Edition
05/2024
Reference Manual
SIMATIC NET
Networking components
RUGGEDCOM SFP transceivers
https://www.siemens.com/ruggedcom

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SIMATIC NET RUGGEDCOM SFP1112-1 and is the answer not in the manual?

Questions and answers

Related Manuals for Siemens SIMATIC NET RUGGEDCOM SFP1112-1

Summary of Contents for Siemens SIMATIC NET RUGGEDCOM SFP1112-1

  • Page 1 Edition 05/2024 Reference Manual SIMATIC NET Networking components RUGGEDCOM SFP transceivers https://www.siemens.com/ruggedcom...
  • Page 2 Preface Introduction Copper SFP transceivers SIMATIC NET Active 100 Mbps SFP transceivers Networking components Fast Ethernet SFP RUGGEDCOM SFP transceivers transceivers Bidirectional Gigabit Ethernet SFP transceivers Reference Manual Gigabit Ethernet SFP transceivers 10-Gigabit Ethernet SFP+ transceivers Installation/removal 05/2024 C79000-G8976-1251-35...
  • Page 3 Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.

  • Page 4: Table Of Contents

    Cybersecurity information ....................... v SIMATIC NET glossary ......................v Registered trademarks ......................vi Training ..........................vi Customer support ........................vi Contacting Siemens ....................... vii Ordering RUGGEDCOM products .................... vii Introduction ........................... 1 Important notes ....................1 Selecting an SFP transceiver .................. 2 Available SFP transceivers ..................
  • Page 5 Table of contents RUGGEDCOM SFP1122-1SX ................. 46 RUGGEDCOM SFP1122-1SX2 ................48 RUGGEDCOM SFP1132-1LX10 ................50 RUGGEDCOM SFP1132-1LX25 ................52 RUGGEDCOM SFP1132-1LX40 ................54 RUGGEDCOM SFP1132-1LX70 ................56 RUGGEDCOM SFP1132-1LX100 ................58 RUGGEDCOM SFP1132-1LX115 ................60 10-Gigabit Ethernet SFP+ transceivers ................63 RUGGEDCOM SFP2123-1SR .................

  • Page 6: Preface

    Cybersecurity RSS Feed under https://www.siemens.com/cert. SIMATIC NET glossary The SIMATIC NET glossary describes special terms that may be used in this document. The glossary is available online via Siemens Industry Online Support (SIOS) at: https://support.industry.siemens.com/cs/ww/en/view/50305045 RUGGEDCOM SFP transceivers Reference Manual, 05/2024, C79000-G8976-1251-35...

  • Page 7: Registered Trademarks

    Siemens Sales representative. Customer support Customer support is available 24 hours, 7 days a week for all Siemens customers. For technical support or general information, contact Siemens Customer Support through any of the following methods: Online Visit http://www.siemens.com/automation/support-request...

  • Page 8: Contacting Siemens

    Preface Contacting Siemens Mobile app Install the Industry Online Support app by Siemens Aktiengesellschaft on any Android, Apple iOS or Windows mobile device and be able to: • Access Siemens' extensive library of support documentation, including FAQs and manuals •...
  • Page 9 Preface Ordering RUGGEDCOM products viii RUGGEDCOM SFP transceivers Reference Manual, 05/2024, C79000-G8976-1251-35...

  • Page 10: Introduction

    RUGGEDCOM router/switch. • Only use SFP transceivers approved by Siemens for RUGGEDCOM products. Siemens accepts no liability as a result of performance issues related in whole or in part to third-party components. • Some RUGGEDCOM routers/switches may only support specific SFP transceivers in select sockets.

  • Page 11: Selecting An Sfp Transceiver

    Each available SFP transceiver has been tested for compatibility with the following RUGGEDCOM routers and switches. Use in any other RUGGEDCOM or third-party router/switch is not supported or recommended by Siemens. Note Some RUGGEDCOM routers/switches may only support specific SFP transceivers in select sockets.
  • Page 12 Introduction 1.3 Available SFP transceivers Type Media Distance SFP name Article number RS900G • • • • • • • • • • • • • • RS900GP • • • • • • • • • • • • • •...
  • Page 13 Introduction 1.3 Available SFP transceivers Type Media Distance SFP name Article number Ports • • • • • • • • • • • • • • • • 0/1-0/4 Modules • • • • • • • • • • •...

