Summary of Contents for Startone MKR 62

Page 1 MKR 62 Roll-Up Keyboard...
Page 2 Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 Internet: www.thomann.de 19.12.2023, ID: 546944 (V2)
Page 3: Table Of Contents
General information..........................5 1.1 Symbols and signal words....................... 5 Safety instructions............................. 7 Features............................... 10 Installation..............................11 Connections and operating elements................... 12 Demo tracks............................... 18 Sound list..............................19 Style list................................ 24 Technical specifications........................29 Protecting the environment......................32 MKR 62 Roll-Up Keyboard...
Page 4 MKR 62 Roll-Up Keyboard...
Page 5: General Information
Please refer to the latest version of the documentation, which is ready for download under www.thomann.de. 1.1 Symbols and signal words In this section you will find an overview of the meaning of symbols and signal words that are used in this document. MKR 62 Roll-Up Keyboard...
Page 6 This combination of symbol and signal word indicates a pos‐ sible dangerous situation that can result in material and environmental damage if it is not avoided. Warning signs Type of danger Warning – dangers due to batteries. Warning – danger zone. MKR 62 Roll-Up Keyboard...
Page 7: Safety Instructions
Always dispose of packaging material properly when it is not in use. Never allow children to use the device without supervi‐ sion. Keep small parts away from children and make sure that the device does not shed any small parts (such knobs) that children could play with. MKR 62 Roll-Up Keyboard...
Page 8 Never subject the device to liquids or moisture. Never move the device to another location while it is in operation. In environments with increased dirt levels (for example due to dust, smoke, nicotine or mist): Have the device cleaned by qualified specialists at reg‐ ular intervals to prevent damage due to overheating and other malfunctions. MKR 62 Roll-Up Keyboard...
Page 9 Recharge the lithium-ion batteries about every three months if they are stored for a longer period of time to avoid permanent damage due to too deep self-discharge. Fully charge the lithium-ion batteries only shortly before use at room temperature. MKR 62 Roll-Up Keyboard...
Page 10: Features
Single-finger and multi-finger automatic Sustain Vibrato Digital display Built-in speakers Automatic shutdown function Incl. USB charging cable, power adapter optionally available (item no. 278119) Connections: headphones output, USB charging connection / MIDI output, microphone input, sustain pedal input MKR 62 Roll-Up Keyboard...
Page 11: Installation
Do not kink the silicone keyboard. The device automatically switches to standby mode if no keys are pressed for about 15 minutes. To return to normal operating mode, press any key on the keyboard or any button on the control panel. MKR 62 Roll-Up Keyboard...
Page 12: Connections And Operating Elements
Connections and operating elements Connections and operating elements Control panel ö & < MKR 62 Roll-Up Keyboard...
Page 13 Press [Single] (display shows ‘CH1’ ) to activate the single-finger mode. Press Then the keyboard automatically plays a suitable chord accompaniment when playing individual notes in the left area of the keyboard. Press [Single] again to deactivate the single-finger mode. MKR 62 Roll-Up Keyboard...
Page 14 Press [Tone-] to activate the selection. The display shows ‘000’ . Press [Tone-] again to select between the preprogrammed sounds ‘000’ … ‘127’ . Alternatively, use the number buttons to select the desired sound. 15 Number buttons | buttons to enter sounds directly. MKR 62 Roll-Up Keyboard...
Page 15 21 [Sustain] | button to activate / deactivate the Sustain effect. 22 [Vibrato] | button to activate / deactivate the Vibrato effect. | button to increase the playback speed of styles and demo pieces. MKR 62 Roll-Up Keyboard...
Page 16 25 Battery charging indicator | this LED lights green during charging. Once the installed battery pack is fully charged, the LED turns off. 26 Power indicator | this LED lights constantly red during operation. | main switch to turn the device on and off. MKR 62 Roll-Up Keyboard...
Page 17 31 [MICROPHONE] | input for an optional microphone, 3.5 mm jack socket 32 [USB 5V | MIDI OUT] | connection for the supplied USB cable to charge the installed battery pack via the USB port of a computer and for transferring MIDI data. MKR 62 Roll-Up Keyboard...
Page 18: Demo Tracks
Name By Alice Les premiers sourires de Vanessa Croatian Rhapsody Snowdreams A comme amour Bandari Green Sleeves Castle in the Sky Dream Wedding Song of Joy Romance De Amor Edelweiss Dancing Girl Dance of fireflie CrystlLake MKR 62 Roll-Up Keyboard...
Page 19: Sound List
Xylophone Piano 2 Tubular Bells Piano 3 Santur Honky-Tonk Piano Organ Rhodes Piano Hammond Organ Chorused Piano Percussive Organ Harpsichord Rock Organ Clavinet Church Organ Percussion Reed Organ Celesta Accordion Glockenspiel Harmonica Music box Bandoneon Vibraphone MKR 62 Roll-Up Keyboard...
