FIRE PIT
ITM./ART.#: PAG-2170
MODEL#: F200031-A1
ANS Z21.97 CSA 2.41-2017
Outdoor Decorative Gas Appliances
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference
DANGER
FIRE OR EXPLOSION HAZARD
If you smell gas:
Shut off gas to the appliance.
Extinguish any open flame.
If odor continues, leave the area immediately.
After leaving the area, call your gas supplier or fire
department.
Failure to follow these instructions could result in
fire or explosion, which could cause property
damage, personal injury, or death.
DANGER
WARNING:
If the information in this manual is not followed exactly, a fire or explosion may result causing
property damage, personal injury, or loss of life.
CARBON MONOXIDE HAZARD
This appliance can produce carbon monoxide which has no odor.
Using it in an enclosed space can kill you.
Never use this appliance in an enclosed space such as a camper,
tent, car or home.
WARNING: For Outdoor Use Only.
Installation and service must be per-
formed by a qualified installer, service
agency, or the gas supplier.
WARNING
Do not store or use gasoline, or other
flammable vapors and liquids,in the
vicinity of this or any other appli-
ance.
An LP-cylinder not connected for use
shall not be stored in the vicinity of
this or any other appliance.
01
Advertisement
Table of Contents
Related Manuals for Direct Wicker F200031-A1
Summary of Contents for Direct Wicker F200031-A1
- Page 1 FIRE PIT ITM./ART.#: PAG-2170 MODEL#: F200031-A1 ANS Z21.97 CSA 2.41-2017 Outdoor Decorative Gas Appliances INSTALLER: Leave this manual with the appliance. WARNING: For Outdoor Use Only. CONSUMER: Retain this manual for future reference Installation and service must be per- formed by a qualified installer, service DANGER agency, or the gas supplier.
-
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION The installation must conform with local codes or, in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.1 NFPA 54; National Fuel Gas Code; Natural Gas and Propane Installation Code, CSA B149.1; or Propane Storage and Handling Code, CSA B149.2, as applicable. The appliance must be isolated from the gas supply piping system by closing its individual manual shutoff valve during any pressure testing of the gas supply piping system at test pressures equal to or less than 1/2 psi (3.5 kPa). -
Page 3: Specifications
IMPORTANT SAFETY INFORMATION ABOUT PROPANE (LP) GAS The LP-gas supply cylinder to be used must be constructed and marked in accordance with the U.S. Deparment of Transportation (D.O.T.) Specifications for LP-Gas Cylinders, or the Standard for Cylinders, Spheres and Tubes for Transportation of Dangerous Goods and Commission, CAN/CSA-B339, as applicable. -
Page 4: Package Contents
PACKAGE CONTENTS PART DESCRIPTION QUANTITY PART DESCRIPTION QUANTITY 1 pc Weather cover 1 pc Fire table 1 pc Lava rock (13.2 Ibs) 1 pack Door 1 pc... - Page 5 ASSEMBLY INSTRUCTIONS Carefully unpack all parts from the box and compare parts with the package content listed above, making sure all parts are present before beginning assembly of the product. If any part is missing or damaged, do not attempt to assemble the product. Contact customer service for replacement parts. Open the box of lava rocks, put the lava rocks (E) into the fire bowl of the fire table (B) (See Figure 2).
- Page 6 3. Open the door. Place the gas cylinder into the gas cylinder support and connect the regulator by turning the black handle clockwise to tighten. To remove the regulator, turn the black handle counter-clockwise. Secure the gas cylinder by tightening clockwise the retention point found on gas cylinder support, so that the gas cylinder cannot move from side to side or fall down.
- Page 7 5. Once the firepit has cooled completely after use, carefully place the lid (A) onto the fire bowl and use the weather cover (D) to protect your fire pit from the elements (See Figure 5). WARNING: Allow 30 minutes after use for fire pit to cool down before placing the lid to prevent scalding. Figure 5...
- Page 8 BATTERY Make sure the control knob is in the “OFF” position. Unscrew the push button cap on the ignitor module located on the control panel to access the battery compartment. The ignitor module requires one AAA size battery (See Figure 6). BATTERY IS NOT INCLUDED.
-
Page 9: Lighting Instructions
gas valve-hose connection (Figure 9) inlet tube-bellows connection (Figure 10) To perform a leak test: Make 2~3 oz. of leak solution by mixing one part liquid dishwashing detergent and three parts water. Noted: make sure control knob is “OFF”. Apply several drops of solution where the cylinder attaches to regulator (See Figure 7), inspect the solution at the connection looking for bubbles. -
Page 10: Care And Maintenance
Observe Flame Height When Lit: The burner will display blue and yellow flames. These flames should be a blue / yellow color between 1~2 in. height (See Figure 12). These flames should not be yellow or produce thick smoke. This would indicate an obstruction of airflow through the burners. -
Page 11: Replacement Parts List
REPLACEMENT PARTS LIST PART# DESCRIPTION Firepit round lid, 530mm x 9 L-530 Fire table F200031-A1-FT Weather cover F200031-A1-WC Firepit lava rock (red), 6.6 lbs x 2 EFP-LVRK-13.2 Firepit thermocouple, 450 mm/18" ET-T-450 Firepit pulse ignition CLTN-PLSELT Firepit regulator 180 degree hose 350 mm/14"... -
Page 12: Warranty
Also excluded: loss of use of time and or inconvenience, money, travel, packaging or any other consequential or incidental damages. In no event shall Direct Wicker, responsibili- ty exceed the value of the replacement product. Warranty is to the original purchaser when items are purchased from one of our authorized retailers and is not transferable.
