Actisense W2K-1 Quick Start Manual And Safety Instructions

W2K-1
NMEA 2000 Wi-Fi Gateway
QuickStart Guide and Safety Instructions – rev
USA: Federal Communications Commission (FCC) Statement
This device complies with FCC part 15 FCC Rules.Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference, including interference that may cause undesired operation of the device.
FCC Warning
Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to
operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This device meets the FCC and IC requirements for RF exposure in public or uncontrolled environments.
Suppliers Declaration of Conformity
47 CFR § 2.1077 Compliance Information
Unique Identifier : Actisense W2K-1
Responsible Party - US Contact Information
GEMECO Marine Accessories
1141 S.Ron McNair Boulevard
Lake City, SC 29560
Phone : 803-693-0777 / Fax 803-693-0477
https://www.gemeco.com/
Canada: Industry Canada (IC) Statement
IC Notice to Users English/French in accordance with RSS GEN Issue 3:
This device complies with Industry Canada license exempt RSS standard(s). Operation is subject to the following two conditions:
1. this device may not cause interference, and
2. this device must accept any interference, including interference that may cause undesired operation of the device.
Cet appareil est conforme avec Industrie Canada RSS standard exempts de licence (s). Son utilisation est soumise à Les deux
conditions suivantes:
1. cet appareil ne peut pas provoquer d'interférences et
2. cet appareil doit accepter Toute interférence, y compris les interférences qui peuvent causer un mauvais fonctionnement du
dispositive
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada
European Union:
The full text of the EU declaration of conformity is available at the following internet address:
https://www.actisense.com/acti_download/w2k-1-declaration-of-conformity/
Hereby, Active Research Ltd declares that the W2K-1 is in compliance with the essential requirements and other relevant
provisions of Directive 2014/53/EU.
Intended Use:
The W2K-1 is a compact and low-power NMEA 2000 to Wi-Fi Gateway intended to transfer data from an NMEA 2000 backbone to
any compatible device (e.g. laptop, tablet or smartphone) connected to it via Wi-Fi. All the data received can be logged to its
internal micro SD card for later downloading. It is NMEA 2000 certified and should be installed by a competent person with a
knowledge of NMEA 2000 networking.
Safety Precautions and Warnings:
All Safety Precautions and Warnings must be followed prevent personal injury and to ensure the correct operation of the W2K-1.
Incorrect installation may invalidate the guarantee.
Installation and Operation:
provided. Failure to do so could result in personal injury, damage to your boat and/or poor product performance. It is to be used
as a navigational aid only and must never be used in preference to sound navigational judgement.
Installation Code of Practice:
prevent damage the W2K-1. Any connection to a battery or power supply must meet the mandatory essential safety
1.2
requirements that may be imposed by local regulatory agencies, this should include suitable fusing. All wiring should be in
accordance with the requirements of the NMEA 0400 installation specification.
Mounting Requirements:
connected. Select a flat location to mount the W2K-1. Mounting on a contoured surface may cause damage to the case.
The W2K-1 has an internal antenna which is located on the end opposite to the NMEA 2000 connector and should not be
mounted on a metal surface. To ensure best range it should be mounted vertically and located centrally on the boat as high as
possible, avoiding other metallic objects.
Safe Distance:
body. To avoid potential injury it should be mounted at a height of less than 2m from floor level.
Product Disposal:
Please consider the environment when disposing of this product. It should be disposed of according to the European WEEE
Directive, or according to the applicable local regulations for the disposal of electrical equipment. The product packaging is
recyclable.
Radio Transceiver:
The W2K-1 contains a Wi-Fi / Bluetooth Radio Transceiver operating in the 2400 – 2483.5 MHz band with a maximum transmit power
of 81mW.
Guarantee:
The product is covered by a 5 year "return to base" guarantee if registered. (else it is 3 years) Please refer to the full user manual at
www.actisense.com
Operating Instructions:
A full user manual is available at
The W2K-1 should be connected to a correctly powered and terminated NMEA 2000 network which has at least 2 NMEA certified
devices attached. The Blue "Power" LED will pulse showing correct operation.
Connecting to Wi-Fi:
The W2K-1 will power up in Access Point mode and it will broadcast it's SSID as "w2k-<serial number>" The serial number and
default password can be found printed on the back of the case. Connect to it using a Web browser on the connected device and
type the IP address 192.168.4.1 into the address bar.
Configuring:
The device can be configured using the devices built-in web application. The default login Username is "admin" and the default
password is "admin". Note: On firmware versions > v1.341 the default login password is the same as the Wi-Fi password above.
Note: The W2K-1 can be configured to use Client (Station) mode to join an existing Wi-Fi network.
1
Warning: This product must be installed and operated in accordance with the instructions
Warning: When wiring the power supply to the W2K-1 ensure the isolation switch is o to
Warning: Do not mount the W2K-1 while the device is powered, or the cable harness is
Warning: The W2K-1 should not be mounted within 5m of a compass or operated within 20cm of a human
www.actisense.com or else via the "Help" menu on the device's built-in web application.
(en)
