- Page 1 PTS-DR200L Clock Server Hardware Installation Manual Published: October 2023 Version: V1.0...
- Page 2 Disclaimer: Kyland Technology (Yichang) Co., Ltd. strives to make the information in this manual as accurate and up-to-date as possible. However, we cannot guarantee that this manual is completely free of any technical or clerical errors and reserve the right to modify it without notifying the user.
- Page 3 Instructions for safe use This product has good and reliable performance within the designed range of use, but it is necessary to avoid man-made damage or destruction to the device. Please read the manual carefully before using the device to ensure the safety of users and device. Please keep this manual properly after reading it for future reference.
- Page 4 or other metal objects to prevent electric shock or scalding. Do not operate device or connect or disconnect cables in lightning weather. Please use connectors and cables approved by our marketing personnel or technical support personnel to avoid affecting module functions due to non-compliance of connectors and cables. ...
-
Page 5: Table Of Contents
Directory 1 Product Overview ......................... 1 2 Structure and Interface ......................2 3 Dimension Figure ........................6 4 Wiring ..........................7 10/100/1000Base-T (X) And 10/100 Base-T (X) Ethernet Interfaces ........7 RS-485 Interface ......................8 100Base-X, SFP Interface ....................9 4.3.1. 100-Megabit SFP Optical Module ................9 SAT Antenna Interface .................... -
Page 6: Product Overview
Product Overview 1 Product Overview PTS-DR200L card rail clock server product is a set of clocks and switching functions in one device. The board supports guideway/wall-mounted installation, and supports at most 2 100-megabit SFP+ 2 10/100 Base-T (X) ports +1 10/100/1000Base-T (X),... -
Page 7: Structure And Interface
Structure and Interface 2 Structure and Interface Device port figure Figure1 Device Front Port Label Figure... - Page 8 Structure and Interface Figure2 Label Figure of Side Port of Device Table2 Device port Label Description Serial Describe number Display screen Device optical signal input port FI BNC port of device output signal 100-megabit electrical ports ETH0 100-megabit optical ports SFP0 Query button Power indicator lamp...
- Page 9 Structure and Interface Star search indicator light Satellite lock indicator (10) External antenna indicator (11) Two-way RS485 (12) Interface gigabit port connection status indicator (green) (13) Gigabit port (14) Gigabit port rate indicator (yellow) (15) 100-megabit electrical port connection status indicator (green) (16) 100-megabit electrical port ETH1 (17)
- Page 10 Structure and Interface Device description Figure Figure3 Device Annotation Figure Figure4 Supplement Of Device Annotation Figure...
-
Page 11: Dimension Figure
Dimension Figure 3 Dimension Figure Figure 5 Dimension Figure (Unit: mm) Note: Device casing is a part of the heat dissipation system of the whole machine. The casing will heat up when working normally. Please do not cover the casing when working. ... -
Page 12: Wiring
Wiring 4 Wiring 10/100/1000Base-T (X) And 10/100 Base-T (X) Ethernet Interfaces 10/100/1000Base-T (X) and 10/100 Base-T (X) Ethernet interfaces adopt standard RJ45 connectors, which have adaptive functions and can be automatically configured to 10M/100M/1000M or 10M/100M/state and full-duplex/half-duplex operation mode, and support MDI/MDI-X self-identification function of cables, that is, connect with terminal device and network device using direct network cable or cross network cable. -
Page 13: Rs-485 Interface
Wiring Figure 7 10/100 Base-T (X) RJ45 Connector Direct Wire, Cross Wire Interconnect Description: RJ45 connector wiring according to standard 568B (1-orange white, 2-orange, 3-green white, 4-blue, 5-blue white, 6-green, 7-brown white, 8-brown). RS-485 Interface RS-485 interface (pin definition as shown in the following figure) 8 Interface Pin Definition Figure 4 Serial Interface Pin Definition... -
Page 14: 100Base-X, Sfp Interface
Wiring 100Base-X, SFP Interface 100Base-X, SFP interface (i.e., 100-megabit SFP interface) needs to be inserted into SFP optical/electrical module before connecting cables for communication. The recommended 100-megabit SFP optical/electrical modules (optional) for this device are shown in the following table. Table 5 100-megabit SFP optical/electrical module Multimode/ Central... - Page 15 Wiring the optical fiber is inserted into the RX and TX of the 100-megabit SFP optical module respectively. Figure 11 Usage of 100-megabit SFP optical module Confirm the RX and TX of the 100-megabit SFP optical module 1. Insert two connectors at one end of the optical fiber into two interfaces of the 100-megabit SFP optical module respectively, and then insert two connectors at the other end of the optical fiber into two interfaces at the corresponding end respectively.
