2007 Chevrolet Tahoe, Suburban Owner Manual

Seats and Restraint Systems ........................ 1

Front Seats

............................................... 9

Rear Seats

.............................................. 19

Safety Belts

............................................. 38

Child Restraints

Airbag System

......................................... 89

Restraint System Check

Features and Controls ............................... 111

Keys

...................................................... 111

Doors and Locks

Windows

................................................ 130

Theft-Deterrent Systems

Starting and Operating Your Vehicle

Mirrors

................................................... 157

OnStar

System

Universal Home Remote System

Storage Areas

....................................... 176

Sunroof

................................................. 183

....................................... 60

........................ 107

................................... 120

........................ 132

...... 136

.................................... 168

........... 171

Instrument Panel ........................................ 188

Instrument Panel Overview

Climate Controls

Warning Lights, Gages, and

Indicators

........................................... 224

Driver Information Center (DIC)

Audio System(s)

Driving Your Vehicle .................................. 336

Your Driving, the Road, and

Your Vehicle

...................................... 336

Towing

.................................................. 397

Service and Appearance Care ................... 424

Service

.................................................. 424

Fuel

....................................................... 426

Checking Things Under the Hood

Rear Axle

.............................................. 474

Four-Wheel Drive

Front Axle

............................................. 476

.................... 188

.................................... 211

............. 242

.................................... 271

.......... 434

.................................. 475

Table of Contents

Chapters

Table of Contents

Need help?

Do you have a question about the Chevrolet Tahoe 2007 and is the answer not in the manual?