Page 20 Tremolo Strings Guitar Harmonics Pizzicato Strings Bass Orchestral Harp Acoustic Bass Timpani Chorus Electric Bass (finger) Electric Bass (pick) String Ensemble 1 Fretless Bass String Ensemble 2 Slap Bass 1 SynthStrings 1 Slap Bass 2 SynthStrings 2 MKR 62 Roll-Up Keyboard...
Page 21 Brass instrument Bassoon Trumpet Clarinet Wild instrument Trombone Tube Piccolo Muted Trumpet Flute French Horn Recorder Brass Section Pan Flute Synth Brass 1 Bottle Blow Synth Brass 2 Skakuhachi Reed instrument Whistle Soprano Sax Ocarina Alto Sax MKR 62 Roll-Up Keyboard...
Page 22 FX 6 (goblins) Synthetic soft tone FX 7 (echoes) Pad 1 (new age) FX 8 (sci-fi) Tribal instrument Pad 2 (warm) Pad 3 (polysynth) Sitar Pad 4 (choir) Banjo Pad 5 (bowed) Shamisen Pad 6 (metallic) Koto MKR 62 Roll-Up Keyboard...
Page 23 Name Alimba Synth Drum Bagpipe Reverse Cymbal Sound effects Fiddle Shanai Guitar Fret Noise Percussion Breath Noise Tinkle Bell Seashore Agogo Bird Tweet Steel Drums Telephone Ring Woodblock Helicopter Taiko Drum Applause Melodic Tom Gun shot MKR 62 Roll-Up Keyboard...
Page 24: Style List
Beguine_3 Reggae Waltz Pop hit Rumba Waltz March_1 Pop Malay March_2 Bossa nova Rumba_1 Disco_1 Rumba_2 Disco_2 Slow_1 Blue grass disco Slow_2 Waltzl_1 Disco cha cha Waltzl_2 Guala cha True ballad waltz Char Bossa Waltz Samba_1 MKR 62 Roll-Up Keyboard...
Page 25 Rock & Roll 16Bit_2 Urban Rock Ballad_16T Ballad Country_16T Jazz Ballad Tango_1 C.Ballad Tango_2 J.Ballad Polka_1 60s Slow Ballad Polka_2 Piano Ballad Pop Swing 50s Ballad Easy Swing Snake Base Soft Swing Happy Blues Rock_1 Old Blues MKR 62 Roll-Up Keyboard...
Page 26 Tecno_2 Boodie_3 Funky_1 Shuffle_1 Funky_2 Shuffle_2 Dixie_1 Dream Shuffle Dixie_2 Country Shuffle Foxtrot_1 Quick Shuffle Foxtrot_2 Reggae Shuffle R.roll_1 R&B R.roll_2 Reggae_1 Fast Beat Reggae_2 Quick Beat Reggae_3 Smooth Beat Salsa_1 Square Beat Salsa_2 Euro Beat MKR 62 Roll-Up Keyboard...
Page 27 Absolute Music Dream Dance Jamaica Dance_1 Synthesis Dance_2 Feel Dance_3 Accelerate Beach Night The Country Irish Country Shuffle Tarantella Electric Keys Big band Dark Keys Easy Walk Fusion Destiny Horse Comedy Canon Drive Latin Liquid Nova Mambo MKR 62 Roll-Up Keyboard...
Page 28 Style list Name Name New age Soul Slow rc Twist MKR 62 Roll-Up Keyboard...
Page 29: Technical Specifications
Roll-up silicone keyboard with 61 keys Polyphony 32-voice polyphonic Sounds Styles Demo and practice tracks Gain +99.3 dB max. Speaker 0.5 W, 8 Ω Power supply External power adapter, 100 - 240 V 50/60 Hz Power adapter Secondary current 1000 mA MKR 62 Roll-Up Keyboard...
Page 30 105 mm × 30 mm × 229 mm Dimensions of keyboard (W × H × D) 895 mm × 8 mm × 166 mm Weight 986 g Ambient conditions Temperature range 0 °C…40 °C Relative humidity 20%…80% (non-condensing) MKR 62 Roll-Up Keyboard...
Page 31 Technical specifications Further information Keys Illuminated keys Touch velocity Aftertouch Storage medium Lyrics function Score function Vocal harmony USB audio recorder MIDI interface via USB Microphone connection MKR 62 Roll-Up Keyboard...
Page 32: Protecting The Environment
Dispose the built-in lithium batteries together with the device. Check for an appropriate collection facility. Dispose of the batteries and rechargeable batteries at relevant collection points or through your local waste facility. MKR 62 Roll-Up Keyboard...
Page 33 Repairing a device or passing it on to another user is an ecologically valuable alternative to disposal. You can return your old device to Thomann GmbH at no charge. Check the current conditions on www.thomann.de. If your old device contains personal data, delete those data before disposing of it. MKR 62 Roll-Up Keyboard...
Page 34 Notes MKR 62 Roll-Up Keyboard...
Page 36 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
