Rev-A-Shelf RV Series Installation Instructions

RV-SERIES DOUBLE 27 & 35 QT. WASTE CONTAINER PULLOUTS
TOOLS REQUIRED:
1
8
ESTIMATED ASSEMBLY TIME:
10-15 MIN
CARE AND MAINTENANCE:
Clean with a damp cloth and
wipe parts dry.
SCAN HERE FOR
INSTALLATION VIDEO
WWW.REV-A-SHELF.COM/VIDEOS
STEP 1
Remove the waste container
frame from plastic packaging.
STEP 2
Place the wire frame on a
flat surface and attach wire
uprights in the appropriate
holes in the frame
(See Figure A).
INSTALLATION INSTRUCTIONS: RV-SERIES DOUBLE 27 & 35 QT. WASTE CONTAINER PULLOUTS
Parts List
No. Description
A 27 or 35 Qt.Waste Containers
B Frame
C Braces
D Basket Wires
E Handle
F #8 x 3/4" Truss Head Screws
A.
or
35 Qt.
B.
FIG. A
Qty
2
1
2
2
1
4
27 Qt.
C.
D.
E.
F.