Questions and answers

Summary of Contents for GM Chevrolet Tahoe 2007

Page 1 2007 Chevrolet Tahoe, Suburban Owner Manual Seats and Restraint Systems ......1 Instrument Panel ........188 Front Seats ..........9 Instrument Panel Overview ....188 Rear Seats ..........19 Climate Controls ........211 Safety Belts ..........38 Warning Lights, Gages, and Indicators Child Restraints ...........
Page 2 Maintenance Schedule ....... 550 Headlamp Aiming ........477 Maintenance Schedule Bulb Replacement ......... 480 ......550 Windshield Wiper Blade Replacement ..483 Customer Assistance Information ..... 572 Tires ............484 Customer Assistance and Information ..572 Appearance Care ........528 Reporting Safety Defects .......
Page 3 Helm, Incorporated P.O. Box 07130 Detroit, MI 48207 GENERAL MOTORS, GM, the GM Emblem, How to Use This Manual CHEVROLET, the CHEVROLET Emblem, and the names TAHOE, SUBURBAN, and Z71 Many people read the owner manual from are registered trademarks of General Motors beginning to end when they ﬁrst receive their new...
Page 4 Safety Warnings and Symbols In the caution area, we tell you what the hazard is. Then we tell you what to do to help avoid or There are a number of safety cautions in this reduce the hazard. Please read these cautions. book.
Page 5 Vehicle Damage Warnings Vehicle Symbols Also, in this manual you will ﬁnd these notices: The vehicle has components and labels that use symbols instead of text. Symbols are shown along Notice: These mean there is something with the text describing the operation or that could damage your vehicle.
Page 6 These are some examples of symbols that may be found on the vehicle:...
Page 7: Table Of Contents
Section 1 Seats and Restraint Systems Front Seats ............9 Shoulder Belt Height Adjustment ....50 Safety Belt Use During Pregnancy ....51 Manual Seats ..........9 Right Front Passenger Position ....51 Power Seats ..........10 Center Front Passenger Position ....52 Power Lumbar ..........11 Rear Seat Passengers .........53 Heated Seats ..........12 Rear Safety Belt Comfort Guides ....55 Memory Seat, Mirrors, and Pedals ....13...
Page 8 Section 1 Seats and Restraint Systems Airbag System ..........89 Servicing Your Airbag-Equipped Vehicle ..105 Adding Equipment to Your Where Are the Airbags? .......92 Airbag-Equipped Vehicle ......106 When Should an Airbag Inﬂate? ....95 What Makes an Airbag Inﬂate? ....97 Restraint System Check ......107 How Does an Airbag Restrain? ....98 Checking the Restraint Systems ....107 What Will You See After an...
Page 9: Front Seats
Front Seats Manual Seats CAUTION: You can lose control of the vehicle if you try to adjust a manual driver’s seat while the vehicle is moving. The sudden movement could startle and confuse you, or make you push a pedal when you do not want to.
Page 10: Power Seats
Power Seats If the vehicle has power seats, the controls used to operate them are located on the outboard side of the seats. To adjust the seat, do any of the following: • Move the seat forward or rearward by sliding the control forward or rearward.
Page 11: Power Lumbar
Power Lumbar • To raise the height of the lumbar support, press and hold the top of the control. • To lower the height of the lumbar support, press and hold the bottom of the control. Release the control when the lower seatback reaches the desired level of lumbar support.
Page 12: Heated Seats
Heated Seats (Heated Seat and Seatback): Press this button to turn on the heated seat and seatback. If the seats have the The light on the button will come on to indicate that heated seat feature, the feature is working. Press the button to cycle the buttons used through the temperature settings of high, medium, to control this feature...
Page 13: Memory Seat, Mirrors, And Pedals
Memory Seat, Mirrors, and Pedals 2. Press and hold button 1 until two beeps sound through the driver’s front speaker to let you Your vehicle may have the memory package. know that the position has been stored. The controls for this A second seating, mirror, and throttle and brake feature are located pedal position can be programmed by repeating...
Page 14 DIC. You can select or memory button. If the memory position is still not select the following: not recalling, see your GM dealer for service. • The automatic easy exit seat feature Easy Exit Seat •...
Page 15: Reclining Seatbacks
Reclining Seatbacks If the seats have manual reclining seatbacks, the lever used to operate them is located on the Manual Reclining Seatbacks outboard side of the seat(s). CAUTION: You can lose control of the vehicle if you try to adjust a manual driver’s seat while the vehicle is moving.
Page 16 Power Reclining Seatbacks To return the seatback to an upright position, do the following: 1. Lift the lever fully without applying pressure to the seatback and the seatback will return to the upright position. 2. Push and pull on the seatback to make sure it is locked.
Page 17 CAUTION: Sitting in a reclined position when your vehicle is in motion can be dangerous. Even if you buckle up, your safety belts cannot do their job when you are reclined like this. The shoulder belt cannot do its job. In a crash, you could go into it, receiving neck or other injuries.
Page 18: Head Restraints
Head Restraints Pull the head restraint up to raise it. To lower the head restraint, press the release button (A), located on the top of the seatback, while you push the head restraint down. The front seats may have head restraints that also tilt forward and rearward.
Page 19: Center Seat
Center Seat (Heated Seat): To heat the seat cushion, press the button with the heated seat symbol. Your vehicle may have a front center seat. The A heated seat symbol will be shown in the RSA seatback doubles as an armrest and cupholder/ display to indicate that the feature is on.
Page 20: 60/40 Split Bench Seat (Second Row)
60/40 Split Bench Seat (Second Row) If your vehicle has a 60/40 split bench, the seat(s) can be folded for additional cargo space or folded and tumbled for easy entry and exit to the third row seats, if your vehicle has them. These seats will have either the manual fold and tumble feature or the automatic seat release fold and tumble feature.
Page 21 3. Lift the same lever again to release the rear of the seat from the ﬂoor. The seat will tumble forward. The seatback will fold forward automatically. Leaving the seatback in this position creates a ﬂat load ﬂoor. If the seatback cannot fold ﬂat, try moving the front seat forward and/or put the front seatback in the upright position.
Page 22 Returning the Seat(s) to the Sitting Position CAUTION: To return the seat to the sitting position, do the following: A safety belt that is improperly routed, not properly attached, or twisted will not 1. Pull the seat down until it latches to the ﬂoor. provide the protection needed in a crash.
Page 23 Folding and Tumbling the Seat(s) from the Third Row Seats CAUTION: Be sure to return the seat to the passenger seating position when ﬁnished. Push and pull on the seat to make sure it is locked in place. Never use the third row seating position while the second row is folded or folded and tumbled.
Page 24 Automatic Release Fold and Tumble 2. From the front seats, press one of Feature the automatic The transmission must be in PARK (P) for this seat release buttons feature to work. located on the overhead console. Folding and Tumbling the Seat(s) CAUTION: Overhead Console Automatically folding and tumbling the...
Page 25 Returning the Seat(s) to the Sitting Position CAUTION: To return the seat to the sitting position, do the following: A safety belt that is improperly routed, not properly attached, or twisted will not 1. Pull the seat down until it latches to the ﬂoor. provide the protection needed in a crash.
Page 26: Bucket Seats (Second Row)
Folding and Tumbling the Second Row 2. Press the automatic seat release button Seat(s) from the Third Row Seats or located on the Outside panel behind the rear doors. CAUTION: Be sure to return the seat to the passenger seating position when ﬁnished. Push and pull on the seat to make sure it is locked in Driver’s Side Rear Panel place.
Page 27 Reclining Seatbacks To return the seatback to an upright position, do the following: To recline the seatback, do the following: 1. Lift the lever fully without applying pressure to the seatback and the seatback will return to the upright position. CAUTION: If the seatback is not locked, it could move forward in a sudden stop or crash.
Page 28 Manual Fold and Tumble Feature Folding and Tumbling the Seat(s) To fold and tumble the seat, do the following: 1. Make sure that there is nothing under, in front of, or on the seat. Notice: Folding a rear seat with the safety belts still fastened may cause damage to the seat or the safety belts.
Page 29 3. Lift the lever again to release the rear CAUTION: of the seat from the ﬂoor. The seat If the seatback is not locked, it could will tumble forward. move forward in a sudden stop or crash. That could cause injury to the person sitting there.
Page 30 Folding and Tumbling the Seat(s) from the 2. Lift the lever, located on the Third Row Seats bottom rear of the second row seat on CAUTION: the inboard side, to release the seatback. The Be sure to return the seat to the seatback will fold passenger seating position when ﬁnished.
Page 31 Automatic Release Fold and Tumble 2. From the front seats, press one of Feature the automatic The transmission must be in PARK (P) for this seat release buttons feature to work. located on the overhead console. Folding and Tumbling the Seat(s) CAUTION: Overhead Console Automatically folding and tumbling the...
Page 32 Returning the Seat(s) to the Sitting Folding and Tumbling the Second Row Position Seat(s) from the Third Row Seats or Outside To return the seat to the sitting position, do the following: CAUTION: 1. Pull the seat down until it latches to the ﬂoor. The seatback cannot be raised if the seat is not latched to the ﬂoor.
Page 33: Third Row Seat
Folding the Seatback(s) 2. Press the automatic seat release button To fold the seatback, do the following: located on the panel behind the 1. Open the liftgate to access the controls for rear doors. the seat. 2. Remove all items on the seat cushion. Notice: Folding a rear seat with the safety belts still fastened may cause damage to the seat or the safety belts.
Page 34 Unfolding the Seatback(s) To tumble the seat, do the following: 1. Open the liftgate to access the controls for To return the seatback to the upright position, the seat. do the following: 2. Make sure the head rests are completely 1.
Page 35 5. Lift the rear of the seat up from the ﬂoor. CAUTION: 6. Tilt the seat fully forward to lock it into place. 7. Push and pull on the seat to make sure it is locked. If the seatback is not locked, it could move forward in a sudden stop or crash.
Page 36 3. Lower the rear of the seat and push down on the seat to engage the rear ﬂoor latches. CAUTION: A seat that is not locked into place properly can move around in a collision or 3. Unlatch the seat from the ﬂoor by pulling the sudden stop.
Page 37 CAUTION: CAUTION: If the seatback is not locked, it could A safety belt that is improperly routed, move forward in a sudden stop or crash. not properly attached, or twisted will not That could cause injury to the person provide the protection needed in a crash. sitting there.
Page 38: Safety Belts
Safety Belts CAUTION: Safety Belts: They Are for Everyone It is extremely dangerous to ride in a This part of the manual tells you how to use cargo area, inside or outside of a vehicle. safety belts properly. It also tells you some things In a collision, people riding in these areas you should not do with safety belts.
Page 39 Why Safety Belts Work In most states and in all Canadian provinces, the law says to wear safety belts. Here is When you ride in or on anything, you go as fast why: They work. as it goes. You never know if you will be in a crash. If you do have a crash, you do not know if it will be a bad one.
Page 40 Put someone on it. Get it up to speed. Then stop the vehicle. The rider does not stop.
Page 41 The person keeps going until stopped by or the instrument panel... something. In a real vehicle, it could be the windshield...
Page 42: Questions And Answers About
Questions and Answers About Safety Belts Will I be trapped in the vehicle after an accident if I am wearing a safety belt? You could be — whether you are wearing a safety belt or not. But you can unbuckle a safety belt, even if you are upside down.
Page 43: How To Wear Safety Belts Properly
How to Wear Safety Belts Properly If I am a good driver, and I never drive far from home, why should I wear This part is only for people of adult size. safety belts? Be aware that there are special things to know You may be an excellent driver, but if you are about safety belts and children.
Page 44 Make sure the release button on the buckle is positioned so you would be able to unbuckle the safety belt quickly if you ever had to. 5. Move the shoulder belt height adjuster to the height that is right for you. Improper shoulder belt height adjustment could reduce the effectiveness of the safety belt in a crash.
Page 45 The lap part of the belt should be worn low and snug on the hips, just touching the thighs. In a crash, this applies force to the strong pelvic bones. And you would be less likely to slide under the lap belt. If you slid under it, the belt would apply force at your abdomen.
Page 46 What is wrong with this? CAUTION: You can be seriously hurt if your shoulder belt is too loose. In a crash, you would move forward too much, which could increase injury. The shoulder belt should ﬁt against your body. The shoulder belt is too loose. It will not give nearly as much protection this way.
Page 47 What is wrong with this? CAUTION: You can be seriously injured if your belt is buckled in the wrong place like this. In a crash, the belt would go up over your abdomen. The belt forces would be there, not at the pelvic bones. This could cause serious internal injuries.
Page 48 What is wrong with this? CAUTION: You can be seriously injured if you wear the shoulder belt under your arm. In a crash, your body would move too far forward, which would increase the chance of head and neck injury. Also, the belt would apply too much force to the ribs, which are not as strong as shoulder bones.
Page 49 What is wrong with this? CAUTION: You can be seriously injured by a twisted belt. In a crash, you would not have the full width of the belt to spread impact forces. If a belt is twisted, make it straight so it can work properly, or ask your dealer to ﬁx it.
Page 50: Shoulder Belt Height Adjustment
Shoulder Belt Height Adjustment Before you begin to drive, move the shoulder belt adjuster to the height that is right for you. Adjust the height so that the shoulder portion of the belt is centered on your shoulder. The belt should be away from your face and neck, but not falling off your shoulder.
Page 51: Safety Belt Use During Pregnancy
Safety Belt Use During Pregnancy The best way to protect the fetus is to protect the mother. When a safety belt is worn properly, Safety belts work for everyone, including pregnant it is more likely that the fetus will not be hurt in a women.
Page 52: Center Front Passenger Position
Center Front Passenger Position Lap Belt If your vehicle has a front bench seat, someone can sit in the center position. To make the belt shorter, pull its free end as shown until the belt is snug. Buckle, position and release it the same way as the lap part of a lap-shoulder belt.
Page 53: Rear Seat Passengers
Rear Seat Passengers It is very important for rear seat passengers to buckle up! Accident statistics show that unbelted people in the rear seat are hurt more often in crashes than those who are wearing safety belts. Rear passengers who are not safety belted can be thrown out of the vehicle in a crash.
Page 54 When the shoulder belt is pulled out all the way, it will lock. If it does, let it go back all the way and start again. If the belt is not long enough, see Safety Belt Extender on page 59. Make sure the release button on the buckle is positioned so you would be able to unbuckle the safety belt quickly if you ever had to.
Page 55: Rear Safety Belt Comfort Guides
The safety belt locks if there is a sudden stop or a crash, or if you pull the belt very quickly out of the retractor. CAUTION: You can be seriously hurt if your shoulder belt is too loose. In a crash, you would move forward too much, which could increase injury.
Page 56 There is one guide for each outside passenger position in the second row seat and the third row, if your vehicle has one. Here is how to install a comfort guide and use the safety belt: Third Row If your vehicle has a third row, remove the guide from its storage pocket on the side of the seat.
Page 57 2. Slide the guide under and past the belt. 3. Be sure that the belt is not twisted and it The elastic cord must be under the belt. lies ﬂat. The elastic cord must be under Then, place the guide over the belt, and the belt and the guide on top.
Page 58 CAUTION: A safety belt that is not properly worn may not provide the protection needed in a crash. The person wearing the belt could be seriously injured. The shoulder belt should go over the shoulder and across the chest. These parts of the body are best able to take belt restraining forces.
Page 59: Safety Belt Pretensioners
Safety Belt Pretensioners Safety Belt Extender Your vehicle has safety belt pretensioners for the If the vehicle’s safety belt will fasten around you, driver and right front passenger. Although you you should use it. cannot see them, they are located on the retractor But if a safety belt is not long enough, your dealer part of the safety belts.
Page 60: Child Restraints
Child Restraints What is the proper way to wear safety belts? If possible, an older child should wear a Older Children lap-shoulder belt and get the additional restraint a shoulder belt can provide. The shoulder belt should not cross the face or neck.
Page 61 What if a child is wearing a lap-shoulder belt, but the child is so small that the shoulder belt is very close to the child’s face or neck? If the child is sitting in a rear seat outside position, move the child toward the center of the vehicle.
Page 62 CAUTION: Never do this. Here a child is sitting in a seat that has a lap-shoulder belt, but the shoulder part is behind the child. If the child wears the belt in this way, in a crash the child might slide under the belt.
Page 63: Infants And Young Children
Infants and Young Children Every time infants and young children ride in vehicles, they should have the protection provided Everyone in a vehicle needs protection! This by appropriate restraints. Young children should includes infants and all other children. Neither the not use the vehicle’s adult safety belts alone, distance traveled nor the age and size of the unless there is no other choice.
Page 64 CAUTION: People should never hold a baby in their arms while riding in a vehicle. A baby does not weigh much — until a crash. During a crash a baby will become so heavy it is not possible to hold it. For example, in a crash at only 25 mph (40 km/h), a 12 lb (5.5 kg) baby will suddenly become a 240 lb (110 kg) force...
Page 65 CAUTION: Children who are up against, or very close to, any airbag when it inﬂates can be seriously injured or killed. Airbags plus lap-shoulder belts offer protection for adults and older children, but not for young children and infants. Neither the vehicle’s safety belt system nor its airbag system is designed for them.
Page 66 What are the different types of add-on child restraints? CAUTION: Add-on child restraints, which are purchased by the vehicle’s owner, are available in four Newborn infants need complete support, basic types. Selection of a particular restraint including support for the head and neck. should take into consideration not only the This is necessary because a newborn child’s weight, height and age but also whether...
Page 67: Child Restraint Systems
Child Restraint Systems CAUTION: The body structure of a young child is quite unlike that of an adult or older child, for whom the safety belts are designed. A young child’s hip bones are still so small that the vehicle’s regular safety belt may not remain low on the hip bones, as it should.
Page 68 A rear-facing infant seat (B) provides restraint with A forward-facing child seat (C-E) provides restraint the seating surface against the back of the for the child’s body with the harness and also infant. The harness system holds the infant in sometimes with surfaces such as T-shaped place and, in a crash, acts to keep the infant or shelf-like shields.
Page 69 How Should I Use a Child Restraint? A child restraint system is any device designed for use in a motor vehicle to restrain, seat, or position children. A built-in child restraint system is a permanent part of the motor vehicle. An add-on child restraint system is a portable one, which is purchased by the vehicle’s owner.
Page 70 Securing an Add-on Child Restraint When securing an add-on child restraint, refer to the instructions that come with the restraint in the Vehicle which may be on the restraint itself or in a booklet, or both, and to this manual. The child restraint instructions are important, so if they are not CAUTION: available, obtain a replacement copy from the...
Page 71: Where To Put The Restraint
Securing the Child Within the Because there are different systems, it is important to refer to the instructions that come with the Child Restraint restraint. A child can be endangered in a crash if There are several systems for securing the child the child is not properly secured in the child within the child restraint.
Page 72 Your vehicle has a rear seat that will accommodate a rear-facing child restraint. A label on your sun CAUTION: (Continued) visor says, “Never put a rear-facing child seat in the front.” This is because the risk to the We recommend that rear-facing child rear-facing child is so great, if the airbag deploys.