  • Page 14: Copper Sfp Transceivers

    Copper SFP transceivers The following copper triple-speed SFP transceivers are available from Siemens for select RUGGEDCOM routers and switches. To determine compatibility, refer to "Available SFP transceivers" (Page 2). RUGGEDCOM SFP transceivers Reference Manual, 05/2024, C79000-G8976-1251-35...

  • Page 15: Ruggedcom Sfp1112-1

    2.1 RUGGEDCOM SFP1112-1 RUGGEDCOM SFP1112-1 Siemens' RUGGEDCOM SFP1112-1 is a 1 Gbps copper SFP transceiver that operates within a wide temperature range (0 to 70 °C or 32 to 158 °F) and provides high performance Gigabit Ethernet communication up to 100 m (328.1 ft).
  • Page 16 Auto negotiation Auto negotiation must be disabled for RUGGEDCOM ROS v3.9 and higher to support 100 Mbps. Product-specific deviations The RUGGEDCOM SFP1112-1 supports the following ratings when installed in the specified Siemens RUGGEDCOM routers and/or switches: Specification Product(s) Rating Speed RUGGEDCOM RSG907R, RSG909R RUGGEDCOM ROS v5.2.2 only...

  • Page 17: Ruggedcom Sfp1112-1I

    2.2 RUGGEDCOM SFP1112-1I RUGGEDCOM SFP1112-1I Siemens' RUGGEDCOM SFP1112-1I is a 1 Gbps copper SFP transceiver that operates within a wide temperature range (-40 to 85 °C or -40 to 185 °F) and provides high performance Gigabit Ethernet communication up to 100 m (328.1 ft).
  • Page 18 • RUGGEDCOM RSG909R • RUGGEDCOM RSG908C • RUGGEDCOM RSG910C Regulator compliance The RUGGEDCOM SFP1112-1I meets the following standards when installed in Siemens RUGGEDCOM routers and/or switches: Feature Standard Performance Electromagnetic Interference FCC Class A, CE Class A, VCCI Compliant (EMI)
  • Page 19 Copper SFP transceivers 2.2 RUGGEDCOM SFP1112-1I RUGGEDCOM SFP transceivers Reference Manual, 05/2024, C79000-G8976-1251-35...

  • Page 20: Active 100 Mbps Sfp Transceivers

    Active 100 Mbps SFP transceivers The following active 100 Mbps Ethernet SFP transceivers are available from Siemens for select RUGGEDCOM routers and switches. To determine compatibility, refer to "Available SFP transceivers" (Page 2). RUGGEDCOM SFP transceivers Reference Manual, 05/2024, C79000-G8976-1251-35...

  • Page 21: Ruggedcom Sfp1121-1Fx2A (Discontinued)

    3.1 RUGGEDCOM SFP1121-1FX2A (discontinued) RUGGEDCOM SFP1121-1FX2A (discontinued) Siemens' RUGGEDCOM SFP1121-1FX2A industrial grade 100 Mbps fiber optic fast Ethernet SFP transceiver operates within a wide temperature range (-40 to 85 °C or -40 to 185 °F) and provides high performance Fast Ethernet communication up to 2 km (1.2 mi) using multi-mode fiber.
  • Page 22 236 years (MTBF) Tested at an operating temperature of 40 °C (104 °F) Regulator compliance The RUGGEDCOM SFP1121-1FX2A meets the following standards when installed in Siemens RUGGEDCOM routers and/or switches: Feature Standard Performance Electrostatic Discharge (ESD) to MIL-STD-883E, Method 3015.7...

  • Page 23: Ruggedcom Sfp1121-1Fx2Ai

    3.2 RUGGEDCOM SFP1121-1FX2AI RUGGEDCOM SFP1121-1FX2AI Siemens' RUGGEDCOM SFP1121-1FX2AI industrial grade 100 Mbps fiber optic fast Ethernet SFP transceiver operates within a wide temperature range (-40 to 85 °C or -40 to 185 °F) and provides high performance Fast Ethernet communication up to 2 km (1.2 mi) using multi-mode fiber.
  • Page 24 For RUGGEDCOM ROX devices, v2.16.1 or higher • For SINEC OS devices, v3.0 or higher Regulator compliance The RUGGEDCOM SFP1121-1FX2AI meets the following standards when installed in Siemens RUGGEDCOM routers and/or switches: Feature Standard Performance Electrostatic Discharge (ESD) to MIL-STD-883E, Method 3015.7...

