Summary of Contents for Cerio DR-3000
- Page 1 CERIO Corporation DR-3000 CenOS5.0 Access Controller with VPN Gateway (60 / 128 APs) Quick Start Guide V1.0a V1.0...
-
Page 2: Table Of Contents
Product Outward Appearance ....................... 3 Panel Function Description......................3 Software Configuration ........................5 Login DR-3000 Web Page ....................... 9 Other Applications .......................... 10 V1.0a V1.0... -
Page 3: Product Outward Appearance
1. Product Outward Appearance Product Side Product Front Product back 2. Panel Function Description Product Front V1.0a V1.0... - Page 4 1. LED for Power / Status and Storage *“STORAGE” LED will have two behaviors for backup and recovery. Power Status Storage 2. USB drive connection port. (only support FAT format) 3. “EJECT” is for configuration backup and recovery. EJECT Button # Operating Instructions After press and hold EJECT button for about 6 seconds release button, the "Storage"...
-
Page 5: Software Configuration
Software Configuration IP Segment Set-up for Administrator's PC/NB Set the IP segment of the administrator's computer to be in the same range as DR-3000 for accessing the system. Do not duplicate the IP Address used here with IP Address of DR-3000 or any other device within the network. - Page 6 Step 3 : In “Change adapter setting” Page. Please find Local LAN and Click the right button on the mouse and Click “Properties” V1.0a V1.0...
- Page 7 Step 4 : In “Properties” page, please Click “Properties” button to TCP/IP setting Step 5 : In Properties page to setting IP address, please find “Internet Protocol Version 4 (TCP/IPv4)” and double click or click “Install” button. Double click Or click Install button V1.0a V1.0...
- Page 8 Step 6 : Select “Use the following IP address”, and fix in IP address: 192.168.2.# ex. The # is any number by 1 to 253 Subnet mask : 255.255.255.0 And Click "OK" to complete the fixed computer IP setting Please Open Web Browser Without a valid certificate, users may encounter the following problem in IE7 when they try to access system's WMI (https://192.168.2.1).
-
Page 9: Login Dr-3000 Web Page
Password default The system manager Login Page then appears. Enter “root” as User name and “default” as Password, and then click “Log in” to login to the system. Please base your Software version check to DR-3000 User’s Manual V1.0a V1.0... -
Page 10: Other Applications
5. Other Applications Cerio's DR-3000 built-in AAA RADIUS Server with Cerio's POS system and CenOS5.0 AP authentication can be combination hotspot architecture. Cerio's POS system has 2 types, respectively SP-800-PRINTER and SP-800-QRCPRT. As follow Cerio's DR-3000 mounted POS system application diagram.