Page 73: Lower Anchors And Tethers For Children (Latch)
Lower Anchors and Tethers for Your vehicle has lower anchors and top tether anchors. Your child restraint may have lower Children (LATCH) attachments and a top tether. Your vehicle has the LATCH system. The LATCH Not all vehicle seating positions or child restraints system holds a child restraint during driving or have lower anchors and attachments or top in a crash.
Page 74 Top Tether Anchor Your child restraint may have a single tether (A) or a dual tether (C). Either will have a single attachment (B) to secure the top tether to the anchor. Some child restraints with top tethers are designed for use with or without the top tether being attached.
Page 75 Lower Anchor and Top Tether Anchor (Top Tether Anchor): Locations Seating positions with top tether anchors. (Lower Anchor): Seating positions with two lower anchors. (Top Tether Anchor): Seating positions with top tether anchors. Third Row — Two Passenger Second Row — 60/40 (Top Tether Anchor): Seating positions with (Lower Anchor):...
Page 76 For models with a three passenger third row seat, see the information following for installing a child restraint with a top tether in the third row, if your vehicle has one. Never install two top tethers using the same top tether anchor. For models with 60/40 second row seating, the rear right side passenger and center seating positions have exposed metal anchors located in...
Page 77 Second Row Seat — 60/40 Third Row Seat — Two or Three Passenger For models with 60/40 second row seating, the For vehicles with a two passenger third row seat, top tether anchors are located at the bottom rear of there is one top tether anchor located at the the seat cushion for each seating position in the bottom rear of the seat cushion that can be used...
Page 78 Securing a Child Restraint Designed for Do not secure a child restraint in the right front passenger position or the third row passenger side the LATCH System seating position if your vehicle has a third row seat, if a national or local law requires that the CAUTION: top tether be attached, or if the instructions that come with the child restraint say that the...
Page 79 CAUTION: CAUTION: Each top tether anchor and lower anchor Children can be seriously injured or in the vehicle is designed to hold only strangled if a shoulder belt is wrapped one child restraint. Attaching more than around their neck and the safety belt one child restraint to a single anchor continues to tighten.
Page 80 Notice: Contact between the child restraint or Refer to your child restraint manufacturer the LATCH attachment parts and the vehicle’s instructions and the instructions in this manual. safety belt assembly may cause damage to 1.1. Find the lower anchors for the desired these parts.
Page 81 2.2. Route, attach and tighten the top If the position you are tether according to your child restraint using has an adjustable instructions and the following head rest/restraint instructions: and you are using a dual tether, route If the position you are the tether around the using does not have head rest/restraint.
Page 82: Securing A Child Restraint In A Rear Seat Position
Securing a Child Restraint in a Rear Seat Position If your child restraint has the LATCH system, see Lower Anchors and Tethers for Children (LATCH) on page 73. If your vehicle has a third row, there is no top tether anchor in the passenger-side seating position.
Page 83 4. Pull the rest of the shoulder belt all the way 5. To tighten the belt, push down on the child out of the retractor to set the lock. restraint, pull the shoulder portion of the belt to tighten the lap portion of the belt and feed the shoulder belt back into the retractor.
Page 84: Securing A Child Restraint In The Center Front Seat Position
Securing a Child Restraint in the 6. If your child restraint manufacturer recommends using a top tether, and the Center Front Seat Position position that you are using has a top tether anchor, attach and tighten the top tether to the top tether anchor. Refer to the CAUTION: instructions that came with the child restraint and to Lower Anchors and Tethers for...
Page 85: Securing A Child Restraint In The Right Front Seat Position
Securing a Child Restraint in the CAUTION: Right Front Seat Position Your vehicle has a right front passenger airbag. A child in a rear-facing child restraint can A rear seat is a safer place to secure a be seriously injured or killed if the right forward-facing child restraint.
Page 86 If you need to secure a forward-facing child 1. Your vehicle has a right front passenger’s restraint in the right front seat position, move the frontal airbag. See Passenger Sensing seat as far back as it will go before securing System on page 100.
Page 87 4. Buckle the belt. Make sure the release button 5. Pull the rest of the shoulder belt all the way is positioned so you would be able to unbuckle out of the retractor to set the lock. the safety belt quickly if you ever had to.
Page 88 8. If your vehicle has the passenger sensing system and the airbag is off, the off indicator in the instrument panel will be lit and stay lit when the key is turned to RUN or START. If a child restraint has been installed and the on indicator is lit, turn the vehicle off.
Page 89: Airbag System
Airbag System Frontal airbags are designed to help reduce the risk of injury from the force of an inﬂating frontal airbag. Your vehicle has a frontal airbag for the driver But these airbags must inﬂate very quickly to do and a frontal airbag for the right front passenger. their job and comply with federal regulations.
Page 90 CAUTION: (Continued) CAUTION: Roof-mounted rollover airbags are Airbags are “supplemental restraints” to designed to inﬂate in moderate to severe the safety belts. All airbags are designed crashes where something hits the side of to work with safety belts but do not your vehicle, during a vehicle rollover, or replace them.
Page 91 CAUTION: CAUTION: Both frontal and roof-mounted rollover Anyone who is up against, or very close airbags inﬂate with great force, faster than to, any airbag when it inﬂates can be the blink of an eye. If you are too close to seriously injured or killed.
Page 92: Where Are The Airbags
Where Are the Airbags? There is an airbag readiness light on the instrument panel cluster, which shows the airbag symbol. The system checks the airbag electrical system for malfunctions. The light tells you if there is an electrical problem. See Airbag Readiness Light on page 227 for more information.
Page 93 The right front passenger’s airbag is in the If your vehicle has a roof-mounted rollover airbag instrument panel on the passenger’s side. for the driver and the person seated directly behind the driver, it is located in the ceiling above the side windows.
Page 94 If your vehicle has a roof-mounted rollover airbag and a third row passenger seat, the airbag is located in the ceiling above the rear windows for If your vehicle has a roof-mounted rollover airbag the outside passenger positions in the third row. for the right front passenger and the person directly behind that passenger, it is located in the ceiling above the side windows.
Page 95: When Should An Airbag Inflate
When Should an Airbag Inﬂate? CAUTION: The driver’s and right front passenger’s frontal airbags are designed to inﬂate in moderate to severe frontal or near-frontal crashes. But If something is between an occupant they are designed to inﬂate only if the impact and an airbag, the bag might not inﬂate exceeds a predetermined deployment threshold.
Page 96 For more severe frontal impacts, full deployment The frontal airbags (driver and right front occurs. If the front of your vehicle goes straight passenger) are not intended to inﬂate during into a wall that does not move or deform, the vehicle rollovers, rear impacts, or in many side threshold level for the reduced deployment is about impacts.
Page 97: What Makes An Airbag Inflate
What Makes an Airbag Inﬂate? In any particular crash, no one can say whether an airbag should have inﬂated simply because In an impact of sufficient severity, the airbag of the damage to a vehicle or because of what the sensing system detects that the vehicle is repair costs were.
Page 98: How Does An Airbag Restrain
How Does an Airbag Restrain? What Will You See After an Airbag Inﬂates? In moderate to severe frontal or near frontal collisions, even belted occupants can contact After a frontal airbag inﬂates, it quickly deﬂates, the steering wheel or the instrument panel. so quickly that some people may not even realize In moderate to severe side collisions, even belted the airbag inﬂated.
Page 99 In many crashes severe enough to inﬂate an airbag, windshields are broken by vehicle CAUTION: deformation. Additional windshield breakage may also occur from the right front passenger airbag. When an airbag inﬂates, there is dust • Airbags are designed to inﬂate only once. in the air.
Page 100: Passenger Sensing System
Passenger Sensing System The passenger sensing system will turn off the right front passenger’s frontal airbag under certain Your vehicle has a passenger sensing system. conditions. The driver’s airbags are not part of The passenger airbag status indicator on the the passenger sensing system.
Page 101 Your vehicle has a rear seat that will accommodate a rear-facing child restraint. A label on your sun CAUTION: (Continued) visor says, “Never put a rear-facing child seat in the front.” This is because the risk to the Even though the passenger sensing rear-facing child is so great, if the airbag deploys.
Page 102 The passenger sensing system is designed to turn When the passenger sensing system has turned off the right front passenger’s airbag if: off the passenger’s airbag, the off indicator will light and stay lit to remind you that the airbag is off. •...
Page 103 If the on indicator is still lit, secure the child in If a person of adult-size is sitting in the right front the child restraint in a rear seat position in passenger’s seat, but the off indicator is lit, it the vehicle and check with your dealer.
Page 104 CAUTION: If the airbag readiness light in the instrument panel cluster ever comes on and stays on, it means that something may be wrong with the airbag system. If this ever happens, have the vehicle serviced promptly, because an adult-size person sitting in the right front passenger’s seat may not have the protection of the frontal airbag.
Page 105: Servicing Your Airbag-Equipped Vehicle
CAUTION: CAUTION: Stowing of articles under the passenger’s For up to 10 seconds after the ignition seat or between the passenger’s seat key is turned off and the battery is cushion and seatback may interfere with disconnected, an airbag can still inﬂate the proper operation of the passenger during improper service.
Page 106: Adding Equipment To Your Airbag-Equipped Vehicle
Adding Equipment to Your Because I have a disability, I have to get my vehicle modiﬁed. How can I ﬁnd out Airbag-Equipped Vehicle whether this will affect my airbag system? Changing or moving any parts of the Is there anything I might add to the front front seats, safety belts, the airbag sensing or sides of the vehicle that could keep the and diagnostic module (located under...
Page 107: Restraint System Check
Restraint System Check Notice: If you damage the covering for the driver’s or the right front passenger’s airbag, or the side impact airbag covering on the Checking the Restraint Systems ceiling near the side windows, the airbag may not work properly. You may have to replace Now and then, make sure the safety belt reminder the airbag module in the steering wheel, both light and all your belts, buckles, latch plates,...
Page 108: Replacing Restraint System Parts After A Crash
Replacing Restraint System Parts If belts are cut or damaged, replace them. Collision damage also may mean you will need to After a Crash have LATCH system, safety belt or seat parts repaired or replaced. New parts and repairs may be necessary even if the belt or LATCH system CAUTION: was not being used at the time of the collision.
Page 109 Section 2 Features and Controls Keys .............111 Starting and Operating Your Vehicle ..136 Remote Keyless Entry System ....112 New Vehicle Break-In .........136 Remote Keyless Entry System Operation ...113 Ignition Positions ........137 Retained Accessory Power (RAP) ....138 Doors and Locks .........120 Starting the Engine ........138 Door Locks ..........120 Adjustable Throttle and Brake Pedal ...140...
Page 110 Section 2 Features and Controls Mirrors ............157 Universal Home Remote System ....171 Automatic Dimming Rearview Mirror with Universal Home Remote System ....171 ® OnStar , Compass and Temperature Universal Home Remote System Display ............157 Operation ..........172 Automatic Dimming Rearview Mirror with Storage Areas ..........176 Compass and Temperature Display ..161 Glove Box ..........176...
Page 111: Keys
Keys CAUTION: Leaving children in a vehicle with the ignition key is dangerous for many reasons. They could operate the power windows or other controls or even make the vehicle move. The children or others could be badly injured or even killed. Do not leave the keys in a vehicle with children.
Page 112: Remote Keyless Entry System
1. This device may not cause interference. If you ever do get locked out of your vehicle, 2. This device must accept any interference call the GM Roadside Assistance Center. received, including interference that may See Roadside Assistance Program on page 577.
Page 113: Remote Keyless Entry System Operation
Remote Keyless Entry System At times you may notice a decrease in operating range. This is normal for any remote keyless entry Operation system. If the transmitter does not work or if you have to stand closer to your vehicle for the The vehicle’s doors can be locked and unlocked transmitter to work, try this: from about 3 feet (1 m) up to 65 feet (20 m)
Page 114 (Lock): Press the lock button to lock all the doors. If enabled through the Driver Information Center (DIC), the parking lamps will ﬂash once to indicate locking has occurred. If enabled through the DIC, the horn will chirp when the lock button is pressed again within ﬁve seconds of the previous press of the lock button.
Page 115 GM dealer. Remember to bring any additional transmitters so they can also be re-coded to (Vehicle Locator/Panic Alarm): Press and match the new transmitter. Once your dealer has release this button to locate your vehicle.
Page 116 Battery Replacement Under normal use, the battery in your RKE transmitter should last about four years. You can tell the battery is weak if the transmitter will not work at the normal range in any location. If you have to get close to your vehicle before the transmitter works, it is probably time to change the battery.
Page 117 3. Slide the new battery into the transmitter with If your vehicle does not have an automatic climate the positive side of the battery facing down. control system, during remote start the climate Use a type CR2032 battery, or equivalent control system will turn on at the setting the vehicle type.
Page 118 If the vehicle is left running it will automatically (Remote Start): Press and release the lock shut off after 10 minutes unless a time extension button and then press and hold the remote has been done. start button to start the vehicle. To manually shut off a remote start, do any of the To start the vehicle using the remote start feature, following:...
Page 119 Remote Start Ready Once two remote starts, or a single remote start with one time extension has been done, the If your vehicle does not have the remote vehicle vehicle must be started with the key. start feature, it may have the remote start After the key is removed from the ignition, the ready feature.
Page 120: Doors And Locks
Doors and Locks CAUTION: (Continued) Door Locks • Young children who get into unlocked vehicles may be unable to get out. A child can be overcome by extreme CAUTION: heat and can suffer permanent injuries or even death from heat stroke. Unlocked doors can be dangerous.
Page 121: Power Door Locks
Power Door Locks This feature will not operate if the key is in the ignition. The power door lock switches are located on the You can program this feature using the Driver armrest on the front doors. Information Center (DIC). See DELAY DOOR LOCK under DIC Vehicle Customization (With (Unlock): Press the side of the switch with the DIC Buttons) on page 262.
Page 122: Rear Door Security Locks
Rear Door Security Locks When you want to open a rear door when the security lock is on, do the following: Your vehicle has rear door security locks. 1. Unlock the door using the remote keyless These prevent passengers from opening the entry transmitter, if the vehicle has one, rear doors from the inside.
Page 123: Liftgate/Liftglass
If the passenger’s side power door lock switch is pressed when the front passenger’s door is CAUTION: (Continued) open and the key is in the ignition, all of the doors will lock and then the front passenger’s If you must drive with the liftglass or door will unlock.
Page 124 To unlock the liftgate, use the power door lock To open the entire liftgate, press the touchpad switch or press the door unlock button on on the underside of the liftgate handle (B). the Remote Keyless Entry (RKE) transmitter twice. The vehicle must be in PARK (P) to open the See Remote Keyless Entry System Operation liftgate.
Page 125: Power Liftgate
Power Liftgate To open and close the liftgate, press and hold the power liftgate button on the Remote Keyless Power Liftgate Operation Entry (RKE) transmitter until the liftgate starts moving. Press the RKE button a second Your vehicle may have a power liftgate. The time during liftgate operation to reverse that vehicle must be in PARK (P) to power open or operation.
Page 126 If you shift the transmission out of PARK (P) while the power function is in progress, the liftgate power function will continue to completion. If you shift the transmission out of PARK (P) and accelerate before the power liftgate latches closed, the liftgate may reverse to the open position.
Page 127 Obstacle Detection Features Manual Operation of Power Liftgate If the liftgate encounters an obstacle during a To change the liftgate power open or close cycle, a warning chime will to manual operation, sound and the liftgate will automatically reverse toggle the switch on the direction to the full closed or open position.
Page 128 It is not recommended that you drive with the liftgate open, however, if you must drive with the CAUTION: (Continued) liftgate open, the power liftgate should be switched to manual liftgate operation — the overhead If you must drive with the liftglass or console switch set to the “Disable”...
Page 129: Power Running Boards
Power Running Boards The switch used to disable the power Your vehicle may have power running boards. running boards is These make getting into and out of the vehicle located on the center easier. console below the climate control system. The power running boards activate when either door on the driver’s or passenger’s side is opened or closed.
Page 130: Windows
Windows CAUTION: Leaving children, helpless adults, or pets in a vehicle with the windows closed is dangerous. They can be overcome by the extreme heat and suffer permanent injuries or even death from heat stroke. Never leave a child, a helpless adult, or a pet alone in a vehicle, especially with the windows closed in warm or hot weather.
Page 131: Power Windows
Power Windows Express-Down Windows The driver and front passenger windows have The power window controls are located on an express-down feature that allows the windows each of the side doors. to be lowered without holding the switch. Press down fully on the window switch, then release, to activate the express-down mode.
Page 132: Sun Visors
Sun Visors Content Theft-Deterrent Pull the sun visor down to block glare. Detach Your vehicle may have a content theft-deterrent the sun visor from the center mount and slide it alarm system. along the rod from side-to-side to cover the driver or passenger side of the front window.
Page 133 If a door is opened without using the RKE If you set off the alarm by accident, turn off the transmitter, a ten second pre-alarm will occur. alarm by pressing unlock on the RKE transmitter The horn will chirp and the lights will ﬂash. If the or by placing the key in the ignition and turning key is not placed in the ignition and turned to it to START.
Page 134: Pass-Key Iii+ Operation
® ® PASS-Key III+ PASS-Key III+ Operation ® The PASS-Key III+ system operates on a radio ® Your vehicle has PASS-Key III+ (Personalized frequency subject to Federal Communications Automotive Security System) theft-deterrent Commission (FCC) Rules and with Industry ® system. PASS-Key III+ is a passive Canada.
Page 135 If your vehicle does start, the ﬁrst key may be 3. After the engine has started, turn the key faulty. See your dealer who can service the to OFF, and remove the key. ® PASS-Key III+ to have a new key made. In an 4.
Page 136: Starting And Operating Your Vehicle
Starting and Operating • Avoid making hard stops for the ﬁrst 200 miles (322 km) or so. During this Your Vehicle time your new brake linings are not yet broken in. Hard stops with new linings can mean premature wear and earlier New Vehicle Break-In replacement.
Page 137: Ignition Positions
Ignition Positions Notice: Using a tool to force the key from the ignition switch could cause damage or break the key. Use the correct key and turn the key only with your hand. Make sure the key is all the way in. If it is, turn the steering wheel left and right while you turn the key hard.
Page 138: Retained Accessory Power (Rap)
Retained Accessory Power (RAP) Notice: Do not try to shift to PARK (P) if your vehicle is moving. If you do, you could damage Your vehicle has a Retained Accessory Power the transmission. Shift to PARK (P) only when (RAP) feature which will allow certain features on your vehicle is stopped.