  • Page 25: Ruggedcom Sfp1131-1Fx10A

    3.3 RUGGEDCOM SFP1131-1FX10A RUGGEDCOM SFP1131-1FX10A Siemens' RUGGEDCOMSFP1131-1FX10A industrial grade 100 Mbps fiber optic fast Ethernet SFP transceiver operates within a wide temperature range (-40 to 85 °C or -40 to 185 °F) and provides high performance Fast Ethernet communication up to 10 km (6.2 mi) using single-mode fiber.
  • Page 26 544 years (MTBF) Tested at an operating temperature of 40 °C (104 °F) Regulator compliance The RUGGEDCOM SFP1131-1FX10A complies with the following regulatory requirements when installed in Siemens RUGGEDCOM routers and/or switches: Feature Standard Performance Electrostatic Discharge (ESD) to MIL-STD-883E, Method 3015.7...

  • Page 27: Ruggedcom Sfp1131-1Fx10Ai

    3.4 RUGGEDCOM SFP1131-1FX10AI RUGGEDCOM SFP1131-1FX10AI Siemens' RUGGEDCOMSFP1131-1FX10AI industrial grade 100 Mbps fiber optic fast Ethernet SFP transceiver operates within a wide temperature range (-40 to 85 °C or -40 to 185 °F) and provides high performance Fast Ethernet communication up to 10 km (6.2 mi) using single-mode fiber.
  • Page 28 For RUGGEDCOM ROX devices, v2.16.1 or higher • For SINEC OS devices, v3.0 or higher Regulator compliance The RUGGEDCOM SFP1131-1FX10AI complies with the following regulatory requirements when installed in Siemens RUGGEDCOM routers and/or switches: Feature Standard Performance Electrostatic Discharge (ESD) to MIL-STD-883E, Method 3015.7...

  • Page 29: Ruggedcom Sfp1131S-1Fx40A

    3.5 RUGGEDCOM SFP1131S-1FX40A RUGGEDCOM SFP1131S-1FX40A Siemens' RUGGEDCOMSFP1131S-1FX40A industrial grade 100 Mbps fiber optic fast Ethernet SFP transceiver operates within a wide temperature range (-5 to 70 °C or 23 to 158 °F) and provides high performance Fast Ethernet communication up to 40 km (24.9 mi) using single-mode fiber.
  • Page 30 181 years (MTBF) Tested at an operating temperature of 40 °C (104 °F) Regulator compliance The RUGGEDCOM SFP1131S-1FX40A complies with the following regulatory requirements when installed in Siemens RUGGEDCOM routers and/or switches: Feature Standard Performance Electrostatic Discharge (ESD) to MIL-STD-883E, Method 3015.7...

  • Page 31: Ruggedcom Sfp1131S-1Fx40Ai

    3.6 RUGGEDCOM SFP1131S-1FX40AI RUGGEDCOM SFP1131S-1FX40AI Siemens' RUGGEDCOMSFP1131S-1FX40AI industrial grade 100 Mbps fiber optic fast Ethernet SFP transceiver operates within a wide temperature range (-40 to 85 °C or -40 to 185 °F) and provides high performance Fast Ethernet communication up to 40 km (24.9 mi) using single-mode fiber.
  • Page 32 Minimum firmware version requirements apply for some devices: • For SINEC OS devices, v3.0 or higher Regulator compliance The RUGGEDCOM SFP1131S-1FX40AI complies with the following regulatory requirements when installed in Siemens RUGGEDCOM routers and/or switches: Feature Standard Performance Electrostatic Discharge (ESD) to MIL-STD-883E, Method 3015.7...
  • Page 33 Active 100 Mbps SFP transceivers 3.6 RUGGEDCOM SFP1131S-1FX40AI RUGGEDCOM SFP transceivers Reference Manual, 05/2024, C79000-G8976-1251-35...

