air mouse will replace stationary computer mouse and infrared button remote control
giving you convenience to manage your computer and television set from a position which is most
comfortable for you.
-
A Power IR Learning key
-
B Mouse ON/OFF
-
C Backspace
-
D Navigation keys (Up/Down/Left/Right)
-
E Home return / Mouse right
-
F
Volume down (-)
-
G Play / Pause
-
H Previous
-
I Indicator
-
J Menu
S T
-
K Enter / Mouse Left
-
L Long press to turn ON/OFF the backlit
-
M Open Google Voice Assistant
-
N Volume up (+)
-
O Next
-
P
Mic
-
Q Full keyboard
-
R Touch panel
-
S Charging Interface
-
T ON/OFF
2 PRODUCT FEATURES
Laser engraving with backlit
Dual Mode: 2.4G & BT5.0
R
High Quality voice input
Built-in 6-axis gyroscope
3 PRODUCT SPECIFICATION
Product Name: G60S PRO
Transmission Method: 2.4G RF wireless & BLE 5.0
Sensor: 6-axis Gyroscope
Number of keys: 80 keys
Transmission Distance: 8 - 10m
Support IR
Learning Keys
NOTE: Upon completion of learning IR cod tfie original code values are replaced
with new codes; Press "OK" and "Del" buttons for three seconds to restore the
factory settings.
4 HOW TO USE THE IR PROGRAMMING
The operation steps of infrared programming are as follows:
(Take learning the power button on the infrared remote control as an example)
1. Press and hold the [power] button of this product for 3 seconds. When the red indicator
light flashes slowly, prompt to enter the IR programming mode.
2. Position the product and your TV remote head-to-head on a flat surface with 1 inch apart,
press the [power] button of your IR remote control, then the indicator light will go out
flashing, indicating that the infrared programming is completed.
6 IR Learning keys
Fully QWERTY mini keyboard on the backside
Built-in 320mAh rechargeable lithium battery
Working Current: <5ma
Quescent Current: <15ua
Product Material: ABS Plastic and silicone
Product Size: 178 * 50 * 16mm
Product Weight: 90g
ICON FUNCTION
Power
Del
Menu
Previous
Play Pause
Next
www.evervue.com