Page 139 Notice: Cranking the engine for long periods of 2. If your engine still will not start, or starts but time, by returning the key to the START position then stops, it could be ﬂooded with too much immediately after cranking has ended, can gasoline.
Page 140: Adjustable Throttle And Brake Pedal
Adjustable Throttle and Brake Pedal No adjustment to the pedals can be made when the vehicle is in REVERSE (R) or while using If your vehicle has this feature, you can change the cruise control. the position of the throttle and brake pedals. Your vehicle may have a memory function which allows pedal settings to be saved and recalled.
Page 141: Displacement On Demand™ (Dod™)
To Use the Engine Coolant Heater 4. Before starting the engine, be sure to unplug and store the cord as it was before to keep it 1. Turn off the engine. away from moving engine parts. If you do 2. Open the hood and unwrap the electrical not, it could be damaged.
Page 142: Automatic Transmission Operation
Automatic Transmission Operation CAUTION: There are several different positions for the shift lever. It is dangerous to get out of your vehicle if the shift lever is not fully in PARK (P) with the parking brake ﬁrmly set. Your vehicle can roll. Do not leave your vehicle when the engine is running unless you have to.
Page 143 NEUTRAL (N): In this position, your engine does not connect with the wheels. To restart when CAUTION: you are already moving, use NEUTRAL (N) only. Also, use NEUTRAL (N) when your two-wheel If you have four-wheel drive, your vehicle drive vehicle is being towed. will be free to roll —...
Page 144 DRIVE (D): This position is for normal driving. It SECOND (2): This position reduces vehicle speed provides the best fuel economy for your vehicle. even more than THIRD (3) without using your If you need more power for passing, and you are: brakes.
Page 145: Tow/Haul Mode
Tow/Haul Mode FIRST (1): This position reduces vehicle speed even more than SECOND (2) without using your brakes. You can use it on very steep hills, or in deep snow or mud. If the shift lever is put in FIRST (1) while the vehicle is moving forward, the transmission will not shift into ﬁrst gear until the vehicle is going slowly enough.
Page 146: Four-Wheel Drive
Front Axle Locking Feature When Tow/Haul mode is selected the The front axle locks and unlocks automatically Tow/Haul indicator when you shift the transfer case. Some delay for light will come on. the axle to lock or unlock is normal. Automatic Transfer Case The transfer case knob ®...
Page 147 You can choose among four driving settings: It sends maximum power to all four wheels. You might choose Four-Wheel Drive Low if you (Two-Wheel Drive High): This setting are driving off-road in deep sand, deep mud, deep is used for driving in most street and highway snow, and while climbing or descending steep situations.
Page 148 Shifting Into Two-Wheel Drive High Indicator lights in the button will come on to show which setting you are in. The indicator lights Turn the knob to the Two-Wheel High position. will come on brieﬂy when you turn on the ignition This can be done at any speed, except when and one will stay on.
Page 149 It is typical for your vehicle to exhibit signiﬁcant You must wait for the Four-Wheel Drive High, engagement noise and bump when shifting AUTO or Two-Wheel Drive High indicator light to between Four-Wheel Drive Low and Four-Wheel stop ﬂashing and remain on before shifting Drive High ranges or from NEUTRAL with the your transmission into gear.
Page 150 Shifting into NEUTRAL 7. If the engine is running, verify that the transmission is in NEUTRAL (N) by shifting To shift the transfer case to NEUTRAL do the the transmission to REVERSE (R) for following: one second, then shift the transmission to DRIVE (D) for one second.
Page 151: Parking Brake
Parking Brake 3. Turn the transfer case knob to the desired transfer case shift position (Two-Wheel To set the parking brake, hold the regular brake Drive High, Four-Wheel Drive High, AUTO). pedal down with your right foot. Push down After the transfer case has shifted out of the parking brake pedal with your left foot.
Page 152: Shifting Into Park (P)
If the ignition is on when the parking brake is released, the brake system warning light will CAUTION: (Continued) go off. To be sure your vehicle will not move, even Notice: Driving with the parking brake on can overheat the brake system and cause when you are on fairly level ground, use premature wear or damage to brake system the steps that follow.
Page 153 Leaving Your Vehicle With the If you have to leave your vehicle with the engine running, be sure your vehicle is in PARK (P) Engine Running and the parking brake is ﬁrmly set before you leave it. After you move the shift lever into PARK (P), hold the regular brake pedal down.
Page 154: Shifting Out Of Park (P)
Parking Over Things That Burn If torque lock does occur, you may need to have another vehicle push yours a little uphill to take some of the pressure from the parking pawl in the transmission, then you will be able to pull the shift lever out of PARK (P).
Page 155: Engine Exhaust
Engine Exhaust CAUTION: (Continued) CAUTION: • Repairs were not done correctly. • Your vehicle or exhaust system had been modiﬁed improperly. Engine exhaust can kill. It contains the gas carbon monoxide (CO), which you If you ever suspect exhaust is coming into cannot see or smell.
Page 156: Running The Engine While Parked
Running the Engine While Parked CAUTION: It is better not to park with the engine running. But if you ever have to, here are some things to know. It can be dangerous to get out of your vehicle if the shift lever is not fully in CAUTION: PARK (P) with the parking brake ﬁrmly set.
Page 157: Mirrors
Mirrors CAUTION: Automatic Dimming Rearview Mirror Four-wheel drive vehicles with the transfer ® with OnStar , Compass and case in NEUTRAL will allow the vehicle to Temperature Display roll, even if your shift lever is in PARK (P). So, be sure the transfer case is in a drive Your vehicle may have this feature.
Page 158 If an abnormal temperature reading is displayed for an extended period of time, please see your GM dealer. Under certain circumstances, a delay in updating the temperature is normal.
Page 159 Compass Calibration Compass Variance The compass may need calibration if one of the The mirror is set in zone eight upon leaving following occurs: the factory. It will be necessary to adjust the compass to compensate for compass variance • After approximately ﬁve seconds, the if the vehicle is outside of zone eight.
Page 160 To adjust for compass variance, do the following: 3. Keep pressing the on/off button until the desired zone number appears in the 1. Find your current location and variance display. Release the button. After zone number on the following zone map. approximately four seconds of inactivity, the new zone number will be locked in and the compass/temperature display will return.
Page 161: Automatic Dimming Rearview Mirror With Compass And Temperature Display
Press and release the compass/temperature button to toggle the temperature display between Fahrenheit or Celsius. If an abnormal reading is displayed, please consult your GM dealer.
Page 162 Automatic Dimming Mirror Operation • The compass does not display the correct heading and the compass zone variance : Press this button to turn the automatic is set correctly. dimming feature on or off. The indicator light to In order to calibrate, CAL must be displayed in the the left of the button will turn on or off to indicate mirror compass windows.
Page 163: Outside Manual Mirrors
To adjust for compass variance: 3. Press the compass/temperature button on the bottom of the mirror until the new zone 1. Find your current location and variance zone number appears in the display. After you stop number on the following zone map. pressing the button, the display will show a compass direction within a few seconds.
Page 164: Outside Trailer-Tow Mirrors
Outside Trailer-Tow Mirrors These mirrors can be manually folded forward or rearward. On the lower portion of the mirror is a convex mirror. A convex mirror’s surface is curved so you can see more from the driver’s seat. The position of the convex mirror must be adjusted manually to the driver’s preferred position.
Page 165: Outside Power Mirrors
Outside Power Mirrors The mirrors may also include a memory function that works with the memory seats. See Memory Seat, Mirrors, and Pedals on page 13 for If your vehicle is more information. equipped with outside power mirrors, the The mirrors can be manually folded inward to controls are located prevent damage when going through an automatic on the driver’s...
Page 166: Outside Power Foldaway Mirrors
Outside Power Foldaway Mirrors If the mirrors are accidentally folded/unfolded manually, they may shake or ﬂutter at normal If your vehicle is driving speeds and may not stay in the unfolded equipped with outside position. If this happens, you will need to reset the power foldaway mirrors, mirrors.
Page 167: Outside Automatic Dimming Mirror
Outside Curb View Assist Mirrors Your vehicle may also have a turn signal indicator on the mirror. An arrow on the mirror will ﬂash If your vehicle has the memory package, the in the direction of the turn or lane change. outside mirrors are able to perform the curb view The mirrors may also include ground illumination assist mirror function.
Page 168: Outside Convex Mirror
® Outside Convex Mirror OnStar System Your passenger’s side mirror may have convex glass. A convex mirror’s surface is curved so you can see more from the driver’s seat. CAUTION: A convex mirror can make things (like other ® OnStar uses several innovative technologies vehicles) look farther away than they really and live advisors to provide you with a wide...
Page 169 ® Safe & Sound Plan A complete OnStar Owner’s Guide and the ® Terms and Conditions of the OnStar Subscription • Advanced Automatic Crash Notiﬁcation Service Agreement are included in the vehicle’s • Automatic Notiﬁcation of Airbag Deployment ® OnStar Subscriber Information packet located in your vehicle.
Page 170 ® ® OnStar Hands-Free Calling OnStar Steering Wheel Controls ® ® OnStar Hands-Free Calling allows OnStar Your vehicle may be subscribers to make and receive calls using voice equipped with a commands at the touch of a button. Hands-Free Talk/Mute button that Calling is fully integrated into the vehicle, and can be used to interact may be used with Pre-Paid Packages or linked to...
Page 171: Universal Home Remote System
Universal Home Remote This device complies with Part 15 of the FCC Rules. Operation is subject to the System following two conditions: 1. This device may not cause harmful Universal Home Remote System interference. 2. This device must accept any interference received, including interference that may cause undesired operation.
Page 172: Operation
Universal Home Remote System Be sure that people and objects are clear of the garage door or gate operator you are Operation programming. When programming a garage door, it is advised to park outside of the garage. Do not use the Universal Home Remote with any garage door opener that does not have the stop It is recommended that a new battery be installed in and reverse feature.
Page 173 2. Position the end of your hand-held transmitter 5. Press and hold the newly-trained Universal about 1 to 3 inches (3 to 8 cm) away from Home Remote button and observe the the Universal Home Remote buttons indicator light. while keeping the indicator light in view. If the indicator light stays on constantly, programming is complete and your device 3.
Page 174 Gate Operator and Canadian 6. Locate in the garage, the garage door opener receiver (motor-head unit). Locate the “Learn” Programming or “Smart” button. This can usually be Canadian radio-frequency laws require transmitter found where the hanging antenna wire is signals to time out or quit after several seconds attached to the motor-head unit.
Page 175 Using Universal Home Remote Reprogramming a Single Universal Home Remote Button Press and hold the appropriate Universal Home Remote button for at least half of a second. To program a device to Universal Home Remote The indicator light will come on while the signal using a Universal Home Remote button is being transmitted.
Page 176: Storage Areas
Storage Areas Glove Box Open the glove box by pulling the bottom of the handle upward. Cupholder(s) Your vehicle may have cupholders located in the front and rear of the ﬂoor console or in the fold down armrest. The front cupholders can be adjusted by moving the insert forward or rearward.
Page 177: Luggage Carrier
Luggage Carrier Be sure the cargo is properly loaded. • If small heavy objects are placed on the roof, If you have the luggage carrier, you can load place the load in the area over the rear wheels things on top of your vehicle. (behind the rear side door on extended The luggage carrier has siderails attached to the models).
Page 178: Rear Storage Area
Cargo Cover Your vehicle has a Center High-Mounted Stoplamp (CHMSL) located above the glass or above the rear load doors. CAUTION: If items are loaded on the roof of the vehicle, care should be taken not to block or damage the CHMSL unit.
Page 179 To return the cover to the retracted position, To put the cover in the vehicle, do the following: do the following: 1. Make sure the cover slot in the holder 1. Pull up on the cover handle to release the faces rearward with the round surface cover posts from the retaining sockets.
Page 180: Cargo Management System
Cargo Tie Downs The system has three rollers on each side. The system will be equipped with either a release lever, located in the middle handle, or a tab Your vehicle may be located on the side. These engage and disengage equipped with cargo a locator pin.
Page 181 To adjust the system from the upper guide to the To adjust the system from the lower guide to the lower guide, do the following: upper guide, do the following: 1. Squeeze and hold the release lever, or slide 1. Squeeze and hold the release lever, or slide the tab towards the inside of the vehicle, to the tab towards the inside of the vehicle, to retract the locator pin.
Page 182 The cargo management system can be pulled out and used as a table on both the upper and lower guide. To use a table, squeeze the release lever and pull the system towards you. Release the lever and pull the system until the locator pin reaches the next hole.
Page 183: Sunroof
Sunroof Your vehicle may be equipped with a power sliding sunroof. To open or close the sunroof, the ignition needs to be turned to ON, or the Retained Accessory Power (RAP) is activated. When RAP is active, the sunroof will work for 10 minutes after the ignition is turned off, or until a front door is opened.
Page 184 Manual-Open/Manual-Close: To open the Vent: To vent the sunroof, press the rear of the sunroof press and hold the rear of the driver’s passenger’s side switch. To stop the sunroof side switch until the sunroof reaches the desired partway, press the switch a second time. To close position.
Page 185 Section 3 Instrument Panel Instrument Panel Overview ......188 Exit Lighting ..........205 Reading Lamps ..........205 Hazard Warning Flashers ......190 Battery Run-Down Protection ......205 Other Warning Devices ......190 Ultrasonic Rear Parking Assist (URPA) ..206 Horn ............190 Accessory Power Outlet(s) ......209 Tilt Wheel ..........190 Ashtray(s) and Cigarette Lighter ....210 Turn Signal/Multifunction Lever ....191 Turn and Lane-Change Signals ....192...
Page 186 Section 3 Instrument Panel Passenger Airbag Status Indicator ....228 DIC Warnings and Messages .....252 Charging System Light .......230 DIC Vehicle Customization Voltmeter Gage ..........231 (With DIC Buttons) ........262 Brake System Warning Light ......231 Audio System(s) ..........271 Anti-Lock Brake System Warning Light ..233 Setting the Time (Radio with a Single ®...
Page 187 NOTES...
Page 188: Instrument Panel Overview
Instrument Panel Overview United States version shown; Canada similar...
Page 189 A. Air Outlets. See Outlet Adjustment on M. Tilt Wheel Lever. See Tilt Wheel on page 190. page 220. N. Horn. See Horn on page 190. B. Turn Signal/Multifunction Lever. See Turn O. Audio Steering Wheel Controls. See Audio Signal/Multifunction Lever on page 191. Steering Wheel Controls on page 330.
Page 190: Hazard Warning Flashers
Hazard Warning Flashers Other Warning Devices The hazard warning ﬂashers warn others. If you carry reﬂective triangles, you can set them They also let police know you have a problem. up at the side of the road about 300 feet (100 m) Your front and rear turn signal lamps will ﬂash behind your vehicle.
Page 191: Turn Signal/Multifunction Lever
Turn Signal/Multifunction Lever The lever on the left side of the steering column includes the following: The tilt steering wheel lever is located on the lower left side of the column. (Turn and Lane Change Signals): See Turn To tilt the wheel, hold the steering wheel and pull and Lane-Change Signals on page 192.
Page 192: Turn And Lane-Change Signals
Holding the turn signal lever for more than one (Windshield Washer): See Windshield second will cause the turn signals to ﬂash until you Washer on page 195. release the lever. The lever will return by itself (Rear Wiper Delay): See Rear Window when it is released.
Page 193: Headlamp High/Low-Beam Changer
Turn Signal On Chime Flash-to-Pass If your turn signal is left on for more than This feature lets you use your high-beam 3/4 of a mile (1.2 km), a chime will sound at headlamps to signal a driver in front of you that each ﬂash of the turn signal and the message you want to pass.
Page 194: Rainsense™ Ii Wipers
Rainsense™ II Wipers Heavy snow or ice can overload the wiper motor. A circuit breaker will stop the motor until it If your vehicle has Rainsense™ II windshield cools down. Clear away snow or ice to prevent wipers, the moisture sensor is located next to the an overload.
Page 195: Windshield Washer
Windshield Washer When Rainsense™ II is active, the headlamps will turn on automatically after approximately 8 wipes. The headlamps will turn off if the wiper switch is set to the delay position, and there have CAUTION: been no wipes for approximately 3 minutes or it has become light enough outside.
Page 196: Rear Window Wiper/Washer
Rear Window Wiper/Washer The button is located in the switchbank under the climate controls. CAUTION: In freezing weather, do not use your washer until the windshield is warmed. Push the heated washer ﬂuid button to activate Otherwise the washer ﬂuid can form ice the heated windshield washer ﬂuid system.
Page 197: Cruise Control
Cruise Control (Rear Wiper Wash): To turn on the rear wiper wash, push the button on the end of the turn signal/multifunction lever to spray washer ﬂuid on the rear window. The wipers will clear CAUTION: the rear window and either stop or return to your preset speed.
Page 198 ® If your vehicle has the StabiliTrak ™ system and (On/Off): This button can both activate and begins to limit wheel spin while you are using turn off the system. The indicator light is on cruise control, the cruise control will automatically when cruise control is on and turns off when ®...
Page 199 Setting Cruise Control Resuming a Set Speed Cruise control will not work if your parking brake is Suppose you set your cruise control at a desired set, or if the master cylinder brake ﬂuid level is low. speed and then you apply the brake. This shuts off the cruise control.
Page 200 Reducing Speed While Using Using Cruise Control on Hills Cruise Control How well your cruise control will work on hills depends upon your speed, load, and the To reduce your speed while using cruise control: steepness of the hills. When going up steep hills, •...
Page 201: Exterior Lamps
Exterior Lamps AUTO (Automatic): Turn the control to this position to automatically turn on the headlamps at normal brightness, together with the following: The exterior lamps • control is located on Parking Lamps the instrument panel • Instrument Panel Lights to the left of the •...
Page 202: Headlamps On Reminder
Headlamps on Reminder When it begins to get dark, the automatic headlamp system will switch from DRL to the A reminder chime will sound when your headlamps headlamps. or parking lamps are manually turned on and When you turn the headlamp switch off, the your ignition is off and a door is open.
Page 203: Fog Lamps
The system may also turn on your headlamps Your headlamps will also stay on after you exit the when driving through a parking garage, heavy vehicle. You can program this feature using the overcast weather, or a tunnel. This is normal. Driver Information Center (DIC).
Page 204: Auxiliary Roof Mounted Lamp
Auxiliary Roof Mounted Lamp Instrument Panel Brightness If your vehicle has this feature, this button includes (Instrument Panel Brightness): This feature wiring provisions for a dealer or a qualiﬁed controls the brightness of the instrument panel service center to install an auxiliary roof lamp. lights.
Page 205: Dome Lamp Override
Dome Lamp Override Reading Lamps If your vehicle has reading lamps they are located (Dome Lamp Override): Press the dome on the overhead console. override button, located next to the exterior lamps control, to keep the dome lamps off when a To turn on the reading lamps, press the button door is open.
Page 206: Ultrasonic Rear Parking Assist (Urpa)
Ultrasonic Rear Parking CAUTION: Assist (URPA) If your vehicle has the Ultrasonic Rear Parking Even with the Ultrasonic Rear Park Assist Assist (URPA) system it is designed to help you system, the driver must check carefully park while in Reverse (R). It operates only at before backing up.
Page 207 The display is located The red light in the URPA display will also be lit near the passenger side if the vehicle is in REVERSE (R). If the vehicle has rear window and can a DIC, PARKING ASSIST OFF will display. be seen by looking over URPA automatically turns back on each time the your right shoulder.