  • Page 34: Fast Ethernet Sfp Transceivers

    Fast Ethernet SFP transceivers The following Fast Ethernet SFP transceivers are available from Siemens for select RUGGEDCOM routers and switches. To determine compatibility, refer to "Available SFP transceivers" (Page 2). RUGGEDCOM SFP transceivers Reference Manual, 05/2024, C79000-G8976-1251-35...

  • Page 35: Ruggedcom Sfp1121-1Fx2

    4.1 RUGGEDCOM SFP1121-1FX2 RUGGEDCOM SFP1121-1FX2 Siemens' RUGGEDCOM SFP1121-1FX2 industrial grade 100 Mbps fiber optic fast Ethernet SFP transceiver operates within a wide temperature range (-40 to 85 °C or -40 to 185 °F) and provides high performance Fast Ethernet communication up to 2 km (1.2 mi) using multi-mode fiber.
  • Page 36 LM 4FG50 module installed, v2.10 or higher • For SINEC OS devices, v2.3 or higher Regulator compliance The RUGGEDCOM SFP1121-1FX2 meets the following standards when installed in Siemens RUGGEDCOM routers and/or switches: Feature Standard Performance Electrostatic Discharge (ESD) to MIL-STD-883C...

  • Page 37: Ruggedcom Sfp1131-1Fx20

    4.2 RUGGEDCOM SFP1131-1FX20 RUGGEDCOM SFP1131-1FX20 Siemens' RUGGEDCOM SFP1131-1FX20 industrial grade 100 Mbps fiber optic fast Ethernet SFP transceiver operates within a wide temperature range (-40 to 85 °C or -40 to 185 °F) and provides high performance Fast Ethernet communication up to 20 km (12.4 mi) using single-mode fiber.
  • Page 38 LM 4FG50 module installed, v2.10 or higher • For SINEC OS devices, v2.3 or higher Regulator compliance The RUGGEDCOM SFP1131-1FX20 complies with the following regulatory requirements when installed in Siemens RUGGEDCOM routers and/or switches: Feature Standard Performance Electrostatic Discharge (ESD) to MIL-STD-883C, Method 3015.4...

  • Page 39: Ruggedcom Sfp1131-1Fx50

    4.3 RUGGEDCOM SFP1131-1FX50 RUGGEDCOM SFP1131-1FX50 Siemens' RUGGEDCOM SFP1131-1FX50 industrial grade 100 Mbps fiber optic fast Ethernet SFP transceiver operates within a wide temperature range (-40 to 85 °C or -40 to 185 °F) and provides high performance Fast Ethernet communication up to 50 km (31.1 mi) using single-mode fiber.
  • Page 40 RUGGEDCOM RX5000PN LM 4FG50 module, v2.10 or higher • For SINEC OS devices, v2.3 or higher Regulator compliance The RUGGEDCOM SFP1131-1FX50 complies with the following regulatory requirements when installed in Siemens RUGGEDCOM routers and/or switches: Feature Standard Performance Electrostatic Discharge (ESD) to MIL-STD-883C, Method 3015.4...

  • Page 41: Ruggedcom Sfp1131-1Fx90

    4.4 RUGGEDCOM SFP1131-1FX90 RUGGEDCOM SFP1131-1FX90 Siemens' RUGGEDCOM SFP1131-1FX90 industrial grade 100 Mbps fiber optic fast Ethernet SFP transceiver operates within a wide temperature range (-40 to 85 °C or -40 to 185 °F) and provides high performance Fast Ethernet communication up to 90 km (55.9 mi) using single-mode fiber.
  • Page 42 Minimum firmware version requirements apply for some devices: • For SINEC OS devices, v2.3 or higher Regulator compliance The RUGGEDCOM SFP1131-1FX90 complies with the following regulatory requirements when installed in Siemens RUGGEDCOM routers and/or switches: Feature Standard Performance Laser Eye Safety...
  • Page 43 Fast Ethernet SFP transceivers 4.4 RUGGEDCOM SFP1131-1FX90 RUGGEDCOM SFP transceivers Reference Manual, 05/2024, C79000-G8976-1251-35...

  • Page 44: Bidirectional Gigabit Ethernet Sfp Transceivers

    Bidirectional Gigabit Ethernet SFP transceivers The following Bidrectional (BiDi) SFP transceivers are available from Siemens for select RUGGEDCOM routers and switches. To determine compatibility, refer to "Available SFP transceivers" (Page 2). RUGGEDCOM SFP transceivers Reference Manual, 05/2024, C79000-G8976-1251-35...

