Summary of Contents for Nexigo AS400
- Page 1 Lifting Slide-Out Tray for Ultra-Short Throw Projectors User Manual AS400 Scan the QR code or visit our link to download the latest manual or watch the installation video. nexigo.com/manuals...
-
Page 2: Contact Information
Avoid setting up the tray in areas prone to vibration or other disturbances to ensure stable operation. PRODUCT INTRODUCTION The NexiGo Lifting Slide-Out Tray is an automated telescoping platform designed for use with ultra-short throw projectors. The device can be repositioned forward/backward and up/down with a remote control. -
Page 3: What's In The Box
WHAT'S IN THE BOX? Power Cable x 1 USB Cable x 1 Lifting Slide-Out Tray x 1 User Manual x 1 Bracket Plates x 2 Reusable Cable Ties x 3 Plastic Wall Anchors x 2 M3.5×40mm Screws x 2 M4×15mm Screws x 4 M5×6mm Screws x 4 L-Brackets x 4 Spare Foot Pads x 4... -
Page 4: Button Instructions
BUTTON INSTRUCTIONS Power Signal Power Button: Connect tray to a power source Signal Button: Connect tray to your projector Up Button: Control the tray up Down Button: Control the tray down Forward Backward Forward Button: Control the tray forward Down Backward Button: Control the tray backward SPECIFICATIONS... - Page 5 Rear View Side View 2. Align the Bracket Plates with the holes on the bottom of the tray. Place the long end of each Bracket Plate on the bottom of the tray, with the short end of the Bracket Plate pointing outward, as shown below.
- Page 6 3. To fasten the Bracket Plates to the tray, insert an M5×6mm Screw into each of the four holes and tighten until snug. 4. Place the Lifting Slide-Out Tray on the surface where you intend to keep it. Fix the bracket to the back of your table or credenza using the M4×15mm Self-Tapping Screws P o w e r S ig n a l...
- Page 7 HOW TO SET UP THE LIFTING SLIDE-OUT TRAY FOR USE WITH THE PROJECTOR? Setting a Position Preset 1. Peel off the adhesive backing from the four L-Brackets and a x them to prevent the projector from shifting. 2. Use the provided USB Cable to connect the Lifting Slide-Out Tray and the projector. Po we r Sig na l...
- Page 8 3. Plug in the Lifting Slide-Out Tray using the provided Power Cable, and then turn on your UST Projector. 4. Use the Up, Down, Forward and Backward Buttons on the side of the tray to adjust the Lifting Slide-Out Tray's position to the optimal distance based on your screen size and throw distance. To prevent accidental touches during tray saving, the buttons will automatically lock after 3 minutes of inactivity, preventing adjustments.
- Page 9 5. After 60 seconds, unplug the Power Cable to turn off the Lifting Slide-Out Tray. It will remember the distance settings. When the power is cut off, it is normal for the vertical direction of this tray to descend slowly. 6.
- Page 10 7. Restart the UST Projector. The Lifting Slide-Out Tray's Plate will automatically slide forward into the preset position. 8. You have now completed the Lifting Slide-Out Tray setup. It will extend when the projector is powered on and retract when it is turned off. If you encounter any issues, please follow the procedure outlined in steps 3 to 6.
-