Page 208 How the System Works when Backing When the System Does Not Seem to Work Properly If the shift lever is in REVERSE (R), URPA detects objects close to the rear bumper. The If the URPA system will not activate due to a ﬁrst time an object is detected a single beep will temporary condition, the message PARKING sound.
Page 209: Accessory Power Outlet(S)
• For Driver Information Center messages related The ultrasonic sensors are not kept clean. to URPA, see DIC Warnings and Messages So, be sure to keep your vehicle’s rear on page 252. bumper free of mud, dirt, snow, ice, and slush. For cleaning instructions, see Washing Your If the bumper is damaged, your URPA system Vehicle on page 532.
Page 210: Ashtray(S) And Cigarette Lighter
Ashtray(s) and Cigarette Lighter The accessory power outlets are powered, even with the ignition off. Continuing to use power The front ashtray is located near the center of outlets while the ignition is off may cause the instrument panel or on the front console, the vehicle’s battery to run down.
Page 211: Climate Controls
Climate Controls (Bi-Level): This mode directs half of the air to the instrument panel outlets and to the ﬂoor outlets. The ﬂow can be divided between Climate Control System vent and ﬂoor outlets depending upon where the With this system you can control the heating, knob is placed between the settings.
Page 212 AUX (Auxiliary): Pressing this button will turn the (Fan): Turn the left knob clockwise or rear heating and air conditioning on. See Rear counterclockwise to increase or decrease the fan Air Conditioning and Heating System on page 221 speed. Turn the knob all the way counterclockwise or Rear Air Conditioning and Heating System to turn the front system off.
Page 213 Defogging and Defrosting In this mode, the system will automatically force outside air into your vehicle. The recirculation mode Fog on the inside of the windows is a result of cannot be selected while in the defrost mode. The high humidity (moisture) condensing on the air conditioning compressor will run automatically in cool window glass.
Page 214: Dual Automatic Climate Control System
If your vehicle has heated outside rearview mirrors, the mirrors will heat to help clear fog or frost from the surface of the mirror when the rear window defog button is pressed. Notice: Do not use anything sharp on the inside of the rear window.
Page 215 Passenger’s Side Temperature Control Automatic Operation The passenger’s temperature buttons can be AUTO (Automatic): When automatic operation is used to change the temperature of the air coming active the system will control the inside through the system on the passenger’s side of temperature, the air delivery, and the fan speed.
Page 216 2. Set the driver’s and passenger’s temperature. To avoid blowing cold air in cold weather, the system will delay turning on the fan until warm To ﬁnd your comfort setting, start with a air is available. The length of delay depends on 74°F (23°C) temperature setting and allow the engine coolant temperature.
Page 217 Manual Operation The air delivery mode setting will be displayed and the AUTO light will turn off. The fan will remain You may manually adjust the air delivery mode under automatic control. or fan speed. (Vent): This setting will deliver air to the (Fan): The buttons with the fan symbols instrument panel outlets.
Page 218 Air Conditioning (Recirculation): Press this button to turn the recirculation mode on. When the button (Air Conditioning): Press this button to turn is pressed, an indicator light will come on. the air conditioning (A/C) compressor on and This mode keeps outside air from entering the off.
Page 219 Defogging and Defrosting (Defrost): Press this button to remove fog or frost from the windshield more quickly. Fog on the inside of the windows is a result of This mode directs a portion of the air to the high humidity (moisture) condensing on the windshield and side window vents and some to cool window glass.
Page 220: Outlet Adjustment
Operation Tips If your vehicle has heated outside rearview mirrors, the mirrors will heat to help clear fog or • Keep the hood and front air inlets free of ice, frost from the surface of the mirror when the snow, or any other obstruction (such as rear window defog button is pressed.
Page 221: Rear Air Conditioning And Heating System
Rear Air Conditioning and Heating System If your vehicle has this system, the rear controls are three knobs located in the headliner. The system can be controlled from the front controls as well as the rear controls. To turn the system on, press the AUX button on the front climate control system, an indicator will be lit.
Page 222: Rear Air Conditioning And Heating System And Electronic Climate Controls
Mode Knob Rear Air Conditioning and Heating System and Electronic Climate The right knob on the control panel allows you to choose the direction of air delivery. Controls (Vent): This setting directs the air through If your vehicle has this system, the rear heat and the headliner outlets.
Page 223 +/− (Increase/Decrease Temperature): Press the + or − buttons to increase or decrease the cabin temperature. The rear control temperature display will show the temperature setting decreasing or increasing. The display will only indicate climate control functions when the system is in rear independent mode.
Page 224: Warning Lights, Gages, And Indicators
+/− (Increase/Decrease Temperature): These Warning lights come on when there may be or buttons select the temperature of the air ﬂowing into is a problem with one of your vehicle’s functions. the passenger area. Press the + button for warmer As you will see in the details on the next few air and press the −...
Page 225: Instrument Panel Cluster
Instrument Panel Cluster United States version shown. Canada similar. Your instrument cluster is designed to let you know at a glance how your vehicle is running. You will know how fast you are going, about how much fuel you have and many other things you will need to know to drive safely and economically.
Page 226: Speedometer And Odometer
Speedometer and Odometer Safety Belt Reminder Light Your speedometer lets you see your speed in When the key is turned to RUN or START, a chime both miles per hour (mph) and kilometers per will be provided for several seconds to remind hour (km/h).
Page 227: Passenger Safety Belt Reminder Light
Passenger Safety Belt Airbag Readiness Light Reminder Light There is an airbag readiness light on the instrument panel, which shows the airbag symbol. The Several seconds after the key is turned to RUN or system checks the airbag’s electrical system for START, a chime will sound for several seconds malfunctions.
Page 228: Passenger Airbag Status Indicator
Passenger Airbag Status Indicator CAUTION: Your vehicle has the passenger sensing system. Your overhead console has a passenger airbag status indicator. If the airbag readiness light stays on after you start your vehicle, it means the airbag system may not be working properly. The airbags in your vehicle may not inﬂate in a crash, or they could even inﬂate without a crash.
Page 229 If the word ON or the on symbol is lit on the Your vehicle has a rear seat that will accommodate passenger airbag status indicator, it means a rear-facing child restraint. A label on your sun that the right front passenger’s frontal airbag is visor says, “Never put a rear-facing child seat enabled (may inﬂate).
Page 230: Charging System Light
Charging System Light If the word OFF or the off symbol is lit on the airbag status indicator, it means that the passenger sensing system has turned off the right The charging system front passenger’s frontal airbag. See Passenger light will come on brieﬂy Sensing System on page 100 for more on when you turn on the this, including important safety information.
Page 231: Voltmeter Gage
Voltmeter Gage This condition is normal since the charging system is not able to provide full power at engine idle. As engine speeds are increased, this condition When your engine should correct itself as higher engine speeds is not running, but the allow the charging system to create full power.
Page 232 If the warning light comes on and a chime sounds If the light comes on while you are driving, pull off there could be a brake problem. Have your the road and stop carefully. You may notice brake system inspected right away. that the pedal is harder to push or may go closer to the ﬂoor.
Page 233: Anti-Lock Brake System Warning Light
Anti-Lock Brake System If the regular brake system warning light is not on, you still have brakes, but you do not have anti-lock Warning Light brakes. If the regular brake system warning light is also on you do not have anti-lock brakes and there With the anti-lock brake is a problem with your regular brakes.
Page 234: Stabilitrak ® Indicator Light
® StabiliTrak Indicator Light Engine Coolant Temperature Gage If equipped, this warning light should come on brieﬂy when the engine is started. If the warning light does not come on then, have it ﬁxed so it will be ready to warn you if there is a problem.
Page 235: Tire Pressure Light
Tire Pressure Light Malfunction Indicator Lamp Check Engine Light This light will come on brieﬂy when you turn Your vehicle has the ignition to RUN. a computer which monitors operation of the fuel, ignition, and emission control systems. This light will also come on when one or more of your tires are signiﬁcantly underinﬂated.
Page 236 Notice: If you keep driving your vehicle with This light will also come on during a malfunction this light on, after awhile, your emission in one of two ways: controls may not work as well, your fuel • Light Flashing — A misﬁre condition has economy may not be as good, and your engine been detected.
Page 237 If the light continues to ﬂash, when it is safe to Have you recently changed brands of fuel? do so, stop the vehicle. Find a safe place to park If so, be sure to fuel your vehicle with quality fuel. your vehicle.
Page 238: Oil Pressure Gage
LOW STOP ENGINE” message will appear in the your vehicle still does not pass the inspection Driver Information Center. See DIC Warnings for lack of OBD system readiness, your GM dealer and Messages on page 252 and Engine Oil can prepare the vehicle for inspection.
Page 239: Oil Pressure Light
Oil Pressure Light A reading in the low pressure zone may be caused by a dangerously low oil level or some other problem causing low oil pressure. Check your oil as soon as possible. CAUTION: CAUTION: Do not keep driving if the oil pressure is low.
Page 240: Security Light
Fog Lamp Light This light will come on brieﬂy when you start your engine. That is a check to be sure the light works. If it does not come on, be sure to have The fog lamps light it ﬁxed so it will be there to warn you if something will come on when goes wrong.
Page 241: Highbeam On Light
Highbeam On Light Fuel Gage This light will come on when the high-beam headlamps are in use. See Headlamp High/Low-Beam Changer on page 193. United States Canada Tow/Haul Mode Light The fuel gage, when the ignition is on, tells you about how much fuel you have left in your tank.
Page 242: Low Fuel Warning Light
Here are some situations you may experience with This light and a chime will come on when the fuel your fuel gage. None of these indicate a problem tank is low on fuel. There will also be a “FUEL with the fuel gage. LEVEL LOW”...
Page 243: Dic Operation And Displays (With Dic Buttons)
DIC Buttons If your vehicle does not have DIC buttons, see “DIC Operation and Displays (Without DIC The buttons are Buttons)” later in this section for the displays the trip/fuel, available. vehicle information, customization, DIC Operation and Displays and set/reset buttons. (With DIC Buttons) The button functions are detailed in the...
Page 244 To switch between English and metric (Vehicle Information): Press this button to measurements, see “Units” later in this section. display the oil life, units, tire pressure readings for vehicles with a Tire Pressure Monitor (TPM) Trip Odometer system, engine hours, Tire Pressure Monitor Press the trip/fuel button until TRIP displays.
Page 245 For example, if the vehicle was driven 5 miles For example, if driving in traffic and making (8 km) before it is started again, and then the frequent stops, this display may read one number, retro-active reset feature is activated, the display but if the vehicle is driven on a freeway, the will show 5 miles (8 km).
Page 246 Timer Instantaneous Economy and Displacement on Demand™ (DoD™) Indicator Press the trip/fuel button until TIMER displays. This display can be used as a timer. If your vehicle has this display, press the trip/fuel button until INST ECONOMY V8 MODE To start the timer, press the set/reset button displays.
Page 247 Vehicle Information Menu Items Remember, you must reset the OIL LIFE display yourself after each oil change. It will not reset (Vehicle Information): Press this button to itself. Also, be careful not to reset the OIL LIFE display accidentally at any time other than scroll through the following menu items: when the oil has just been changed.
Page 248 Tire Pressure Relearn Tire Positions If your vehicle has a Tire Pressure Monitor (TPM) If your vehicle has a Tire Pressure Monitor (TPM) system, the pressure for each tire can be system, after rotating the tires or after replacing viewed in the DIC. The tire pressure will be shown a tire or sensor, the system must re-learn the tire in either pounds per square inch (psi) or positions.
Page 249: (Without Dic Buttons)
4. To match additional transmitters at this time, The DIC displays trip and vehicle system repeat Step 3. information, and warning messages if a system problem is detected. Each vehicle can have a maximum of eight transmitters matched to it. If your vehicle does not have DIC buttons, you can use the trip odometer reset stem to view 5.
Page 250 Engine Hours since the ignition was last turned on and the vehicle was moving. Once the vehicle begins To display the ENGINE HOURS, place the ignition moving, the trip odometer will accumulate mileage. in LOCK or ACCESSORY, then press and hold For example, if the vehicle was driven 5 miles the trip odometer reset stem for four seconds while (8 km) before it is started again, and then the...
Page 251 Relearn Tire Positions When the remaining oil life is low, the CHANGE ENGINE OIL SOON message will appear on To access this display, the vehicle must be in the display. See “CHANGE ENGINE OIL SOON” PARK (P). If your vehicle has a Tire Pressure under DIC Warnings and Messages on Monitor (TPM) system, after rotating the tires or page 252.
Page 252: Dic Warnings And Messages
3. Press and hold the lock and unlock buttons 3. Continue to press and hold the trip odometer on the ﬁrst transmitter at the same time for reset stem to scroll through all of the available approximately 15 seconds. languages. A chime will sound indicating that the The available languages are ENGLISH transmitter is matched.
Page 253 CHECK TIRE PRESSURE Some messages cannot be cleared from the DIC display because they are more urgent. If your vehicle has a Tire Pressure Monitor (TPM) These messages require action before they can system, this message will display when the be cleared.
Page 254 If this message continues to appear, have the temperature is too hot. Stop and allow the system repaired by your GM dealer as soon vehicle to idle until it cools down. See Engine as possible to avoid damage to your engine.
Page 255 DIC, stop the vehicle as soon as possible. this message stays on, the vehicle should be See Engine Overheating on page 451 for more taken to your GM dealer for service as soon as information. possible. If the engine cooling system reaches unsafe...
Page 256 RUN, this message will display and a Check your oil as soon as possible and have chime will sound. Turn off the vehicle and check your vehicle serviced by your GM dealer. the liftgate and liftglass. Restart the vehicle See Engine Oil on page 437.
Page 257 If there is a problem with the airbag system, this this message will display. The battery needs to message will display. Have your GM dealer inspect be replaced in the transmitter. See “Battery the system for problems. See Airbag Readiness Replacement”...
Page 258 SERVICE BRAKES SOON it means there is a problem. You should see your GM dealer for service. The vehicle is safe to If there is a problem with the brake system, this drive, however, you do not have the beneﬁt of message will display.
Page 259 If your vehicle has StabiliTrak , this message will ® to take the vehicle to your GM dealer before display when you turn off StabiliTrak , or when ® turning off the engine. See PASS-Key...
Page 260 See your If your vehicle has a Tire Pressure Monitor (TPM) GM dealer. system, this message will display when the • The message will also appear if the vehicle system is re-learning the tire positions on your is shifted into 4LO.
Page 261 TRACTION CONTROL OFF Stop the vehicle and let it idle to allow the transmission to cool. This message will clear and ® If your vehicle has StabiliTrak , this message the chime will stop when the ﬂuid temperature will display when the traction control system reaches a safe level.
Page 262: Dic Vehicle Customization (With Dic Buttons)
DIC Vehicle Customization Entering the Feature Settings Menu (With DIC Buttons) 1. Turn the ignition on and place the vehicle in PARK (P). Your vehicle may have customization capabilities 2. Press the customization button to scroll that allow you to program certain features to through the available customizable options.
Page 263 AUTO DOOR LOCK Press the customization button until the DISPLAY LANGUAGE screen appears on the DIC display. This feature allows you to select when the Press the set/reset button once to access the vehicle’s doors will automatically lock. See settings for this feature. Then press the Programmable Automatic Door Locks on page 121 customization button to scroll through the for more information.
Page 264 AUTO DOOR UNLOCK feature. The current setting will remain. Choose one of the available settings and press This feature allows you to select whether or not the set/reset button while it is displayed on the DIC to turn off the automatic door unlocking feature. to select it.
Page 265 HORN ONLY: The horn will sound on the second You will not receive feedback when unlocking the press of the lock button on the remote keyless vehicle with the remote keyless entry transmitter entry transmitter. if the doors are open. See Remote Keyless Entry System Operation on page 113 for more HORN &...
Page 266 DELAY DOOR LOCK NO CHANGE: No change will be made to this feature. The current setting will remain. This feature allows you to select whether or not Choose one of the available settings and press the locking of the vehicle’s doors and liftgate the set/reset button while it is displayed on the DIC will be delayed.
Page 267 NO CHANGE: No change will be made to this The lights will remain on for 20 seconds or until feature. The current setting will remain. the lock button on the remote keyless entry transmitter is pressed, or the vehicle is no longer Choose one of the available settings and press off.
Page 268 NO CHANGE: No change will be made to this BOTH MIRRORS: The driver’s and passenger’s feature. The current setting will remain. outside mirrors will be tilted down when the vehicle is shifted into REVERSE (R). Choose one of the available settings and press the set/reset button while it is displayed on the NO CHANGE: No change will be made to this DIC to select it.
Page 269 The automatic easy exit seat movement will only ON: The driver’s seat will automatically move to occur one time after the key is removed from the stored driving position when the unlock the ignition. If the automatic movement has button on the remote keyless entry transmitter is already occurred, and you put the key back in the pressed.
Page 270 EXIT FEATURE SETTINGS ON (default): The remote start feature will be enabled. This feature allows you to exit the feature settings menu. NO CHANGE: No change will be made to this feature. The current setting will remain. Press the customization button until PRESS Choose one of the available settings and press EXIT FEATURE SETTINGS appears in the DIC the set/reset button while it is displayed on the DIC...
Page 271: Audio System(S)
Audio System(s) CAUTION: Determine which radio your vehicle has and then read the pages following to familiarize yourself This system provides you with a far greater with its features. access to audio stations and song listings. Driving without distraction is a necessity for a Giving extended attention to entertainment safer driving experience.
Page 272 Here are some ways in which you can help avoid Added sound equipment may interfere with distraction while driving. the operation of your vehicle’s engine, radio, or other systems, and even damage them. While your vehicle is parked: Your vehicle’s systems may interfere with •...
Page 273: Setting The Time (Radio With A Single Cd Player)
Setting the Time (Radio with a Changing the Time and Date Default Settings Single CD Player) You can change the time default setting from If your vehicle has a radio with a single CD player, 12 hours to 24 hours or change the date default the radio will have a clock button for setting the setting from month/day/year to day/month/year.
Page 274: Setting The Time
Setting the Time (Radio with a Changing the Time and Date Default Settings Six-Disc CD Player) You can change the time default setting from If your vehicle has a radio with a six-disc CD 12 hours to 24 hours or change the date default player, the radio will have a MENU button instead setting from month/day/year to day/month/year.
Page 275: Radio With Cd (Mp3)
Radio with CD (MP3) This system relies upon receiving speciﬁc information from these stations and will only work when the information is available. While the radio is tuned to an FM-RDS station, the station name or call letters will appear on the display. In rare cases, a radio station may broadcast incorrect information that will cause the radio features to work improperly.