-
Page 16: Sat Antenna Interface
Wiring SAT Antenna Interface Figure 12 SAT Antenna Interface The external antenna is connected with the device through the SAT antenna interface, and is used for assisting the device to search and receive satellite signals for timing Optical Signal Input Interface FI Figure 13 Optical signal input interface FI The optical signal input port FI of the device receives the B code input signal Device Output Signal Interface... -
Page 17: Console Port
Wiring Console Port Use the DB9-RJ45 network pipeline to connect the 9 pin serial port of the PC to the console of the device, or connect the DB9-RJ45, USB-DB9 network pipeline in series and then connect the USB port of the PC to the console of the device. The Console software of the device can be called by running the Hyper Terminal of WINDOWS system or the related software tools, and the configuration, maintenance and management functions of the device can be realized. -
Page 18: Power Terminal
Wiring Figure 17 Schematic figure of physical objects Table6 DB9 Interface (PC Terminal 9 Pin Serial),RJ45 Interface (Console) Pin Definition DB9Interface (DB9-RJ45) RJ45Interface (Console) Signal Signal RXD(received data) TXD(send data) TXD(send data) RXD(received data) GND(Ground) GND(Ground) Power Terminal This series of device adopts 3-core 5.08 mm spacing plug-in power terminals and supports single-channel power supply. - Page 19 Wiring Power Supply +/L Power Supply-/N Wiring and installation Step 1: Remove the power terminal plug from the device. Step 2: Plug one end of the power cord into the power terminal plug according to Table and fix the power cord Step 3: Plug the plug connected with the power cord back to the corresponding power terminal socket of the device.
-
Page 20: Reset Button
Reset Button 5 Reset Button The Reset button has the function of restarting and restoring the default configuration. Press the reset button continuously for 0.5 ~ 3 seconds and then release it to complete the device restart. Press the reset key continuously for more than 3 seconds (less than 10 seconds), then release to restore the default configuration and restart, and press the reset key continuously for more than 10 seconds, then release the cancellation action (neither reset nor restore the factory settings). -
Page 21: Led Indicator Status
LED Indicator Status 6 LED Indicator Status Table 8 Description of Board Indicator Light Status Describe Bright The input power supply is connected and running normally Power indicator PWR The input power supply is not connected or not operating properly The number of stars searched by the device is not less than Bright four stars... - Page 22 LED Indicator Status Bright 1000M operating state (i.e. 1000Base-T) 10M/100M/1000M Ethernet Interface Rate Indicator 10/100 m operation (i.e. 10/100 Base-T (X)) or no (Yellow) connection Bright Port has established a valid network connection 10M/100M/1000M Ethernet Interface Connection Status Flash Port has network activity Indicator (Green) Port does not have a valid network connection Indicator lights 1 and 2 indicate the status of the lower SFP interface;...
-
Page 23: Access
Access 7 Access You can access the device in three ways. 7.1 Console Port Access Use the 9 pin serial port connecting the DB9-RJ45 network pipeline to the PC and the console of the device, or connect the DB9-RJ45 and USB-DB9 network pipeline together, and then connect one end to the USB serial port of the PC. -
Page 24: Web Access
Step 2: Enter the IP address of the device in the address bar of the browser. After opening the login dialog box, enter the default user name and default password, and you can successfully log in to the device Web management page. Table 9 IP And Login Account Password Corresponding To PTS-DR200L Network Port Product type Illustrated... - Page 25 Access Description: Firefox or Google Browser is recommended. For device access and other specific operations, please refer to the supporting Web operation manual.
-
Page 26: Basic Performance And Specifications
Basic Performance and Specifications 8 Basic Performance and Specifications Power supply Power identification Rated voltage value PTS-DR200L-1111-HV: 220VAC/DC (85-264VAC/77-300VDC) Input voltage PTS-DR200L-1111-L2: 24VDC (18 ~ 72VDC) Access terminal 3-core 5.08 mm pitch plug-in terminal Rated power Rated power < 12W Mechanical structure... - Page 27 Customer Service Hotline: 010-88796676 Fax: 010-88796678 Website: http://www.Kyland.com.cn Email: services@Kyland.com.cn For more information about KYLAND products, please visit the website: http://www.Kyland.com.cn http://www.Kyland.com...
