Summary of Contents for HYPERLITE MARS Series
- Page 1 USER MANUAL L E D F L O O D L I G H T MARS series www.hi-hyperlite.com service@hi-hyperlite.com +1(855) 688 7879...
-
Page 2: Features And Specifications
FEATURES & SPECIFICATIONS The MARS series LED floodlight is designd to provide a cost-effective, energy-effificient solution for illuminating building facades, sign lighting, wall washing building exteriors, landscape lighting. MARS luminaires deliver a uniform, wide flood distribution. Model CES-LS-VN-30W CES-LS-VN-50W CES-LS-VN-70W... - Page 3 DIMENSIONS 1/2" Knuckle Mount Trunnion Mount U-bracket Mount 45mm 45mm 45mm 189mm [1.8"] 172mm 172mm [1.7"] [1.7"] [7.4"] [6.7"] [6.7"] 108mm 108mm 146mm [4.2"] [4.2"] [5.6"] 208mm [8.1"] 87mm [3.4"] CES-LS-VN-30W 45mm 45mm 229mm 45mm 212mm 212mm [1.7"] [1.7"] [9.0"] [1.8"] [8.3"] [8.3"]...
- Page 4 DIMENSIONS Knuckle Mount Trunnion Mount U-bracket Mount 71mm 71mm 307mm [2 . 8"] 71mm 307mm 307mm [2 . 8"] [12 . 1"] [2 . 8"] [12 . 1"] [12 . 1"] 211mm 211mm 211mm [8 . 3"] [8 . 3"] [8 .
-
Page 5: Installation Instructions
- Ensure that the product around the vent, the lamp cannot violate any fire prevention regulations when using. Carefully read these instructions before installing product and keep it for future reference. If you do not understand these instructions, before starting any work, contact service@hi-hyperlite.com or (855) 688-7879. - Page 6 INSTALLATION INSTRUCTIONS 1/2 Knuckle Mount (Only available on 30w, 50w, 70w, 100w light) 1. Open junction box and run wiring into box. 2. Thread light body onto junction box using the 1/2-14 threads on knuckle 3. Connect wiring. 4. Adjust light head to desired angle and tighten Hexagon screw. Black Wire - Line Voltage Green Wire - Ground White Wire - Neutral...
- Page 7 INSTALLATION INSTRUCTIONS Trunnion Mount 1. Loosen light head adjustment screws with hex key. 2. Securely attach light to wall and connect wiring. 3. Connect wiring. 4. Rotate light head to desired angle and tighten adjustment screws. Wall Black Wire - Line Voltage Green Wire - Ground White Wire - Neutral LIGHT MUST BE GROUNDED...
- Page 8 INSTALLATION INSTRUCTIONS U-bracket Mount 1. Loosen light head adjustment screws with hex key. 2. Securely attach light to wall and connect wiring. 3. Adjust light head to desired angle and tighten Hexagon screw. Roof/Wall Black Wire - Line Voltage Green Wire - Ground White Wire - Neutral LIGHT MUST BE GROUNDED Hex-key...
- Page 9 INSTALLATION INSTRUCTIONS Slipfitter Mount (Only available on 100w, 150w, 200W and 250W light) 1.Attach the slipfitter mounting kit onto the light head. 2.Rotate light head to desired angle and tighten adjustment screw. 3.Connect wiring. 4.Securely attach light to pole/post.The maximum pole/post diameter is 2.36 in. Black Wire - Line Voltage Green Wire - Ground White Wire - Neutral...
- Page 10 MORE PRODUCTS... LED High Bay Light Hero Black Series Hero White Series Tale Series Will Series LED Flood Light Eyes Series Guarder Series Max Series LED Grow Light Area Light & Canopy Garage Light Ares Series Vega Series Groplanner O Series LED Wall Pack Light LED Vapor Tight Light Wall.
- Page 11 Use hyperlite LED flood light, enjoy brighter life now If you need more information about our lights, please email us or call us Email: service@hi-hyperlite.com Toll-free number: +1(855) 688 7879...