Page 276 Playing the Radio The display will time out after approximately 10 seconds. Each higher setting allows (Power/Volume): Press this knob to turn the for more radio volume compensation at faster system on and off. vehicle speeds. Turn this knob clockwise or counterclockwise to Finding a Station increase or decrease the volume.
Page 277 Press the FAV button to go through up to (Information) (XM™ Satellite Radio Service, six pages of favorites, each having six favorite MP3, and RDS Features): Press the information stations available per page. Each page of favorites button to display additional text information can contain any combination of AM, FM, or related to the current FM-RDS or XM™...
Page 278 3. Select the desired number of favorites pages To quickly adjust bass, midrange, or treble to the by pressing the pushbutton located below the middle position, press the pushbutton positioned displayed page numbers. under the BASS, MID, or TREB label for more than two seconds.
Page 279 Adjusting the Speakers (Balance/Fade) Finding a Category (CAT) Station BAL/FADE (Balance/Fade): To adjust balance CAT (Category): The CAT button is used to ﬁnd or fade, press the tune knob until the speaker XM™ stations when the radio is in the XM™ control labels appear on the display.
Page 280 Radio Messages Undesired XM™ categories can be removed through the setup menu. To remove an undesired Calibration Error: The audio system has been category, perform the following: calibrated for your vehicle from the factory. If 1. Press the MENU button to display the radio Calibration Error appears on the display, it means setup menu.
Page 281 Playing a CD(s) (Six-Disc CD Player) If the ignition or radio is turned off, with a CD in the player, it will stay in the player. When the LOAD : Press this button to load CDs into ignition or radio is turned on, the CD will start playing where it stopped, if it was the last the CD player.
Page 282 Notice: If you add any label to a CD, insert For the Six-Disc CD player, press and hold the more than one CD into the slot at a time, eject button for two seconds to eject all discs. or attempt to play scratched or damaged CDs, (Tune): Turn this knob to select tracks on the you could damage the CD player.
Page 283 RDM (Random): With random, you can listen to BAND: Press this button to listen to the radio the tracks in random, rather than sequential when a CD is playing. The CD will remain safely order, on one CD or all CDs in a six-disc CD inside the radio for future listening.
Page 284 Compressed Audio • Avoid subfolders. The system can support up to 8 subfolders deep, however, keep the total The radio will also play discs that contain both number of folders to a minimum in order to uncompressed CD audio (.CDA ﬁles) and reduce the complexity and confusion in trying MP3 ﬁles.
Page 285 Empty Directory or Folder You can change playlists by using the previous and next folder buttons, the tuner knob, or the seek If a root directory or a folder exists somewhere buttons. You can also play an MP3 CD-R that was in the ﬁle structure that contains only folders/ recorded using no ﬁle folders.
Page 286 Order of Play File System and Naming Tracks recorded to the CD-R will be played in Preprogrammed Playlists the following order: You can access preprogrammed playlists that • Play will begin from the ﬁrst track in the ﬁrst were created using WinAmp™, MusicMatch™, playlist and will continue sequentially through or Real Jukebox™...
Page 287 The CD player can play the smaller 3 inch (8 cm) Do not add any label to a CD, it could get caught single CD-Rs with an adapter ring. Full-size in the CD player. If a CD is recorded on a CD-Rs and the smaller CD-Rs are loaded in the personal computer and a description label is same manner.
Page 288 © ¨ RDM (Random): With random, you can listen to SEEK : Press the left SEEK arrow to go to MP3 ﬁles on the CD-R in random, rather than the start of the current MP3 ﬁle, if more than ten sequential order, on one CD-R or all discs in a seconds have played.
Page 289 The radio may begin playing while it is scanning Once all songs from that album are played, the the disc in the background. When the scan is player will move to the next album in alphabetic ﬁnished, the CD-R will begin playing again. order on the CD-R and begin playing MP3 ﬁles from that album.
Page 290 CD Messages Using the Auxiliary Input Jack Your radio system has an auxiliary input jack CHECK DISC: If this message appears on the located on the lower right side of the faceplate. display and/or the CD comes out, it could be This is not an audio output;...
Page 291: Radio With Cd And Dvd (Mp3)
Radio with CD and DVD (MP3) BAND: Press this button to listen to the radio when a portable audio device is playing. The portable audio device will continue playing, so you may want to stop it or turn it off. CD/AUX (CD/Auxiliary): Press this button to play a CD when a portable audio device is playing.
Page 292 Radio Data System (RDS) Playing the Radio The audio system has a Radio Data System (Power/Volume): Press this knob to turn the (RDS). The RDS feature is available for use only system on and off. on FM stations that broadcast RDS information. Turn this knob clockwise to increase or This system relies upon receiving speciﬁc counterclockwise to decrease the volume.
Page 293 Finding a Station Continue pressing the information button to highlight the desired label, or press the pushbutton BAND: Press this button to switch between AM, positioned under any one of the labels and the FM, or XM™ (if equipped). The display will information about that label will be displayed.
Page 294 Each page of favorites can contain any 4. Press the FAV button, or let the menu time combination of AM, FM, or XM™ (if equipped) out, to return to the original main radio stations. To store a station as a favorite, perform screen showing the radio station frequency the following steps: labels and to begin the process of...
Page 295 EQ (Equalization): Press this button to choose To quickly adjust both the balance and fade to bass and treble equalization settings designed for the middle position at one time, press the different types of music. Your choices are pop, tune knob for more than two seconds until you rock, country, talk, jazz, and classical.
Page 296 3. Rotate the tune knob, press the buttons below Removed categories can be restored by pressing the right or left arrows displayed, or press the the pushbutton under the Add label when a right or left SEEK buttons to go to the next removed category is displayed or by pressing the or previous XM™...
Page 297 Playing a CD (In Either the DVD or The CD player can play the smaller 3 inch (8 cm) single CDs with an adapter ring. Full-size CDs CD Slot) and the smaller CDs are loaded in the same Insert a CD partway into the slot, label side up. manner.
Page 298 Notice: If you add any label to a CD, insert If loading and reading of a CD cannot be more than one CD into the slot at a time, or completed, such as unknown format, etc., and the attempt to play scratched or damaged CDs, you disc fails to eject, press and hold the DVD eject could damage the CD player.
Page 299 Press the right SEEK arrow to go to the next BAND: Press this button to listen to the radio track. If either SEEK arrow is held, or pressed when a CD or DVD is playing. The CD or DVD will multiple times, the player will continue moving remain safely inside the radio for future listening backward or forward through the tracks on the CD.
Page 300 Audio Output Using an MP3/WMA CD-R or CD-RW Disc Only one audio source can be heard through the speakers at one time. An audio source Compressed Audio or Mixed Mode Discs is deﬁned as DVD slot, CD slot, XM™, FM/AM, The radio will also play discs that contain both Front Aux Jack, or Rear Aux Jack.
Page 301 • Root Directory Create a folder structure that makes it easy to ﬁnd songs while driving. Organize songs by The root directory of the CD-R is treated as a folder. albums using one folder for each album. If the root directory has compressed audio ﬁles, Each folder or album should contain 18 songs the directory will be displayed as F1 ROOT.
Page 302 When the CD-R contains only playlists and When play enters a new folder, the display will compressed audio ﬁles, but no folders, all ﬁles not automatically show the new folder name unless will be located under the root folder. The you have chosen the folder mode as the default folder down and the folder up buttons will search display.
Page 303 Playing an MP3 (In Either the DVD or The CD player can play the smaller 3 inch (8 cm) single CD-Rs with an adapter ring. Full-size CD Slot) CD-Rs and the smaller CD-Rs are loaded in the Insert a CD-R partway into either the top or same manner.
Page 304 Notice: If you add any label to a CD, insert If loading and reading of a CD cannot be more than one CD into the slot at a time, or completed, such as unknown format, etc., and the attempt to play scratched or damaged CDs, you disc fails to eject, press and hold the DVD eject could damage the CD player.
Page 305 © ¨ RDM (Random): With random, you can listen to SEEK : Press the left SEEK arrow to go MP3 ﬁles on the CD-R in random, rather than to the start of the current MP3 ﬁle, if more sequential order. To play MP3 ﬁles from the CD-R than ﬁve seconds have played.
Page 306 If you want to listen to MP3 ﬁles by another artist, DVD/CD AUX (Auxiliary): Press this button to press the pushbutton located below either cycle through DVD, CD, or Auxiliary when listening arrow button. You will go to the next or previous to the radio.
Page 307 CD Messages If any error occurs repeatedly or if an error cannot be corrected, contact your dealer. If the If these messages appear on the display and/or radio displays an error message, write it down the CD comes out, it could be for one of the and provide it to your dealer when reporting following reasons: the problem.
Page 308 Playing a DVD A single press turns the radio off, a press and hold for more than two seconds turns off the entire DVD/CD AUX (Auxiliary): Press this button to radio and rear seat entertainment system and cycle through DVD, CD, or Auxiliary when listening starts the parental control feature which prevents to the radio.
Page 309 ¨ If loading and reading of a CD cannot be SEEK (Next Track/Chapter): Press this button completed, such as unknown format, etc., and the to go to the next track or chapter. This button disc fails to eject, press and hold the CD eject may not work when the DVD is playing the button for more than ﬁve seconds to force the disc copyright information or the previews.
Page 310 Some DVDs will begin playing after the previews (Return): Press this button to exit the current have ﬁnished, although there may be a delay of up active menu and return to the previous menu. to 30 seconds. If the DVD does not begin playing This button will operate only when a DVD is the movie automatically, press the pushbutton playing and a menu is active.
Page 311 Inserting a Disc (Play/Pause): Press either the play or pause icon displayed on the radio system, To play a disc, gently insert the disc, with the label to toggle between pausing or restarting playback side up, into the loading slot. The DVD player of a DVD.
Page 312 DVD Radio Error Messages To resume DVD playback, press the play/pause button on the remote control, or press the Player Error: This message is displayed when pushbutton located under the play/pause symbol there are disc load or eject problems. tag displayed on the radio. The DVD should resume play from where it last stopped if the disc Disc Format Error: This message will be has not been ejected and the stop button has...
Page 313 To use a portable audio player, connect a DVD/CD AUX (CD/Auxiliary): Press this button 3.5 mm (1/8 inch) cable to the radio’s front to cycle through DVD, CD, or Auxiliary when auxiliary input jack. When a device is connected, listening to the radio. The DVD/CD text label and the radio automatically begins playing audio a message showing track or chapter number from the device over the vehicle speakers.
Page 314: Xm Radio Messages
XM Radio Messages Radio Display Message Condition Action Required XL (Explicit Language XL on the radio display, These channels, or any others, can be blocked at a Channels) after the channel name, customer’s request, by calling 1-800-852-XMXM (9696). indicates content with explicit language.
Page 315 Radio Display Message Condition Action Required No CAT Info Category Name No category information is available at this time on this not available channel. The system is working properly. No Information No Text/Informational No text or informational messages are available at this time message available on this channel.
Page 316: Navigation/Radio System
Navigation/Radio System Before You Drive The RSE is designed for rear seat passengers Your vehicle may have a navigation radio system. only. The driver cannot safely view the video The navigation system has built-in features screen while driving and should not try to do so. intended to minimize driver distraction.
Page 317 Headphones To enable Parental Control press and hold the radio power button for more than 2 seconds. If on, the radio, video screen, and RSA will turn off. If a DVD and/or CD is playing, it will be stopped. A “padlock” icon or a text message may be displayed on the radio display depending on which radio you have, while Parental Control is on.
Page 318 Push the power button to turn on the headphones. For optimal audio performance, the headphones An indicator light located on the headphones must be worn correctly. The symbol L (Left) will illuminate. If the light does not illuminate, the will appear on the upper left side, above the ear batteries may need to be replaced.
Page 319 Battery Replacement Audio/Video (A/V) Jacks To change the batteries, do the following: 1. Turn the screw with a coin or screw driver to loosen, then slide open the battery door located on the left side of the headphones. 2. Replace the two AAA batteries in the compartment.
Page 320 How to Change the Video Format When in The A/V jacks are color coded to match typical home entertainment system equipment. The the Auxiliary Mode yellow jack is for the video input. The white jack The auxiliary input video format is preset to NTSC. is for the left audio input.
Page 321 Video Screen The RSE system will always transmit the audio signal to the wireless headphones, if there is audio The video screen is located in the RSE overhead available. See “Headphones” earlier in this console. section for more information. To use the video screen, do the following: The DVD player is capable of outputting audio to the wired headphone jacks on the RSA system, 1.
Page 322 Remote Control Remote Control Buttons To use the remote control, aim it at the transmitter window at the rear of the RSE overhead console and press the desired button. Direct sunlight or very bright light may affect the ability of the RSE transmitter to receive signals from the remote control.
Page 323 (Title): Press this button to return the DVD to (Return): Press this button to exit the current the main menu of the DVD. This function may active menu and return to the previous menu. vary for each disc. This button will operate only when the display menu or a DVD menu is active.
Page 324 (Previous Track/Chapter): Press this button (Audio): Press this button to change audio to return to the start of the current track or chapter. tracks on DVDs that have this feature when Press this button again to go to the previous the DVD is playing.
Page 325 (Clear): Press this button within three seconds Problem Recommended Action after inputting a numeric selection, to clear all No power. The ignition might not numeric inputs. be in on or accessory. 10 (Double Digit Entries): Press this button to The picture does not ﬁll the Check the display screen.
Page 326 DVD Display Error Messages Problem Recommended Action The DVD display error message depends on The auxiliary source is Check that the DVD running but there is no player is in the auxiliary which radio you have. The video screen may picture or sound.
Page 327: Rear Seat Audio (Rsa)
DVD Distortion Rear Seat Audio (RSA) Video distortion may occur when operating cellular This feature allows rear seat passengers to listen phones, scanners, CB radios, Global Position to and control any of the music sources: radio, Systems (GPS)*, two-way radios, mobile fax, or CDs, DVDs, or other auxiliary sources.
Page 328 © ¨ (Seek): When listening to FM, AM, or XM (if equipped), press the seek up or the seek down arrow to go to the next or the previous station or channels and stay there. This function is inactive, with some radios, if the front seat passengers are listening to the radio.
Page 329: Theft-Deterrent Feature
Theft-Deterrent Feature PROG (Program): Press this button to go to the next preset radio station or channel set on the ® THEFTLOCK is designed to discourage theft main radio. This function is inactive, with of your vehicle’s radio. The feature works some radios, if the front seat passengers are automatically by learning a portion of the Vehicle listening to the radio.
Page 330: Audio Steering Wheel Controls
Audio Steering Wheel Controls (Mute/Voice Recognition): Press and release this button to silence the vehicle speakers only. The audio of the wireless and wired headphones, If your vehicle has audio if your vehicle has these features, will not be steering wheel controls, muted.
Page 331: Radio Reception
SRCE (Source): Press this button to switch between the radio (AM, FM), XM (if equipped), The range for most AM stations is greater than for CD, and if your vehicle has these features, DVD, FM, especially at night. The longer range can front auxiliary, and rear auxiliary.
Page 332: Care Of Your Cds And Dvds
XM™ Satellite Radio Service Do not touch the bottom side of a CD while handling it; this could damage the surface. Pick up XM™ Satellite Radio Service gives digital radio CDs by grasping the outer edges or the edge of reception from coast-to-coast in the 48 contiguous the hole and the outer edge.
Page 333: Xm™ Satellite Radio Antenna System
XM™ Satellite Radio Antenna Notice: Using a razor blade or sharp object to clear the inside of the rear side windows System may affect radio reception or damage the rear window defogger. Repairs would not The XM™ Satellite Radio antenna is located on be covered by your warranty.
Page 334 NOTES...
Page 335 Section 4 Driving Your Vehicle Your Driving, the Road, and Highway Hypnosis ........377 Hill and Mountain Roads ......378 Your Vehicle ..........336 Winter Driving ..........380 Defensive Driving ........336 If Your Vehicle is Stuck in Sand, Mud, Drunken Driving .........337 Ice, or Snow ...........384 Control of a Vehicle ........340 Rocking Your Vehicle to Get It Out ....385 Braking ............340...
Page 336: Your Driving, The Road, And Your Vehicle
Your Driving, the Road, and CAUTION: Your Vehicle Defensive driving really means “Be ready Defensive Driving for anything.” On city streets, rural roads, The best advice anyone can give about driving is: or expressways, it means “Always expect Drive defensively. the unexpected.”...
Page 337: Drunken Driving
Drunken Driving Many adults — by some estimates, nearly half the adult population — choose never to drink alcohol, Death and injury associated with drinking and so they never drive after drinking. For persons driving is a national tragedy. It is the number one under 21, it is against the law in every U.S.
Page 338 According to the American Medical Association, a It is the amount of alcohol that counts. For example, 180 lb (82 kg) person who drinks three 12 ounce if the same person drank three double martinis (355 ml) bottles of beer in an hour will end up with (3 ounces or 90 ml of liquor each) within an hour, a BAC of about 0.06 percent.
Page 339 approaching 0.05 percent, and that the effects are There is something else about drinking and driving worse at night. All drivers are impaired at BAC that many people do not know. Medical research levels above 0.05 percent. Statistics show that the shows that alcohol in a person’s system can make chance of being in a collision increases sharply crash injuries worse, especially injuries to the...
Page 340: Control Of A Vehicle
System on page 343. And, of course, actual stopping distances vary greatly with the surface of the road, whether it is Adding non-GM accessories can affect your pavement or gravel; the condition of the road, vehicle’s performance. See Accessories and whether it is wet, dry, or icy;...
Page 341: Anti-Lock Brake System (Abs)
See Anti-Lock Brake Adding non-GM accessories can affect your System Warning vehicle’s performance. See Accessories and Light on page 233. Modiﬁcations on page 424.
Page 342 ABS can change the brake pressure faster than any driver could. The computer is programmed to make the most of available tire and road conditions. This can help you steer around the obstacle while braking hard. Let us say the road is wet and you are driving safely.
Page 343: Braking In Emergencies
Locking Rear Axle Remember: ABS does not change the time you need to get your foot up to the brake pedal If your vehicle has this feature, your locking rear or always decrease stopping distance. If you get axle can give you additional traction on snow, mud, too close to the vehicle in front of you, you will not ice, sand or gravel.
Page 344 ® If the system fails to turn on or activate, the The StabiliTrak light ® StabiliTrak light along with one of the following will ﬂash on the messages will be displayed on the Driver instrument panel cluster Information Center (DIC) (TRACTION CONTROL when the system is OFF, SERVICE TRACTION CONTROL, both on and activated.
Page 345 ® Traction control and StabiliTrak can be turned on It is recommended to leave the system on for ® by pressing and releasing the StabiliTrak button normal driving conditions, but it may be necessary if both systems were previously off, if not to turn the system off if your vehicle is stuck in automatically shut off for any other reason.