  • Page 45: Ruggedcom Sfp1132-1Bx10R

    5.1 RUGGEDCOM SFP1132-1BX10R RUGGEDCOM SFP1132-1BX10R Siemens' RUGGEDCOM SFP1132-1BX10R industrial grade 1 Gbps fiber optic bi- directional SFP transceiver operates within a wide temperature range (-40 to 85 °C or -40 to 185 °F) and provides high performance Gigabit Ethernet communication up to 10 km (6.2 mi) using single-mode fiber.
  • Page 46 Minimum firmware version requirements apply for some devices: • For SINEC OS devices, v2.3 or higher Regulator compliance The RUGGEDCOM SFP1132-1BX10R meets the following standards when installed in Siemens RUGGEDCOM routers and/or switches: Feature Standard Performance Electrostatic Discharge (ESD) to MIL-STD-883E, Method 3015.7...

  • Page 47: Ruggedcom Sfp1132-1Bx10T

    5.2 RUGGEDCOM SFP1132-1BX10T RUGGEDCOM SFP1132-1BX10T Siemens' RUGGEDCOM SFP1132-1BX10T industrial grade 1 Gbps fiber optic bi- directional SFP transceiver operates within a wide temperature range (-40 to 85 °C or -40 to 185 °F) and provides high performance Gigabit Ethernet communication up to 10 km (6.2 mi) using single-mode fiber.
  • Page 48 Minimum firmware version requirements apply for some devices: • For SINEC OS devices, v2.3 or higher Regulator compliance The RUGGEDCOM SFP1132-1BX10T meets the following standards when installed in Siemens RUGGEDCOM routers and/or switches: Feature Standard Performance Electrostatic Discharge (ESD) to MIL-STD-883E, Method 3015.7...

  • Page 49: Ruggedcom Sfp1132-1Bx40R

    5.3 RUGGEDCOM SFP1132-1BX40R RUGGEDCOM SFP1132-1BX40R Siemens' RUGGEDCOM SFP1132-1BX40R industrial grade 1 Gbps fiber optic bi- directional SFP transceiver operates within a wide temperature range (-40 to 85 °C or -40 to 185 °F) and provides high performance Gigabit Ethernet communication up to 40 km (24.9 mi) using single-mode fiber.
  • Page 50 Minimum firmware version requirements apply for some devices: • For SINEC OS devices, v2.3 or higher Regulator compliance The RUGGEDCOM SFP1132-1BX40R meets the following standards when installed in Siemens RUGGEDCOM routers and/or switches: Feature Standard Performance Electrostatic Discharge (ESD) to MIL-STD-883E, Method 3015.7...

  • Page 51: Ruggedcom Sfp1132-1Bx40T

    5.4 RUGGEDCOM SFP1132-1BX40T RUGGEDCOM SFP1132-1BX40T Siemens' RUGGEDCOM SFP1132-1BX40T industrial grade 1 Gbps fiber optic bi- directional SFP transceiver operates within a wide temperature range (-40 to 85 °C or -40 to 185 °F) and provides high performance Gigabit Ethernet communication up to 40 km (24.9 mi) using single-mode fiber.
  • Page 52 Minimum firmware version requirements apply for some devices: • For SINEC OS devices, v2.3 or higher Regulator compliance The RUGGEDCOM SFP1132-1BX40T meets the following standards when installed in Siemens RUGGEDCOM routers and/or switches: Feature Standard Performance Electrostatic Discharge (ESD) to MIL-STD-883E, Method 3015.7...
  • Page 53 Bidirectional Gigabit Ethernet SFP transceivers 5.4 RUGGEDCOM SFP1132-1BX40T RUGGEDCOM SFP transceivers Reference Manual, 05/2024, C79000-G8976-1251-35...

  • Page 54: Gigabit Ethernet Sfp Transceivers

    Gigabit Ethernet SFP transceivers The following Gigabit Ethernet SFP transceivers are available from Siemens for select RUGGEDCOM routers and switches. To determine compatibility, refer to "Available SFP transceivers" (Page 2). RUGGEDCOM SFP transceivers Reference Manual, 05/2024, C79000-G8976-1251-35...

