Summary of Contents for KuWFi CPE400
-
Page 2: Table Of Contents
Contents 1. List of Packaging Accessories·····················02 2. Product Appearance and Interface···················03 3. Video Transmission Introduction····················04 4. Outdoor CPE Function························04 5. Outdoor CPE Specification······················05 6. Digital Display Setting·························06 7. WeBUI Manage Pages························07 8. Field Application···························11 — 1 —... -
Page 3: List Of Packaging Accessories
1. List of Packaging Accessories What is in the box 48V POE Adapter *2 Outdoor CPE *2 12V DC Cable *4 RJ45 Cable(1M) *2 Lashing Rope *4 User Manual *1 — 2 —... -
Page 4: Product Appearance And Interface
2. Product Appearance and Interface — 3 —... -
Page 5: Video Transmission Introduction
3. Video Transmission Introduction CPE is widely used in highways, reservoir river monitoring, elevator monitoring systems, site crane monitoring systems, port terminal monitoring systems, marine aquaculture monitoring systems and So on. CPE Video Bridge Transmission usually consists of two devices in AP and Station mode respectively. -
Page 6: Outdoor Cpe Specification
5. Outdoor CPE Specification DRAM: DDR2 64MByte FLASH: 16MByte Wired Interface: 10/100Mbps LAN*3 DC output: 12V out *2 Transfer method: Direct Sequence Spread Spectrum (DSSS) Modulation: OFDM/BPSK/QPSK/CCK/DQPSK/DBPSK Network Standard: IEEE802. 11n,IEEE802.11a Power scheme: POE 48V 0.5A ... -
Page 7: Digital Display Setting
6. Digital Display Setting The digital display bridge is simply connected by dialing. After setting Bridge 1 and Bridge 2 to AP and STA mode, set the two bridges to the same number (1,2,3, ... F) through the "shift" button, then the two bridges can be automatically connected without using a computer for IP setting (Signal light on=pairing succeeded). -
Page 8: Webui Manage Pages
7. WeBUI Manage Pages Connect the CPE by LAN port (Use RJ45 cable) How to Configure Your PC IP As 192.168.0.xxx: a. Find the network connection you are using and right click on Properties. b. Double- click the IPV4 setting, select the IP address below, enter the IP and confirm. - Page 9 Login WebUI CPE Default IP(192.168.0.20) User Name and Password: admin/admin CPE Advanced Settings Since the Bridge devices are mainly used for long-range signal bridge and repeating,and to avoid IP address confliction when the CPE is connected with another router device,our bridge products disable the DHCP function(automatic IP address assignment)by default How to pair manually STA: Means Slave AP...
- Page 10 Wireless Basic Configuration Here, Use the STA device to scan the SSID of AP device, which is also a method of manual pairing Pairing succeeded (If show “No information available”,means pairing failed) — 9 —...
- Page 11 Wireless Advanced Configuration Operating frequency（Mode/Channel/Width）/ Transmit Power/ Distance optimization Wireless Mode Switch High speed mode has high data transmission speed and is used for short distance high-speed transmission, but its stability is poor. It is recommended to use stable mode. Router Password:Changes the administrator password for accessing the device —...
-
Page 12: Field Application
8. Field Application — 11 —... - Page 13 — 12 —...