Page 346 Traction Control Operation The traction control system may activate on dry or rough roads or under conditions such as The traction control system is part of the heavy acceleration while turning or abrupt ® StabiliTrak system. Traction control limits wheel upshifts/downshifts of the transmission.
Page 347: Steering
Adding non-GM accessories can affect your speed. While you are in a curve, speed is the one vehicle’s performance. See Accessories and factor you can control.
Page 348 Steering in Emergencies There are times when steering can be more effective than braking. For example, you come over a hill and ﬁnd a truck stopped in your lane, or a car suddenly pulls out from nowhere, or a child darts out from between parked cars and stops right in front of you.
Page 349: Off-Road Recovery
Off-Road Recovery Passing You may ﬁnd that your right wheels have dropped The driver of a vehicle about to pass another on a off the edge of a road onto the shoulder while you two-lane highway waits for just the right moment, are driving.
Page 350 • A broken center line usually indicates it is all If other vehicles are lined up to pass a slow right to pass, providing the road ahead is vehicle, wait your turn. But take care that clear. Never cross a solid line on your side of someone is not trying to pass you as you pull the lane or a double solid line, even if the out to pass the slow vehicle.
Page 351: Loss Of Control
Loss of Control A cornering skid is best handled by easing your foot off the accelerator pedal. Let us review what driving experts say about what ® Remember: StabiliTrak helps avoid only the happens when the three control systems — brakes, ®...
Page 352: Off-Road Driving
Off-Road Driving While driving on a surface with reduced traction, try your best to avoid sudden steering, This off-road guide is for vehicles that have acceleration, or braking, including reducing four-wheel drive or all-wheel drive. Also, see vehicle speed by shifting to a lower gear. Braking on page 340.
Page 353 Off-road driving involves some new skills. And that When you are back on roads, though, be sure to is why it is very important that you read this replace the air dam. guide. You will ﬁnd many driving tips and Notice: Operating your vehicle for extended suggestions.
Page 354 Before You Go Off-Roading Loading Your Vehicle for Off-Road Driving There are some things to do before you go out. For example, be sure to have all necessary maintenance and service work done. Check to CAUTION: make sure all underbody shields, if the vehicle has them, are properly attached.
Page 355 Environmental Concerns CAUTION: (Continued) Off-road driving can provide wholesome and satisfying recreation. However, it also raises • Heavy loads on the roof raise the environmental concerns. We recognize these vehicle’s center of gravity, making it concerns and urge every off-roader to follow these more likely to roll over.
Page 356 Traveling to Remote Areas Tune your senses to different kinds of signals. Your eyes, for example, need to constantly sweep It makes sense to plan your trip, especially when the terrain for unexpected obstacles. Your ears going to a remote area. Know the terrain and need to listen for unusual tire or engine sounds.
Page 357 Surface Obstacles: Unseen or hidden obstacles can be hazardous. A rock, log, hole, rut, or CAUTION: bump can startle you if you are not prepared for them. Often these obstacles are hidden by When you are driving off-road, bouncing grass, bushes, snow, or even the rise and fall of and quick changes in direction can easily the terrain itself.
Page 358 Driving on Off-Road Hills Because you will be on an unpaved surface, it is especially important to avoid sudden acceleration, Off-road driving often takes you up, down, or sudden turns, or sudden braking. across a hill. Driving safely on hills requires good In a way, off-road driving requires a different kind of judgment and an understanding of what your alertness from driving on paved roads and...
Page 359 Approaching a Hill • Are there obstructions on the hill that can block your path, such as boulders, trees, logs, When you approach a hill, you need to decide if it or ruts? is one of those hills that is just too steep to •...
Page 360 Driving Uphill • Ease up on your speed as you approach the top of the hill. Once you decide you can safely drive up the hill, • Attach a ﬂag to the vehicle to make you more you need to take some special steps. visible to approaching traffic on trails or hills.
Page 361 • If your engine has stopped running, you will What should I do if my vehicle stalls, need to restart it. With the brake pedal or is about to stall, and I cannot make it pressed and the parking brake still applied, up the hill? shift the transmission to PARK (P) and restart If this happens, there are some things you...
Page 362 Here are some things you must not do if you stall, or are about to stall, when going up a hill. CAUTION: (Continued) • Never attempt to prevent a stall by shifting You or someone else could be injured. into NEUTRAL (N) to rev-up the engine If you are going to leave your vehicle, and regain forward momentum.
Page 363 • Are there hidden surface obstacles? Ruts? Suppose, after stalling, I try to back down Logs? Boulders? the hill and decide I just cannot do it. What should I do? • What is at the bottom of the hill? Is there a hidden creek bank or even a river bottom Set the parking brake, put your transmission with large rocks?
Page 364 Are there some things I should not do Am I likely to stall when going downhill? when driving down a hill? It is much more likely to happen going Yes! These are important because if you uphill. But if it happens going downhill, here is ignore them you could lose control and what to do.
Page 365 Driving Across an Incline • Hidden obstacles can make the steepness of the incline even worse. If you drive across a Sooner or later, an off-road trail will probably go rock with the uphill wheels, or if the downhill across the incline of a hill. If this happens, wheels drop into a rut or depression, your you have to decide whether to try to drive across vehicle can tilt even more.
Page 366 What if I am driving across an incline that is not too steep, but I hit some loose gravel and start to slide downhill. What should I do? If you feel your vehicle starting to slide sideways, turn downhill. This should help straighten out the vehicle and prevent the side slipping.
Page 367 Driving in Mud, Sand, Snow or Ice Hard packed snow and ice offer the worst tire traction. On these surfaces, it is very easy to lose When you drive in mud, snow, or sand, your control. On wet ice, for example, the traction is wheels will not get good traction.
Page 368 Driving in Water CAUTION: Heavy rain can mean ﬂash ﬂooding, and ﬂood waters demand extreme caution. Driving through rushing water can be Find out how deep the water is before you drive dangerous. Deep water can sweep your through it. If it is deep enough to cover your wheel hubs, axles or exhaust pipe, do not try it —...
Page 369: Driving At Night
After Off-Road Driving Driving at Night Remove any brush or debris that has collected on Night driving is more dangerous than day driving. the underbody, chassis, or under the hood. One reason is that some drivers are likely to These accumulations can be a ﬁre hazard. be impaired —...
Page 370 No one can see as well at night as in the daytime. Keep the windshield and all the glass on your But as we get older these differences increase. vehicle clean — inside and out. Glare at night is A 50-year-old driver may require at least twice as made much worse by dirt on the glass.
Page 371: Driving In Rain And On Wet Roads
Driving in Rain and on Wet Roads It is always wise to go slower and be cautious if rain starts to fall while you are driving. The surface may get wet suddenly when your reﬂexes are tuned for driving on dry pavement. The heavier the rain, the harder it is to see.
Page 372 Hydroplaning CAUTION: Hydroplaning is dangerous. So much water can build up under your tires that they can actually ride on the water. This can happen if the road is wet Wet brakes can cause accidents. They will enough and you are going fast enough. When your not work as well in a quick stop and may vehicle is hydroplaning, it has little or no contact cause pulling to one side.
Page 373 Driving Through Deep Standing Water CAUTION: (Continued) Notice: If you drive too quickly through deep puddles or standing water, water can As little as six inches of ﬂowing water come in through your engine’s air intake and can carry away a smaller vehicle. If this badly damage your engine.
Page 374: City Driving
City Driving Here are ways to increase your safety in city driving: • Know the best way to get to where you are going. Get a city map and plan your trip into an unknown part of the city just as you would for a cross-country trip.
Page 375: Freeway Driving
Freeway Driving The most important advice on freeway driving is: Keep up with traffic and keep to the right. Drive at the same speed most of the other drivers are driving. Too-fast or too-slow driving breaks a smooth traffic ﬂow. Treat the left lane on a freeway as a passing lane.
Page 376: Before Leaving On A Long Trip
Of course, you will ﬁnd experienced and able exit, do not, under any circumstances, stop and service experts in GM dealerships all across back up. Drive on to the next exit. North America. They will be ready and willing to The exit ramp can be curved, sometimes quite help if you need it.
Page 377: Highway Hypnosis
• There is something about an easy stretch of road Lamps: Are they all working? Are the with the same scenery, along with the hum of the lenses clean? tires on the road, the drone of the engine, and the •...
Page 378: Hill And Mountain Roads
Hill and Mountain Roads If you drive regularly in steep country, or if you are planning to visit there, here are some tips that can make your trips safer and more enjoyable. See Off-Road Driving on page 352 for information about driving off-road.
Page 379 • Know how to go uphill. You may want to shift down to a lower gear. The lower gears help CAUTION: cool your engine and transmission, and you can climb the hill better. Coasting downhill in NEUTRAL (N) or with •...
Page 380: Winter Driving
Winter Driving Here are some tips for winter driving: • Have your vehicle in good shape for winter. • You may want to put winter emergency supplies in your vehicle. Also see Tires on page 484. Include an ice scraper, a small brush or broom, a supply of windshield washer ﬂuid, a rag, some winter outer clothing, a small shovel, a ﬂashlight, a red cloth, and a couple of reﬂective...
Page 381 Driving on Snow or Ice What is the worst time for this? Wet ice. Very cold snow or ice can be slick and hard to drive on. Most of the time, those places where the tires But wet ice can be even more trouble because it meet the road probably have good traction.
Page 382 If You Are Caught in a Blizzard Your Anti-Lock Brake System (ABS) improves your vehicle’s stability when you make a hard stop If you are stopped by heavy snow, you could be in on a slippery road. Even though you have ABS, a serious situation.
Page 383 CAUTION: Snow can trap exhaust gases under your vehicle. This can cause deadly CO (carbon monoxide) gas to get inside. CO could overcome you and kill you. You cannot see it or smell it, so you might not know it is in your vehicle. Clear away snow from around the base of your vehicle, especially any that is blocking your exhaust pipe.
Page 384: If Your Vehicle Is Stuck In Sand, Mud, Ice, Or Snow
If Your Vehicle is Stuck in Sand, Run your engine only as long as you must. This saves fuel. When you run the engine, make it Mud, Ice, or Snow go a little faster than just idle. That is, push the accelerator slightly.
Page 385: Rocking Your Vehicle To Get It Out
Notice: Spinning your wheels can destroy Release the accelerator pedal while you shift, and parts of your vehicle as well as the tires. If you press lightly on the accelerator pedal when the spin the wheels too fast while shifting your transmission is in gear.
Page 386: Recovery Hooks
Recovery Hooks Your vehicle may have recovery hooks at the front of the vehicle. You may need to use them if you are stuck off-road and need to be pulled to some place where you can continue driving. CAUTION: These hooks, when used, are under a lot of force.
Page 387: Loading Your Vehicle
Loading Your Vehicle CAUTION: It is very important to know how much weight your vehicle can carry. This weight is called the vehicle capacity weight and includes the Do not load your vehicle any heavier than weight of all occupants, cargo, and all the Gross Vehicle Weight Rating (GVWR), nonfactory-installed options.
Page 388 Tire and Loading Information Label The Tire and Loading Information label also shows the size of the original equipment tires (C) and the recommended cold tire inﬂation pressures (D). For more information on tires and inﬂation see Tires on page 484 and Inﬂation - Tire Pressure on page 492.
Page 389 4. The resulting ﬁgure equals the available amount of cargo and luggage load capacity. For example, if the “XXX” amount equals 1400 lbs and there will be ﬁve 150 lb passengers in your vehicle, the amount of available cargo and luggage load capacity is 650 lbs (1400 −...
Page 390 Example 2 Example 3 Item Description Total Item Description Total Vehicle Capacity Weight Vehicle Capacity Weight 1,000 lbs (453 kg) 1,000 lbs (453 kg) for Example 2 = for Example 3 = Subtract Occupant Subtract Occupant Weight 150 lbs 750 lbs (136 kg) Weight 200 lbs 1,000 lbs (453 kg) (68 kg) ×...
Page 391 Certiﬁcation/Tire Label To ﬁnd out the actual loads on your front and rear axles, you need to go to a weigh station and weigh your vehicle. Your dealer can help you with this. Be sure to spread out your load equally on both sides of the centerline.
Page 392 Notice: Overloading your vehicle may cause damage. Repairs would not be covered by your CAUTION: warranty. Do not overload your vehicle. The label will help you decide how much cargo Things you put inside your vehicle can and installed equipment your truck can carry. strike and injure people in a sudden stop Using heavier suspension components to or turn, or in a crash.
Page 393: Adding A Snow Plow Or Similar Equipment
Adding a Snow Plow or Similar How heavy can a snow plow safely be? Equipment The plow your vehicle can carry depends on many things, such as: Before installing a snow plow on your vehicle, here are some things you will need to know: •...
Page 394 Here are some guidelines for safely carrying a What is front axle reserve capacity, and snow plow on your vehicle: how do I calculate it? • Make sure the weight on the front and rear Front axle reserve capacity is the difference axles does not exceed the axle rating for each.
Page 395 In order to calculate the amount of weight any Where: front accessory, such as a snow plow, is adding to W = Weight of added accessory the front axle, use the following formula: A = Distance that the accessory is in front of the front axle W.B.
Page 396 What if I want to add heavier equipment to my vehicle? CAUTION: You can add heavier equipment on the front of the vehicle if you compensate for it by On some vehicles that have certain front carrying fewer passengers, less cargo, or by mounted equipment, such as a snow positioning cargo towards the rear.
Page 397: Towing
Emergency Roof Lamp Provisions What is total vehicle reserve capacity? Vehicles with the RPO VYU snow plow prep This is the difference between your GVWR and package also have an emergency roof lamp the weight of your vehicle with full fuel and provision package, RPO TRW.
Page 398: Recreational Vehicle Towing
Recreational Vehicle Towing • Do you have the proper towing equipment? See your dealer or trailering professional Recreational vehicle towing means towing your for additional advice and equipment vehicle behind another vehicle – such as behind a recommendations. motorhome. The two most common types of •...
Page 399 Four-Wheel-Drive Vehicles CAUTION: Shifting a four-wheel-drive vehicle’s transfer case into NEUTRAL can cause your vehicle to roll even if the transmission is in PARK (P). You or others could be injured. Make sure the parking brake is ﬁrmly set before you shift the transfer case to NEUTRAL.
Page 400 Dolly Towing Four-Wheel-Drive Vehicles ® If your vehicle is equipped with StabiliTrak , it is Two-Wheel-Drive Vehicles not designed to be dolly towed. If you need to tow Notice: If you tow a two-wheel-drive vehicle your vehicle, see “Dinghy Towing” earlier in this with the rear wheels on the ground, the section.
Page 401: Level Control
Level Control 3. Turn the engine off, but leave the ignition on. 4. Firmly set the parking brake. Automatic Level Control 5. Securely attach the vehicle being towed to the The automatic level control rear suspension is tow dolly. available on two-wheel drive and four-wheel drive light-duty vehicles and comes as a part of the CAUTION: ®...
Page 402: Autoride
® Autoride Towing a Trailer ® If equipped, the Autoride feature will provide a Do not tow a trailer during break-in. See New superior vehicle ride and handling under a variety Vehicle Break-In on page 136 for more information. of passenger and loading conditions. The system is fully automatic and uses a computer CAUTION: controller to continuously monitor vehicle speed,...
Page 403 • To identify the trailering capacity of your vehicle, Don’t tow a trailer at all during the ﬁrst you should read the information in “Weight of 500 miles (800 km) your new vehicle is driven. the Trailer” that appears later in this section. Your engine, axle or other parts could be damaged.
Page 404 Tow/Haul Mode Tow/Haul is a feature that assists when pulling a heavy trailer or a large or heavy load. The purpose of the Tow/Haul mode is to: • Reduce the frequency and improve the predictability of transmission shifts when pulling a heavy trailer or a large or heavy load.
Page 405 Your vehicle is equipped with a button at the end of Operating the vehicle in tow/haul when lightly the shift lever which, when pressed, enables loaded or with no trailer at all will not cause tow/haul. Your vehicle may be equipped with damage.
Page 406 Use one of the following charts to determine how much your vehicle can weigh, based upon your vehicle model and options. Vehicle Axle Ratio Maximum Trailer Weight GCWR C-1500 (2WD) 3.23 4,200 lbs (1 905 kg) 10,000 lbs (4 536 kg) 4800 V8 3.73 6,200 lbs (2 812 kg)
Page 407 Vehicle Axle Ratio Maximum Trailer Weight GCWR C-2500 (2WD) 6000 V8 3.73 7,700 lbs (3 493 kg) 14,000 lbs (6 350 kg) (Extended Models) 4.10 9,700 lbs (4 400 kg) 16,000 lbs (7 257 kg) Vehicle Axle Ratio Maximum Trailer Weight GCWR K-2500 (4WD) 6000 V8...
Page 408 Weight of the Trailer Tongue The tongue load (A) of any trailer is an important weight to measure because it affects the total or gross weight of your vehicle. The Gross Vehicle Weight (GVW) includes the curb weight of the vehicle, any cargo you may carry in it, and the people who will be riding in the vehicle.
Page 409 Do not exceed the maximum allowable tongue Consider the following example: weight for your vehicle. Choose the shortest hitch A vehicle model base weight is 5,500 lbs extension that will position the hitch ball closest (2 495 kg); 2,800 lbs (1 270 kg) at the front axle to the vehicle.
Page 410 This is very close to, but within the limit for Because your rear axle now weighs 3,100 lbs RGAWR as well. The vehicle is set to trailer up to (1 406 kg), you can only put 900 lbs (408 kg) 8,500 lbs (3 856 kg).
Page 411 Total Weight on Your Vehicle’s Tires Weight-Distributing Hitches and Weight Carrying Hitches Be sure your vehicle’s tires are inﬂated to the upper limit for cold tires. You’ll ﬁnd these numbers on the Certiﬁcation label at the rear edge of the driver’s door or see Loading Your Vehicle on page 387 for more information.
Page 412 Trailer Brakes If you will be pulling a trailer that, when loaded, will weigh more than 5,000 lbs (2 270 kg) be sure If your trailer weighs more than 2,000 lbs (900 kg) to use a properly mounted weight-distributing loaded, then it needs its own brakes – and they hitch and sway control of the proper size.
Page 413 Driving with a Trailer CAUTION: (Continued) CAUTION: • Keep the rear-most windows closed. • If exhaust does come into your vehicle through a window in the rear or If you have a rear-most window open and another opening, drive with your front, you pull a trailer with your vehicle, carbon main heating or cooling system on monoxide (CO) could come into your...
Page 414 Backing Up Before you start, check all trailer hitch parts and attachments, safety chains, electrical connector, Hold the bottom of the steering wheel with one lamps, tires and mirror adjustment. If the trailer has hand. Then, to move the trailer to the left, electric brakes, start your vehicle and trailer just move that hand to the left.
Page 415 Turn Signals When Towing a Trailer You can tow in DRIVE (D). You may want to shift the transmission to THIRD (3) or, if necessary, The arrows on your instrument panel will a lower gear selection if the transmission shifts ﬂash whenever you signal a turn or lane change.
Page 416 Parking on Hills 4. Reapply the regular brakes. Then apply your parking brake and shift into PARK (P). 5. If you have a four-wheel-drive vehicle, be sure CAUTION: the transfer case is in a drive gear and not in NEUTRAL. You really should not park your vehicle, 6.
Page 417 Maintenance When Trailer Towing CAUTION: (Continued) Your vehicle will need service more often when you’re pulling a trailer. See the Maintenance If the transfer case on four-wheel-drive Schedule for more on this. Things that are vehicles is in NEUTRAL, your vehicle will especially important in trailer operation are automatic transmission ﬂuid (don’t overﬁll), engine be free to roll, even if your shift lever is in...
Page 418 Trailer Wiring Harness The seven-wire harness contains the following trailer circuits: Your vehicle is equipped with the following wiring • Yellow: Left Stop/Turn Signal harnesses for towing a trailer. • Dark Green: Right Stop/Turn Signal Basic Trailer Wiring • Brown: Taillamps The trailer wiring harness, with a seven-pin •...