  • Page 55: Ruggedcom Sfp1122-1Sx

    6.1 RUGGEDCOM SFP1122-1SX RUGGEDCOM SFP1122-1SX Siemens' RUGGEDCOM SFP1122-1SX industrial grade 1 Gbps fiber optic SFP transceiver operates within a wide temperature range (-40 to 85 °C or -40 to 185 °F) and provides high performance Gigabit Ethernet communication up to either 0.5 km (0.3 mi) or 0.3 km (0.2 mi) using multi-mode fiber, depending on the cable type in...
  • Page 56 Minimum firmware version requirements apply for some devices: • For SINEC OS devices, v2.3 or higher Regulator compliance The RUGGEDCOM SFP1122-1SX meets the following standards when installed in Siemens RUGGEDCOM routers and/or switches: Feature Standard Performance Laser Eye Safety IEC/EN 60825...

  • Page 57: Ruggedcom Sfp1122-1Sx2

    6.2 RUGGEDCOM SFP1122-1SX2 RUGGEDCOM SFP1122-1SX2 Siemens' RUGGEDCOM SFP1122-1SX2 industrial grade 1 Gbps fiber optic SFP transceiver operates within a wide temperature range (-40 to 85 °C or -40 to 185 °F) and provides high performance Gigabit Ethernet communication up to 2 km (1.2 mi) using multi-mode fiber.
  • Page 58 Minimum firmware version requirements apply for some devices: • For SINEC OS devices, v2.3 or higher Regulator compliance The RUGGEDCOM SFP1122-1SX2 meets the following standards when installed in Siemens RUGGEDCOM routers and/or switches: Feature Standard Performance Laser Eye Safety IEC/EN 60825...

  • Page 59: Ruggedcom Sfp1132-1Lx10

    6.3 RUGGEDCOM SFP1132-1LX10 RUGGEDCOM SFP1132-1LX10 Siemens' RUGGEDCOM SFP1132-1LX10 industrial grade 1 Gbps fiber optic long haul SFP transceiver operates within a wide temperature range (-40 to 85 °C or -40 to 185 °F) and provides high performance Gigabit Ethernet communication up to 10 km (6.2 mi) using single-mode fiber.
  • Page 60 Minimum firmware version requirements apply for some devices: • For SINEC OS devices, v2.3 or higher Regulator compliance The RUGGEDCOM SFP1132-1LX10 meets the following standards when installed in Siemens RUGGEDCOM routers and/or switches: Feature Standard Performance Electrostatic Discharge (ESD) to MIL-STD-883C, Method 3015.4...

  • Page 61: Ruggedcom Sfp1132-1Lx25

    6.4 RUGGEDCOM SFP1132-1LX25 RUGGEDCOM SFP1132-1LX25 Siemens' RUGGEDCOM SFP1132-1LX25 industrial grade 1 Gbps fiber optic long haul SFP transceiver operates within a wide temperature range (-40 to 85 °C or -40 to 185 °F) and provides high performance Gigabit Ethernet communication up to 25 km (15.5 mi) using single-mode fiber.
  • Page 62 Minimum firmware version requirements apply for some devices: • For SINEC OS devices, v2.3 or higher Regulator compliance The RUGGEDCOM SFP1132-1LX25 meets the following standards when installed in Siemens RUGGEDCOM routers and/or switches: Feature Standard Performance Electromagnetic Interference FCC Class B...

  • Page 63: Ruggedcom Sfp1132-1Lx40

    6.5 RUGGEDCOM SFP1132-1LX40 RUGGEDCOM SFP1132-1LX40 Siemens' RUGGEDCOM SFP1132-1LX40 industrial grade 1 Gbps fiber optic long haul SFP transceiver operates within a wide temperature range (-40 to 85 °C or -40 to 185 °F) and provides high performance Gigabit Ethernet communication up to 40 km (24.9 mi) using single-mode fiber.
  • Page 64 Minimum firmware version requirements apply for some devices: • For SINEC OS devices, v2.3 or higher Regulator compliance The RUGGEDCOM SFP1132-1LX40 meets the following standards when installed in Siemens RUGGEDCOM routers and/or switches: Feature Standard Performance Electromagnetic Interference FCC Class B...

