Marshall Electronics MXL 770 Instruction Manual

Technical Specifications
Type: .......................................................Condenser microphone
Capsule: ................................................................ 22mm gold-sputtered
Frequency Response: ...................................................... 20 Hz – 20 kHz
Polar Pattern: ......................................................................................Cardioid
Sensitivity: ......................................................................................................... xxx
Impedance: .......................................................................................150 ohms
Attenuation Switch: ...................................................................0dB, -10dB
High Pass Filter: .....................................................6dB/octave @ 150Hz
Equivalent Noise Level: ............. 20 dB (A-weighted IEC 268-4)
Max SPL for .5% THD: ............................................................................137 dB
S/N Ratio: .................................................74 dB (Ref. 1 Pa A-weighted)
Power requirements: ....................................... 48V phantom power
Size & Weight: 59mm x 158mm / 2.32 in. x 6.22 in. 453.59g / 1lb
Metal Finish: ............................................................ Black with black grill
Polar Pattern
A Division of Marshall Electronics
310-333-0606 800-800-6608

www.mxlmics.com
Frequency Chart
Fax: 310-333-0688

sales@mxlmics.com

770
Pressure-Gradient
Condenser Microphone
