- Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. LG LS-C1210HD Owner's Manual Shop genuine replacement parts for LG LS-C1210HD Find Your LG Air Conditioner Parts - Select From 2328 Models -------- Manual continues below --------...
- Page 2 DELUXE HIGH WALL MINI SPLIT INSTALLATION INSTRUCTIONS IMPORTANT! Please read this instruction sheet completely before installing the product. This air conditioning system meets strict safety and operating standards. As the installer or service person, it is an important part of your job to install or service the system so it operates safely and efficiently. WARNING •...
-
Page 3: Table Of Contents
OUT-LINE OF INSTALLATION Installation works Installation Parts Required Tools 1. Installation Parts Providided 2. Installation of indoor, Outdoor Unit 1) Selection of the best location..3 • Installation Plate • Level 2) Indoor unit Installation .....4 • Four Type "A" screws •... -
Page 4: Installation Parts Providided
1. Installation Parts Provided 1. Type "A" screw 3. Type "B" screw 4. Holder Remote-Controller 2. Installation Plate 2. Installation of Indoor, Outdoor unit 1) Selection of the best location 1. Indoor unit. There should not be any heat source or •... -
Page 5: Indoor Unit Installation
2) Indoor Unit Installation The mounting wall should be strong and solid enough to protect it from the vibration. 1.Mount the installation plate on the wall Installation Plate with four Type "A" screws. (if mounting the unit on the concrete wall, consider using anchor bolts.) •... -
Page 6: Piping And Drainage Of Indoor Unit
3. Piping and Drainage of Indoor Unit 1) Preparation of pipings Pipe cutter 1. Cut the pipes and the cable. • Use the pipes purchased locally. • Measure the distance between the indoor Rough Slanted and the outdoor unit. • Cut the pipes a little longer than measured distance. -
Page 7: Pipes: Gas Side
2) Connection of Pipings 1. Remove the indoor tubing with Drain hose from the hole • Remove tubing holder and pull the tubing out of the chassis. 2. Replace the tubing holder into original position. • Recommended SPEC. of the additional Drain Hose. - Page 8 6. Indoor unit installation • Hook the indoor unit onto the upper portion of installation plate. (Engage the two hooks Connecting of the rear top of the indoor unit with the cable upper edge of the installation plate.) Ensure the hooks are properly seated on the installation plate by moving it left and right.
-
Page 9: For The Left Pipings
For the left pipings 3. Route the indoor tubing with the drain hose to the piping hole as desired position. Tubing holder To remove the holder, press the bottom of chassis near the holder ¤Ł Pull upward and pull the tab ¤... -
Page 10: Liquid Side
5. Insert the connecting cable into the indoor unit. • Don't connect the cable to the indoor unit. • Make a small loop with the cable for easy Indoor/outdoor connecting cable connection later. 6. Tape the tubing, drain hose and the connecting cable. - Page 11 10. Set the pipings and the connecting cable to the back of the chassis with the tubing holder • Hook the edge of tubing holder to tap on chassis and push the bottom of tubing holder to be engaged in the bottom of chassis. Drain hose Taping Piping...
-
Page 12: Connecting Pipings And The Cable To Outdoor Unit
4. Connecting Pipings and the cable to Outdoor unit 1) Connecting the pipings to the Outdoor unit 1. Align the center of the pipings and sufficiently tighten the flare nut with fingers. Outdoor unit 2. Finally, tighten the flare nut with torque wrench until the wrench clicks. - Page 13 Connection method of the connecting cable(Example) (1) Dismount two-caps on the conduit panel. (2) Make a hole appropriate for the passage of connection cable through on cap by tool. (for low voltage line) (3) Pass the connecting cable through the hole. (4) Properly connect the cable on the terminal block.
-
Page 14: Checking The Drainage And Connecting The Cable To Indoor Unit
5. Checking the Drainage and Connecting the cable to Indoor unit 1) Checking the Drainage 1. Remove the Grille from the cabinet. Chassis Grille • Set the up-and-down air direction louver to open position (horizontally) by finger pressure. • Remove 3 screws. •... -
Page 15: Connecting Of The Cable
2) Connect the cable to the indoor unit 1. Connect the wires to the terminals on the control board individually according to the outdoor unit connection. • Ensure that the color of the wires of outdoor unit and the terminal No. are the same as those of indoor unit respectively. -
Page 16: Forming The Pipings
3) Forming the pipings 1. Wrap the connecting portion of indoor unit with the Insulation material and secure it Seal a small opening with two Plastic Bands.(for the right around the pipings with gum type sealer. pipings) • If you want to connect an additional drain hose, the end of the drain-outlet should keep Drain hose distance from the ground.(Do not dip it into... -
Page 17: Air Purging
6. Air Purging Air and moisture remaining in the refrigerant system have undesirable effects as indicated below. • Pressure in the system rises. Indoor unit • Operating current rises. • Cooling(or heating) efficiency drops. • Moisture in the refrigerant circuit may freeze and block capillary tubing. - Page 18 § Evacuation 1. Connect the charge hose end described in the preceding steps to the vacuum pump to evacuate the tubing and indoor unit. Indoor unit Confirm the "Lo" knob of the manifold valve is open. Then, run the vacuum pump. The operation time for evacuation varied with the tubing length and capacity of the pump.
-
Page 19: Test Running
7. Test running (1) Check that all tubing and wiring have been properly connected. (2) Check that the gas and liquid side service valves are fully open. Prepare to Remote Control • Insert two batteries provided. Remove the battery cover from the remote controller. -
Page 20: Installation Instruction Templates
8. Installation Instruction Templates Left Side Installation... - Page 21 Right Side Installation Models...