  • Page 65: Ruggedcom Sfp1132-1Lx70

    6.6 RUGGEDCOM SFP1132-1LX70 RUGGEDCOM SFP1132-1LX70 Siemens' RUGGEDCOM SFP1132-1LX70 industrial grade 1 Gbps fiber optic long haul SFP transceiver operates within a wide temperature range (-40 to 85 °C or -40 to 185 °F) and provides high performance Gigabit Ethernet communication up to 70 km (43.5 mi) using single-mode fiber.
  • Page 66 Minimum firmware version requirements apply for some devices: • For SINEC OS devices, v2.3 or higher Regulator compliance The RUGGEDCOM SFP1132-1LX70 meets the following standards when installed in Siemens RUGGEDCOM routers and/or switches: Feature Standard Performance Electromagnetic Interference FCC Class B...

  • Page 67: Ruggedcom Sfp1132-1Lx100

    6.7 RUGGEDCOM SFP1132-1LX100 RUGGEDCOM SFP1132-1LX100 Siemens' RUGGEDCOM SFP1132-1LX100 industrial grade 1 Gbps fiber optic long haul SFP transceiver operates within a wide temperature range (0 to 70 °C or 32 to 158 °F) and provides high performance Gigabit Ethernet communication up to 100 km (62.1 mi) using single-mode fiber.
  • Page 68 Minimum firmware version requirements apply for some devices: • For SINEC OS devices, v2.3 or higher Regulator compliance The RUGGEDCOM SFP1132-1LX100 meets the following standards when installed in Siemens RUGGEDCOM routers and/or switches: Feature Standard Performance Electromagnetic Interference FCC Class B...

  • Page 69: Ruggedcom Sfp1132-1Lx115

    6.8 RUGGEDCOM SFP1132-1LX115 RUGGEDCOM SFP1132-1LX115 Siemens' RUGGEDCOM SFP1132-1LX115 industrial grade 1 Gbps fiber optic long haul SFP transceiver operates within a wide temperature range (-10 to 70 °C or 14 to 158 °F) and provides high performance Gigabit Ethernet communication up to 115 km (71.5 mi) using single-mode fiber.
  • Page 70 Minimum firmware version requirements apply for some devices: • For SINEC OS devices, v2.3 or higher Regulator compliance The RUGGEDCOM SFP1132-1LX115 meets the following standards when installed in Siemens RUGGEDCOM routers and/or switches: Feature Standard Performance Laser Eye Safety IEC/EN 60825...
  • Page 71 Gigabit Ethernet SFP transceivers 6.8 RUGGEDCOM SFP1132-1LX115 RUGGEDCOM SFP transceivers Reference Manual, 05/2024, C79000-G8976-1251-35...

  • Page 72: 10-Gigabit Ethernet Sfp+ Transceivers

    10-Gigabit Ethernet SFP+ transceivers The following 10-Gigabit Ethernet SFP+ transceivers are available from Siemens for select RUGGEDCOM routers and switches. To determine compatibility, refer to "Available SFP transceivers" (Page 2). RUGGEDCOM SFP transceivers Reference Manual, 05/2024, C79000-G8976-1251-35...

  • Page 73: Ruggedcom Sfp2123-1Sr

    7.1 RUGGEDCOM SFP2123-1SR RUGGEDCOM SFP2123-1SR Siemens' RUGGEDCOM SFP2123-1SR industrial grade 10 Gbps fiber optic long reach SFP+ transceiver operates within a wide temperature range (-40 to 85 °C or -40 to 185 °F) and provides high performance Gigabit Ethernet communication up to 400 m (1312 ft) using multi-mode fiber.
  • Page 74 Minimum firmware version requirements apply for some devices: • For SINEC OS devices, v2.3 or higher Regulator compliance The RUGGEDCOM SFP2123-1SR meets the following standards when installed in Siemens RUGGEDCOM routers and/or switches: Feature Standard Performance Electromagnetic Interference FCC Class B...

