Oil Alert - Three Phase, Simplex
Model: OAHC3S | Hard Wired, Clear Door
QSG00362_Rev04_Oil Alert Hard Wired Clear Door 3P Simplex OAHC3S Series.pdf | September 12th, 2023 3:01pm
Introduction
Product Overview
The Oil Alert Simplex control system is designed and approved for the safe operation of pumping, alarming and
monitoring elevator sump pits, transformer vaults and leachate well applications. The Oil Alert will activate a pump
to remove water from elevator pits in accordance with ASME A17.1. The Oil Alert stops the pump before oil or
other harmful substances enter our water supply.
A menu system with a rotary encoder interface and a front facing RGB indicator beacon provide indication of the
current system state as well as access to the application configurations. Hand-Off-Auto controls for each pump
are provided via push button control or via optional toggle switches mounted on the inner door of the panel.
The panel also has several auxiliary dry contact outputs. They are as follows:
Auxiliary
Contact
C1
O
W
C2
T1
P1
Operation
The Oil Alert control system has two modes of operation; Standard Oil Alert for Sump Applications and Pump
Station for Lift Station Applications. The panel will be programmed at the factory for one mode or the other based
Meaning
Common 1
Oil Alarm Contact
Water Alarm Contact
Common 2
Trouble Alarm 1
Contact
Pump 1 Run Contact
This is the common connection for the O and W contacts
Oil Alarms
Water Alarms, Input Errors, and Power Loss
This is the common connection for the T1, P1, T2, and P2
contacts
P1 Overload, P1 Under Current, P1 Over Current, P1 Fail, P1
Contactor Latched
P1 Run
Function/Trigger

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OAHC3S and is the answer not in the manual?

Questions and answers

Related Manuals for Alderon Industries OAHC3S

Summary of Contents for Alderon Industries OAHC3S

  • Page 1 Oil Alert - Three Phase, Simplex Model: OAHC3S | Hard Wired, Clear Door QSG00362_Rev04_Oil Alert Hard Wired Clear Door 3P Simplex OAHC3S Series.pdf | September 12th, 2023 3:01pm Introduction Product Overview The Oil Alert Simplex control system is designed and approved for the safe operation of pumping, alarming and monitoring elevator sump pits, transformer vaults and leachate well applications.
  • Page 2 on the sensors purchased with the panel. However, this setting can still be changed in the field by the user. See the Settings section for further details. Standard Oil Alert for Sump Applications This mode uses the standard preset level sensor (three water probes and one float) for elevator sump applications.

  • Page 3: Pump Monitoring

    active until the stop float goes down. If water continues to rise and activates the alarm float, a high level alarm will be triggered. In this mode, the extra digital input (PCB Input FLT 2) will configured as a fire system alarm input. If the fire input is active, ANY sensor input will activate the pumps in order to empty the pit during emergencies.

  • Page 4: Safety Guidelines

    moisture or gases from entering the panel. NEMA 1 enclosures are for indoor use only while NEMA 4X panel enclosures may be used indoor or outdoor. Refer to panel model name plate on inside of door for enclosure rating. Note: If options are ordered that affect the number of floats, refer to the panel schematic for complete information. Safety Guidelines 1.

  • Page 5: Board Power

    Fig.3 - Oil Alert PCB Board Power Board power for the Oil Alert PCB is wired directly into the L and N terminals in the lower right quadrant of the PCB pictured above. The PCB is connected to earth ground via the aluminum backplate of the panel. Therefore, earth ground from both the pump and control power inputs MUST be connected to the backplate using the provided ground connection points to ensure proper operation of the product.

  • Page 6: Menu System

    FLT 2 Input Input G Input Y Input R Input F Configuration Fire Input Stop Start High Water Fire Input (Default) Probe Probe Probe Float Stop Start High Water Low Alarm/Redundant Off Low Alarm Probe Probe Probe Float Float When using the pump station mode (3-4 floats with a single water detecting probe), all of the floats must have a common return connected to either (B) or the GND terminal.
  • Page 7 Action Result Scrolling Clockwise Navigate to the Right, Increase a Config Value Scrolling Counter-Clockwise Navigate to the Left, Decrease a Config Value Activating Test/Silence Switch Cancel Input; Silence Alarm; Exit Menu; Start Test Routine Test/Silence Switch Note The Test/Silence switch on the side of the panel can be used to: Silence the buzzer Cancel user inputs Exit the menu system...

  • Page 8: Menu Conventions

    Menu Conventions There are a set of arrow indicators that will appear on the bottom line of the display to aid with menu navigation. Below is a table summarizing these indicators: Indicator             Image Meaning Right Arrow on The user can navigate forward or select a config from Bottom Right here.
  • Page 9 To Clear an Alarm To clear an alarm, simply scroll to it in the main screen (press the test/silence switch to jump there) and then press the rotary knob. A confirmation screen will appear and ask if the alarm should be cleared. Press the knob again to clear the alarm.

  • Page 10: Optional Configurations

    This is for lift station applications where three or four floats are used with a suspension oil probe Step 3 (In Setup Wizard) Enter Full Load Amps (FLA) for the pump. This will configure the high and low amps alarm points for the pump. The system will set the trip points at 25% above and below the FLA entered here.

  • Page 11: Available Settings

    Step 6 (Optional) Review the Settings section of this manual for any other configurations that may be relevant to the application. The system at this point is configured for a basic application. However, there are several other configurations available in the system that may be useful depending on the specific system requirements. Stats The Oil Alert panel tracks several statistics for the system.
  • Page 12 Name Menu Path Range Description System MENU->SETTINGS- High, Med, This controls how bright the system normal Normal LED >PASSWORD->SYSTEM Low, Off indicator LEDs are. Brightness SET UP->NORMAL LED MENU->SETTINGS- Password 0000 - This is the system password. It can be >PASSWORD->SYSTEM Change 9999...

  • Page 13: Input Configurations

    Name Menu Path Range Description MENU->SETTINGS- This is the exercise timer for pump one. If the Pump One >PASSWORD->PUMP SET Disabled - pump has been inactive for the indicated Exercise UP->PUMP 1->P1 45 Days number of days, the system will briefly run Interval EXERCISOR INT the pump to maintain long term pump health.
  • Page 14 Config codes on this product can be decoded by customer support to provide a snap-shot for how the system is configured. The code itself is a base 32 number that must be decoded to yield the system configurations. © 2023 Alderon Industries. All rights reserved. | Powered by Wiki.js...
