- Page 1 WRANGLER AUDIO KIT Installation Guide v.4.24.24...
- Page 2 Wet Sounds technical support by dialing 1-877-WET-SPKR (1-877-938-7757). !WARNING! We build all Wet Sounds products to play at high volumes for extended periods of time. Your ears however are not designed for high volume listening. This product can easily generate high volumes that can permanently damage your hearing.
-
Page 3: Table Of Contents
Amp Bracket Installation ................Power Harness Installation ................. 10-12 Audio Harness Installation ................13-14 Front Speaker Installation ................15-16 Rear Speaker Installation ................17-18 Subwoofer Installation ................19-20 Level Control Installation ................21-22 Limited Warranty ..................Wet Sounds JEEP-JL-LVL1-C Install Guide... -
Page 4: Disassembly
This screw fastens the upper dash panel to the vehicle. You can now unclip this panel and remove it from the vehicle. This will expose (8) screws securing the instrument panel cover, and airbag cover. Wet Sounds JEEP-JL-LVL1-C Install Guide... - Page 5 Remove the (3) bolts securing the speaker pod to the dash and unclip both harnesses from the pod. There is an electronic module attached to the back of this pod that will be reused later for reassembly. Wet Sounds JEEP-JL-LVL1-C Install Guide...
- Page 6 From the footwell area looking up into the glovebox opening, there will be (2) 13 mm screws used to secure the passenger airbag. Remove these screws and gently unclip the airbag cover. Wet Sounds JEEP-JL-LVL1-C Install Guide...
- Page 7 The next panels needing to be removed would be from the overhead trim. Take the passenger side front trim panel off by removing the T25 torx screws, and angle driver will aid in this. Unclip and set aside. Wet Sounds JEEP-JL-LVL1-C Install Guide...
- Page 8 (2) 10 mm bolts fastening the grab handle, followed by un-clipping the panel and re- moving from the vehicle. The vehicle is now completely disassembled and you are now able to begin the installation of the amp mount bracket. Wet Sounds JEEP-JL-LVL1-C Install Guide...
-
Page 9: Amp Bracket Installation
Get all (4) bolts started, then tighten completely. You can fasten the amp to the mount now using the hardware provided. (If you are doing the LVL2-T kit, you can install that amp at this time as well.) Wet Sounds JEEP-JL-LVL1-C Install Guide... -
Page 10: Power Harness Installation
Under the carpet you will find a rubber grommet currently not in use. Remove this grommet and use the step drill bit to pierce a hole into the grommet large enough for the wire to be snugly ran through. Wet Sounds JEEP-JL-LVL1-C Install Guide... - Page 11 M6 20 mm allen head hard- ware. The second mount will be an unused factory threaded location. You can now fasten the power wire to the distribution block terminals located towards the front of the vehicle. Wet Sounds JEEP-JL-LVL1-C Install Guide...
- Page 12 Connect the battery power harness with the eyelet to the positive side of the battery terminal. Use the threaded stud indicated in the picture. Wet Sounds JEEP-JL-LVL1-C Install Guide...
-
Page 13: Audio Harness Installation
This connector will need to be used in place of the factory sound bar harness. Simply disconnect the factory harness, and connect the new audio harness to the sound bar. Continue routing the main harness forward towards the passenger side foot well. Wet Sounds JEEP-JL-LVL1-C Install Guide... - Page 14 A wire runner will aid in routing this harness up the inside of the dash. This will connect directly to an amplifier integration interface compatible with your Jeep, or any aftermarket radio. Wet Sounds JEEP-JL-LVL1-C Install Guide...
-
Page 15: Front Speaker Installation
These will mount using the factory hardware. Connect the factory harness back into the control module and the shorter portion of the front speaker harness into the audio harness you ran under the dash earlier. Wet Sounds JEEP-JL-LVL1-C Install Guide... - Page 16 Run the longer portion of the front speaker harness up the dash toward the tweeter mounting location. Connect the tweeter to the harness and snap the panel into place. Wet Sounds JEEP-JL-LVL1-C Install Guide...
- Page 17 Plug in the Rear Speaker harness into the factory harness on both sides of the sound bar. Connect the other side of the harness into the 6x9 speakers and mount with the supplied hardware. Wet Sounds JEEP-JL-LVL1-C Install Guide...
-
Page 18: Rear Speaker Installation
PEAKER NST ALLA TION You can now install the new speaker grills using the original grill hardware. Wet Sounds JEEP-JL-LVL1-C Install Guide... -
Page 19: Subwoofer Installation
A rubber plug is provided to cover this hardware after installation. You can now place the loaded enclosure into the vehicle and fasten the rear hinge with the supplied clevis and snap rings. Wet Sounds JEEP-JL-LVL1-C Install Guide... - Page 20 Install the shocks to the amp bracket using the supplied nuts and bolts. *Keep allen head side facing in. Connect the Subwoofer Output Harness to the enclosure, followed by the SYN-DX6. Wet Sounds JEEP-JL-LVL1-C Install Guide...
- Page 21 1/8” drill bit to drill the holes for the mounting screws. Install the level control knob bracket along with the harnesses. Attach the bracket to the panel through the holes you drilled in the previous step. Cut Template Wet Sounds JEEP-JL-LVL1-C Install Guide...
-
Page 22: Level Control Installation
Now you can finish running the level control portion of the audio harness into the console and connect it to the level control knob. Reinstall the panel and make sure the harness clears the 4wd selectors moving mechanisms. Wet Sounds JEEP-JL-LVL1-C Install Guide... - Page 23 Wet Sounds JEEP-JL-LVL1-C Install Guide...
-
Page 24: Limited Warranty
Wet Sounds dealer.) Wet Sounds is not responsible for any damages to a consumer’s boat or person from a product failure. The warranty is void if Wet Sounds deems the product was installed or used improperly. Wet Sounds shall not be responsible for any incidental or consequential damages, except to the extent provided (or prohibited) by applicable law. - Page 25 Wet Sounds JEEP-JL-LVL1-C Install Guide...
- Page 26 2975 Louise Street Rosenberg, Texas 77471 USA © 2024 Wet Sounds, Inc. All Rights Reserved. WET SOUNDS and associated logos where applicable are registered trademarks of Wet Sounds Corporation in the United States and/or other countries. All other trademarks are the property of their respective owners.