  • Page 75: Ruggedcom Sfp2133-1Lr10

    7.2 RUGGEDCOM SFP2133-1LR10 RUGGEDCOM SFP2133-1LR10 Siemens' RUGGEDCOM SFP2133-1LR10 industrial grade 10 Gbps fiber optic long reach SFP+ transceiver operates within a wide temperature range (-40 to 85 °C or -40 to 185 °F) and provides high performance Gigabit Ethernet communication up to 10 km (6.2 mi) using single-mode fiber.
  • Page 76 Minimum firmware version requirements apply for some devices: • For SINEC OS devices, v2.3 or higher Product-specific deviations The RUGGEDCOM SFP2133-1LR10 supports the following ratings when installed in the specified Siemens RUGGEDCOM routers and/or switches: Product(s) Specification Rating RUGGEDCOM RX5000 Operating Temperature -40 to 80 °C (-40 to 176 °F)

  • Page 77: Ruggedcom Sfp2133-1Er40

    7.3 RUGGEDCOM SFP2133-1ER40 RUGGEDCOM SFP2133-1ER40 Siemens' RUGGEDCOM SFP2133-1ER40 industrial grade 10 Gbps fiber optic extended reach SFP+ transceiver operates within a wide temperature range (-40 to 85 °C or -40 to 185 °F) and provides high performance Gigabit Ethernet communication up to 40 km (24.9 mi) using single-mode fiber.
  • Page 78 Minimum firmware version requirements apply for some devices: • For SINEC OS devices, v2.3 or higher Regulator compliance The RUGGEDCOM SFP2133-1ER40 meets the following standards when installed in Siemens RUGGEDCOM routers and/or switches: Feature Standard Performance RoHS EU RoHS Directive 2002/95/EC...

  • Page 79: Ruggedcom Sfp2133-1Zr80

    7.4 RUGGEDCOM SFP2133-1ZR80 RUGGEDCOM SFP2133-1ZR80 Siemens' RUGGEDCOM SFP2133-1ZR80 industrial grade 10 Gbps fiber optic extended reach SFP+ transceiver operates within a wide temperature range (-40 to 85 °C or -40 to 185 °F) and provides high performance Gigabit Ethernet communication up to 80 km (49.7 mi) using single-mode fiber.
  • Page 80 Minimum firmware version requirements apply for some devices: • For SINEC OS devices, v2.3 or higher Regulator compliance The RUGGEDCOM SFP2133-1ZR80 meets the following standards when installed in Siemens RUGGEDCOM routers and/or switches: Feature Standard Performance RoHS EU RoHS Directive 2002/95/EC...
  • Page 81 10-Gigabit Ethernet SFP+ transceivers 7.4 RUGGEDCOM SFP2133-1ZR80 RUGGEDCOM SFP transceivers Reference Manual, 05/2024, C79000-G8976-1251-35...

  • Page 82: Installation/Removal

    SFP ports. CAUTION Electrical hazard – risk of damage to equipment. Use only components certified by Siemens with RUGGEDCOM products. Damage to the router/switch may occur if compatibility and reliability have not been properly assessed.

  • Page 83: Required Tools

    Installation/removal 8.2 Required tools CAUTION Mechanical hazard – risk of damage to equipment. Do not install/remove SFP transceivers more than necessary. Repeated installation/ removal can reduce the life of the transceiver. NOTICE Only permit trained and qualified personnel to install and remove SFP transceivers. Required tools The following tools are required for installing/removing SFP transceivers: •...
  • Page 84 Installation/removal 8.3 Installation CAUTION Mechanical hazard – risk of component damage SFP transceivers are designed to insert in only one orientation. Do not force the SFP transceiver into the socket. Remove the dust plug from the socket and store for future use. Insert the SFP transceiver into the socket, and then swing the bail-latch on the SFP transceiver up and push it in to lock the transceiver in place.

  • Page 85: Removal

    Installation/removal 8.4 Removal Removal To remove an SFP transceiver, do the following: WARNING Explosion hazard – risk of serious personal injury and/or equipment damage. Do not install or remove SFP transceivers when an explosive atmosphere is present. Make sure all potential electrostatic build-up has been properly discharged to prevent an electrostatic discharge (ESD).
  • Page 86 For more information Siemens RUGGEDCOM https://www.siemens.com/ruggedcom Industry Online Support (service and support) https://support.industry.siemens.com Industry Mall https://mall.industry.siemens.com Siemens Canada Ltd. Digital Industries Process Automation 300 Applewood Crescent Concord, Ontario, L4K 4E5 Canada © 2024 Siemens Canada Ltd. Subject to change...
