Bullard H3000 User Instructions

USER INSTRUCTIONS
Thank you for choosing a Bullard fire helmet. Fire helmets are a part of personal
protective equipment and help to protect you from head injuries. Read all
instructions and warnings before adjusting and using your helmet.
WARNING
FAILURE TO FOLLOW THESE INSTRUCTIONS CAN RESULT IN
SERIOUS OR EVEN FATAL INJURY.
HEAD SIZES AND WEIGHT
The H3000 covers all head sizes from 52–62 cm.
The total weight of the helmet without attachments is approximately 1,165
grams.
ADJUSTING FOR HEAD SIZE WITH THE
SURE-LOCK RATCHET.
®
Turn the ratchet on the back of the headband fully counterclockwise (Fig. 1).
Put the fire helmet on and turn the ratchet clockwise until the fire helmet fits
comfortably but tightly.
VERTICALLY ADJUSTING THE FIRE HELMET
There are four catches on the headband adapters for connecting to four black
fastening pins on the inner lining (Fig. 2). To adjust the headband higher or
lower, simply press the catches firmly onto the black pins according to the
desired setting. The fire helmet gives you even more vertical adjustment options
by letting you change the position of the headband adapters.
Vertical adjustment of the fire helmet (Fig.3).
VISOR MOUNTING, PROTECTIVE PERFORMANCE,
REPLACEMENT
The visor has an adjusting screw on each of the right and left sides, which can
be used to lock the visor in place. The visor assembly itself screws into the
adapter and is released by pressing on the two locking tabs. The visor serves
as face protection with limitations in the case of extreme temperatures and flying
particles. It is recommended to remove the visor during an inside attack.
The performance of the visor has been tested in the temperature range from
-40° to +60°C. Components not marked "BT" should not be used under extreme
temperatures.
Visors with blistering, cracks, melting, severe scratches, or deformation must be
replaced.
VISOR MARKINGS
Markings Explanation of markings
EN14458:2018 European standard followed for the markings
Bullard Manufacturer
A/B 10cm Visor type and size
R315 Example item No.
10 Example year of manufacture
Optional features and labeling
.-40°C Suitable down to -40°C
Contact with liquid chemicals
The visor and associated adapters have been tested for resistance to the
following chemicals
Chemical Concentration
Sulfuric acid 30%
Sodium hydroxide 10%
p-xylen Undiluted
Butan-1-oL Undiluted
n-Heptan Undiluted
ONLY COMPLETELY CLEAN AND DRY FIRE HELMETS MAY BE
WORN. FAILURE TO FOLLOW THIS INSTRUCTION CAN RESULT IN
SERIOUS OR EVEN FATAL INJURY.
CHIN STRAP
First, adjust the neck strap by the buckle so that the chin strap comes to rest as
far forward as possible under the chin.
You adjust the length of the chin strap using the two buckles on the right and left
of the chin strap.
The chin strap opens and closes by the buckle.
The chin strap meets the requirements of the standard for the restraint system if
the chin strap supplied by the manufacturer is worn and adjusted in accordance
with these regulations.
REPLACING PARTS
For replacing parts or cleaning, the helmet can be disassembled quickly and
easily. To do so, unscrew the four Allen screws on the chin strap mount. A
matching Allen key is included with each helmet.
RATCHET
www.bullard.com
User Instructions for
H3000 Fire Helmets
WARNING
HEADBAND
ADAPTOR
Fig. 1 Fig. 2
FASTENING PINS
NECK STRAP
ADJUSTMENT
Fig. 4
CHIN STRAP ADJUSTMENT
SNAP FITTINGS FOR
VERTICAL ADJUSTMENT
Fig 3
Fig. 5 Fig. 6
BUCKLE
