Summary of Contents for Sonetonix AC-BLK-12-W
- Page 1 User Manual AC-BLK-12-W Sonetonix Wall Mount Distribution Block...
- Page 2 AC-BLK-12-W User Manua Preface Read this user manual carefully before using this product. Pictures shown in this manual is for reference only, different model and specifications are subject to real product. This manual is only for operation instruction only, not for any maintenance usage. The functions described in this version are updated till January 2016.
- Page 3 AC-BLK-12-W User Manua SAFETY PRECAUTIONS To insure the best from the product, please read all instructions carefully before using the device. Save this manual for further reference. Unpack the equipment carefully and save the original box and packing material for possible future shipment ...
-
Page 4: Table Of Contents
AC-BLK-12-W User Manua Contents 1. PRODUCT OVERVIEW...........................1 1.1 Key Features..........................1 1.2 Front panel...........................2 1.3 Loads............................2 1.4 S-NET............................2 2. TECHNICAL SPECIFICATIONS........................2 Electrical Specifications....................... 2 2.2 Power Requirements......................... 2 2.3 Connections..........................2 2.4 Controls and Indications......................2 2.5 Mechanical specifications......................3 2.5.1 Enclosure..........................3 2.5.2 Environmental........................3... -
Page 5: Product Overview
Separate power bus for each channel Detachable terminal blocks for easy termination Diagnostic LEDs for S-NET signal connection Complete solution for power distribution for all Sonetonix Lighting/ Dimming modules for a complete Automation Solution Wall Mountable Sonetonix... -
Page 6: Front Panel
11 connectors for connect the S-NET Devices with in loop. 1.4 S-NET The AC-BLK-12-D communicates with all Sonetonix products or third party units via S-NET. An Eleven of S-NET terminal blocks, allow for easy daisy-chaining of several DIN rail Series automation control modules. -
Page 7: Mechanical Specifications
AC-BLK-12-W User Manua 2.5 Mechanical specifications 2.5.1 Enclosure Wall Mount dark Gray metal sheet enclosure 2.5.2 Environmental Operating Temperature: 0° to 45°C 2.5.3 Dimensions and weight Parameter Value Unit Height 4.33 Inches Width 6.10 Inches Depth 0.787 Inches Weight Grams... -
Page 8: Application And Wiring Diagram
AC-BLK-12-W User Manua 3. Application and wiring diagram Sonetonix... -
Page 9: S-Net Communication
AC-BLK-12-W User Manua 4. S-NET Communication The BLK Modular can be connected in S-NET with other Automation modules using RS485 serial interface. The signal connection is shown in Fig 1. Wiring diagram 4.1Communication parameters Parameter Description Signal Level RS-485 compliant... - Page 10 AC-BLK-12-W User Manua Sonetonix...
-
Page 11: After-Sales Service
AC-BLK-12-W User Manua 6. After-sales Service If there appear some problems when running the device, please check and deal with the problems reference to this user manual. 1) Product Limited Warranty: We warrant that our products will be free from defects in materials and workmanship for three years, which starts from the first day the product leaves warehouse (check the SN mark on the product).