Page 419 Heavy-Duty Trailer Wiring Harness The seven-wire harness contains the following trailer circuits: Package • Yellow: Left Stop/Turn Signal • Dark Green: Right Stop/Turn Signal • Brown: Taillamps • White: Ground • Light Green: Back-up Lamps • Red: Battery Feed* Your vehicle is equipped with the seven-wire •...
Page 420: Trailer Recommendations
Electric Brake Control Wiring Trailer Recommendations Provisions You must subtract your hitch loads from the Cargo Weight Rating (CWR) for your vehicle. CWR is These wiring provisions are included with your the maximum weight of the load your vehicle can vehicle as part of the trailer wiring package.
Page 421 Section 5 Service and Appearance Care Service ............424 Engine Air Cleaner/Filter ......442 Automatic Transmission Fluid .....444 Accessories and Modiﬁcations ....424 Engine Coolant ...........448 California Proposition 65 Warning ....425 Coolant Surge Tank Pressure Cap .....451 Doing Your Own Service Work ....425 Engine Overheating ........451 Adding Equipment to the Outside Overheated Engine Protection...
Page 422 Section 5 Service and Appearance Care Bulb Replacement ........480 If a Tire Goes Flat ........507 Changing a Flat Tire ........508 Halogen Bulbs ..........480 Removing the Spare Tire and Tools ...509 Taillamps, Turn Signal, Stoplamps Removing the Flat Tire and Installing and Back-up Lamps ........480 the Spare Tire ........513 License Plate Lamp ........482...
Page 423 Section 5 Service and Appearance Care Aluminum or Chrome-Plated Wheels ..534 Electrical System .........538 Tires ............535 Add-On Electrical Equipment ......538 Sheet Metal Damage ........535 Windshield Wiper Fuses ......539 Finish Damage ...........536 Power Windows and Other Power Underbody Maintenance ......536 Options ...........539 Chemical Paint Spotting ......536 Fuses and Circuit Breakers ......539 Vehicle Care/Appearance Materials ....537...
Page 424: Service
We hope you will want to keep your GM vehicle control. Some of these accessories may even all GM. Genuine GM parts have one of these...
Page 425: California Proposition 65 Warning
California Proposition 65 Warning CAUTION: (Continued) Most motor vehicles, including this one, contain and/or emit chemicals known to the State of • Be sure you have sufficient California to cause cancer and birth defects or knowledge, experience, the proper other reproductive harm. Engine exhaust, replacement parts, and tools many parts and systems (including some inside before you attempt any vehicle...
Page 426: Adding Equipment To The Outside
Fuel Your vehicle has an airbag system. Before attempting to do your own service work, see The 8th digit of your vehicle identiﬁcation number Servicing Your Airbag-Equipped Vehicle on (VIN) shows the code letter or number that page 105. identiﬁes your engine. You will ﬁnd the VIN at You should keep a record with all parts receipts the top left of the instrument panel.
Page 427: Gasoline Octane
See Malfunction Indicator Lamp on page 235. If this occurs, return to Gasoline Speciﬁcations your authorized GM dealer for diagnosis. If it is At a minimum, gasoline should meet determined that the condition is caused by the type ASTM speciﬁcation D 4814 in the United States...
Page 428: Additives
Also, your GM dealer has additives that will The malfunction indicator lamp may turn on. help correct and prevent most deposit-related If this occurs, return to your authorized GM dealer problems. for service. Gasolines containing oxygenates, such as ethers and ethanol, and reformulated gasolines may be available in your area.
Page 429: Fuel E85 (85% Ethanol)
Fuel E85 (85% Ethanol) Those stations that do have E85 should have a label indicating ethanol content. Do not use the The 8th digit of your vehicle identiﬁcation number fuel if the ethanol content is greater than 85%. (VIN) shows the code letter or number that At a minimum, E85 should meet ASTM identiﬁes your engine.
Page 430: Fuels In Foreign Countries
Fuels in Foreign Countries E85 has less energy per gallon than gasoline, so you will need to reﬁll your fuel tank more If you plan on driving in another country outside often when using E85 than when you are the United States or Canada, the proper fuel may using gasoline.
Page 431: Filling The Tank
Filling the Tank CAUTION: Fuel vapor burns violently and a fuel ﬁre can cause bad injuries. To help avoid injuries to you and others, read and follow all the instructions on the pump island. Turn off your engine when you are refueling.
Page 432 If your vehicle has a Driver Information Center (DIC), the TIGHTEN GAS CAP message will be CAUTION: displayed if the fuel cap is not properly installed. If you spill fuel and then something CAUTION: ignites it, you could be badly burned. Fuel can spray out on you if you open the fuel cap too quickly.
Page 433: Filling A Portable Fuel Container
Filling a Portable Fuel Container CAUTION: (Continued) CAUTION: • Bring the ﬁll nozzle in contact with the inside of the ﬁll opening before operating the nozzle. Contact should Never ﬁll a portable fuel container while be maintained until the ﬁlling is it is in your vehicle.
Page 434: Checking Things Under The Hood
Checking Things Under CAUTION: the Hood Things that burn can get on hot engine CAUTION: parts and start a ﬁre. These include liquids like fuel, oil, coolant, brake ﬂuid, windshield washer and other ﬂuids, and An electric fan under the hood can start up plastic or rubber.
Page 435: Hood Release
Hood Release To open the hood do the following: 1. Pull the handle with this symbol on it. It is located inside the vehicle to the lower left of the steering wheel. 2. Then go to the front of the vehicle and locate the secondary hood release, near the center of the grille.
Page 436: Engine Compartment Overview
Engine Compartment Overview When you open the hood on the 5.3L engine (4.8L and 6.0L similar), here is what you will see:...
Page 437: Engine Oil
A. Engine Air Cleaner/Filter. See Engine L. Brake Master Cylinder Reservoir. See “Brake Air Cleaner/Filter on page 442. Fluid” under Brakes on page 464. B. Air Filter Restriction Indicator (If Equipped). M. Underhood Fuse Block. See Underhood Fuse See Engine Air Cleaner/Filter on page 442. Block on page 542.
Page 438 The engine oil dipstick handle is a yellow loop. Notice: Do not add too much oil. If the engine See Engine Compartment Overview on page 436 has so much oil that the oil level gets above for the location of the engine oil dipstick. the cross-hatched area that shows the proper operating range, the engine could be 1.
Page 439 GM Standard GM6094M and showing GM Standard GM6094M. You should look for the American Petroleum Institute Certiﬁed For and use only an oil that meets GM Standard Gasoline Engines starburst symbol. Failure to GM6094M. use the recommended oil can result in engine •...
Page 440: Engine Oil Life System
Do not add anything to your oil. The recommended over a year. However, your engine oil and oils with the starburst symbol that meet GM ﬁlter must be changed at least once a year and at Standard GM6094M are all you will need for good this time the system must be reset.
Page 441 How to Reset the Engine Oil Life What to Do with Used Oil System Used engine oil contains certain elements that may be unhealthy for your skin and could The Engine Oil Life System calculates when even cause cancer. Do not let used oil stay on to change your engine oil and ﬁlter based your skin for very long.
Page 442: Engine Air Cleaner/Filter
Engine Air Cleaner/Filter When to Inspect the Engine Air Cleaner/Filter See Engine If your vehicle has an air ﬁlter restriction indicator, Compartment Overview it lets you know when the engine air cleaner/ﬁlter on page 436 for the needs to be replaced. On vehicles with a restriction location of the engine indicator, you should inspect the air ﬁlter air cleaner/ﬁlter and...
Page 443 How to Inspect the Engine Replacing the Engine Air Cleaner/Filter and Resetting the Air Filter Restriction Air Cleaner/Filter Indicator Vehicles With an Air Filter Restriction Indicator Locate the air ﬁlter restriction indicator on the engine air cleaner/ﬁlter cover. When the indicator turns black or is in the red/orange “change”...
Page 444: Automatic Transmission Fluid
CAUTION: Operating the engine with the air cleaner/ ﬁlter off can cause you or others to be burned. The air cleaner not only cleans the air; it helps to stop ﬂames if the engine backﬁres. If it is not there and the engine backﬁres, you could be burned.
Page 445 How to Check Automatic To get the right reading, the ﬂuid should be at normal operating temperature, which is Transmission Fluid 180°F to 200°F (82°C to 93°C). Because this operation can be a little difficult, you Get the vehicle warmed up by driving about may choose to have this done at the dealership 15 miles (24 km) when outside temperatures are service department.
Page 446 Checking the Fluid Level See Engine Compartment Overview on page 436 for more information on location. Prepare your vehicle as follows: 1. Flip the handle up and then pull out the dipstick 1. Park your vehicle on a level place. Keep the and wipe it with a clean rag or paper towel.
Page 447 Consistency of Readings Notice: Use of the incorrect automatic transmission ﬂuid may damage your vehicle, Always check the ﬂuid level at least twice using and the damages may not be covered by the procedure described previously. Consistency your warranty. Always use the automatic (repeatable readings) is important to maintaining transmission ﬂuid listed in Recommended proper ﬂuid level.
Page 448: Engine Coolant
Engine Coolant A 50/50 mixture of clean, drinkable water and ® DEX-COOL coolant will: The cooling system in your vehicle is ﬁlled with Give freezing protection down to −34°F (−37°C). • ® DEX-COOL engine coolant. This coolant is • Give boiling protection up to 265°F (129°C). designed to remain in your vehicle for ﬁve years or 150,000 miles (240 000 km), whichever •...
Page 449 What to Use Notice: If you use an improper coolant mixture, your engine could overheat and be Use a mixture of one-half clean, drinkable water badly damaged. The repair cost would not be ® and one-half DEX-COOL coolant which will covered by your warranty.
Page 450 Checking Coolant Adding Coolant If you need more coolant, add the proper The coolant surge tank is located in the engine ® DEX-COOL coolant mixture at the surge tank, compartment on the passenger’s side of the but only when the engine is cool. vehicle.
Page 451: Coolant Surge Tank Pressure Cap
Coolant Surge Tank Pressure Cap Engine Overheating You will ﬁnd a coolant temperature gage on your Notice: If the pressure cap is not tightly vehicle’s instrument panel. See Engine Coolant installed, coolant loss and possible engine Temperature Gage on page 234. damage may occur.
Page 452 If Steam Is Coming From Your Engine CAUTION: (Continued) CAUTION: See Overheated Engine Protection Operating Mode on page 454 for Steam from an overheated engine can information on driving to a safe place burn you badly, even if you just open the in an emergency.
Page 453 If No Steam Is Coming From If you get the ENGINE OVERHEATED STOP ENGINE or the ENGINE OVERHEATED IDLE Your Engine ENGINE message with no sign of steam, try The ENGINE OVERHEATED STOP ENGINE this for a minute or so: or the ENGINE OVERHEATED IDLE ENGINE 1.
Page 454: Overheated Engine Protection
Overheated Engine Protection If there is still no sign of steam and your vehicle is equipped with an engine-driven cooling fan, Operating Mode push down the accelerator until the engine speed is about twice as fast as normal idle speed for If an overheated engine condition exists and at least ﬁve minutes while you are parked.
Page 455: Cooling System
Cooling System CAUTION: When you decide it is safe to lift the hood, here is what you will see: An electric fan under the hood can start up and injure you even when the engine is not running. Keep hands, clothing, and tools away from any underhood electric fan.
Page 456 CAUTION: Heater and radiator hoses, and other engine parts, can be very hot. Do not touch them. If you do, you can be burned. Do not run the engine if there is a leak. If you run the engine, it could lose all coolant.
Page 457 How to Add Coolant to the Coolant Notice: Engine damage from running your engine without coolant is not covered by your Surge Tank warranty. See Overheated Engine Protection If you have not found a problem yet, check to see Operating Mode on page 454 for information on if coolant is visible in the surge tank.
Page 458 If no coolant is visible in the surge tank, add coolant as follows: CAUTION: CAUTION: Adding only plain water to your cooling system can be dangerous. Plain water, or some other liquid such as alcohol, can Steam and scalding liquids from a hot boil before the proper coolant mixture will.
Page 459 Notice: In cold weather, water can freeze and 1. You can remove the crack the engine, radiator, heater core and coolant surge tank other parts. Use the recommended coolant pressure cap when and the proper coolant mixture. the cooling system, including the coolant surge tank pressure CAUTION:...
Page 460 3. Fill the coolant surge tank with the proper 4. With the coolant surge tank pressure cap off, mixture, to the FULL COLD mark. start the engine and let it run until you can feel the upper radiator hose getting hot. Watch out for the engine cooling fan.
Page 461: Engine Fan Noise
5. Then replace the pressure cap. Be sure the It is merely the cooling system functioning pressure cap is hand-tight and fully seated. properly. The fan will slow down when additional cooling is not required and the clutch disengages. 6. Verify coolant level after engine is shut off and the coolant is cold.
Page 462: Power Steering Fluid
Power Steering Fluid How to Check Power Steering Fluid To check the power steering ﬂuid, do the following: See Engine 1. Turn the key off and let the engine Compartment Overview compartment cool down. on page 436 for reservoir location. 2.
Page 463: Windshield Washer Fluid
Windshield Washer Fluid Open the cap with the washer symbol on it. What to Use Add washer ﬂuid until the tank is full. See When you need windshield washer ﬂuid, be sure Engine Compartment to read the manufacturer’s instructions before Overview on page 436 use.
Page 464: Brakes
Brakes There are only two reasons why the brake ﬂuid level in the reservoir might go down. The ﬁrst Brake Fluid is that the brake ﬂuid goes down to an acceptable level during normal brake lining wear. When new linings are put in, the ﬂuid level goes back Your brake master up.
Page 465 Checking Brake Fluid CAUTION: You can check the brake ﬂuid without taking off the cap. If you have too much brake ﬂuid, it can Look at the brake spill on the engine. The ﬂuid will burn if ﬂuid reservoir. the engine is hot enough. You or others The ﬂuid level should could be burned, and your vehicle could be above MIN.
Page 466 What to Add Notice: • Using the wrong ﬂuid can badly damage When you do need brake ﬂuid, use only DOT-3 brake system parts. For example, just a brake ﬂuid. Use new brake ﬂuid from a sealed few drops of mineral-based oil, such container only.
Page 467 The sound may come and go or be heard all inspect brake pads for wear and evenly tighten the time your vehicle is moving, except when you wheel nuts in the proper sequence to GM torque are pushing on the brake pedal ﬁrmly. speciﬁcations.
Page 468: Battery
— be sure you get 25 days or more, remove the black, negative (−) new approved GM replacement parts. If you do cable from the battery. This will help keep not, your brakes may no longer work properly.
Page 469: Jump Starting
Jump Starting Trying to start your vehicle by pushing or pulling it will not work, and it could damage If your vehicle’s battery (or batteries) has run your vehicle. down, you may want to use another vehicle 1. Check the other vehicle. It must have a and some jumper cables to start your vehicle.
Page 470 Notice: If you leave your radio or other The remote positive (+) terminal, if equipped, accessories on during the jump starting is located under a red plastic cover at the procedure, they could be damaged. The repairs positive battery post. To uncover the remote would not be covered by your warranty.
Page 471 CAUTION: CAUTION: Using a match near a battery can cause Fans or other moving engine parts can battery gas to explode. People have been injure you badly. Keep your hands away hurt doing this, and some have been from moving parts once the engine is blinded.
Page 472 Do not connect positive (+) to negative (−) 8. Now connect the black negative (−) cable to or you will get a short that would damage the the negative (−) terminal of the good battery. battery and maybe other parts too. And do Use a remote negative (−) terminal if the not connect the negative (−) cable to the vehicle has one.
Page 473 Notice: If the jumper cables are connected or To disconnect the jumper cables from both removed in the wrong order, electrical shorting vehicles do the following: may occur and damage the vehicle. The repairs 1. Disconnect the black negative (−) cable from would not be covered by your warranty.
Page 474: Rear Axle
Rear Axle How to Check Lubricant When to Check Lubricant It is not necessary to regularly check rear axle ﬂuid unless you suspect there is a leak or you hear an unusual noise. A ﬂuid loss could indicate a problem. Have it inspected and repaired. All axle assemblies are ﬁlled by volume of ﬂuid during production.
Page 475: Four-Wheel Drive
Four-Wheel Drive To get an accurate reading, the vehicle should be on a level surface. Lubricant checks in this section also apply to If the level is below the bottom of the ﬁller plug hole, these vehicles. There are two additional systems you’ll need to add some lubricant.
Page 476: Front Axle
Front Axle If the level is below the bottom of the ﬁller plug hole, located on the front axle, you may need to add some lubricant: When to Check and Change Lubricant • When the differential is cold, add enough It is not necessary to regularly check front axle lubricant to raise the level from 0 (0 mm) ﬂuid unless you suspect there is a leak or you hear...
Page 477: Headlamp Aiming
Headlamp Aiming • The vehicle should be placed so it is perpendicular to the wall or other ﬂat surface. The vehicle has a visual optical headlamp aiming • The vehicle should not have any snow, ice, system. The aim of the headlamps have been or mud on it.
Page 478 To adjust the vertical aim, do the following: 1. Open the hood. See Hood Release on page 435 for more information. 4. At the wall or other ﬂat surface, measure from the ground upward (A) to the recorded distance from Step 3 and mark it. 5.
Page 479 9. Make sure that the light from the headlamp is positioned at the bottom edge of the horizontal tape line. The lamp on the left (A) shows the correct headlamp aim. The lamp on the 7. Locate the vertical headlamp aiming screws, right (B) shows the incorrect headlamp aim.
Page 480: Bulb Replacement
Bulb Replacement Taillamps, Turn Signal, Stoplamps and Back-up Lamps For the proper type of replacement bulbs, see Replacement Bulbs on page 482. A. Taillamp/Stoplamp For any bulb changing procedure not listed in this B. Back-up Lamp section, contact your dealer. C.
Page 481 To replace one of these bulbs, do the following: 4. Press the release tab, if bulb socket has one, and turn the bulb socket counterclockwise to 1. Open the liftgate. See Power Liftgate on remove it from the taillamp assembly. page 125 for more information.
Page 482: License Plate Lamp
License Plate Lamp 3. Turn the bulb socket counterclockwise and pull the bulb straight out of the socket. 4. Install the new bulb. 5. Reverse steps 1– 3 to reinstall the license plate lamp. Replacement Bulbs Exterior Lamp Bulb Number Back-up Lamp 7441 License Plate Lamp...
Page 483: Windshield Wiper Blade Replacement
Windshield Wiper Blade Replacement Windshield wiper blades should be inspected for wear or cracking. See Scheduled Maintenance on page 553. Replacement blades come in different types and are removed in different ways. To replace the wiper blade assembly, do the following: 1.
Page 484: Tires
If you ever Tire pressure should be checked when have questions about your tire warranty and where to obtain service, see your GM Warranty booklet for your tires are cold. See Inﬂation - Tire details. For additional information refer to the tire Pressure on page 492.
Page 485: Tire Sidewall Labeling
(B) TPC Spec (Tire Performance Criteria Speciﬁcation): Original equipment tires designed to GM’s speciﬁc tire performance criteria have a TPC speciﬁcation code molded onto the sidewall. GM’s TPC speciﬁcations meet or exceed all federal safety guidelines.
Page 486 (D) Tire Identiﬁcation Number (TIN): The letters and numbers following DOT code are the Tire Identiﬁcation Number (TIN). The TIN shows the manufacturer and plant code, tire size, and date the tire was manufactured. The TIN is molded onto both sides of the tire, although only one side may have the date of manufacture.
Page 487 (E) Tire Identiﬁcation Number (TIN): The letters Speciﬁcation): Original equipment tires designed and numbers following DOT code are the Tire to GM’s speciﬁc tire performance criteria have Identiﬁcation Number (TIN). The TIN shows a TPC speciﬁcation code molded onto the sidewall.
Page 488 Tire Size (A) Light Truck (LT-Metric) Tire: The United States version of a metric tire sizing system. The The following examples show the different parts of letters LT as the ﬁrst two characters in the tire size a tire size. means a light truck tire engineered to standards set by the U.S.
Page 489: Tire Terminology And Definitions
Tire Terminology and Deﬁnitions Cold Inﬂation Pressure: The amount of air pressure in a tire, measured in pounds per square inch (psi) or kilopascals (kPa) before a tire has Air Pressure: The amount of air inside the tire built up heat from driving. See Inﬂation - Tire pressing outward on each square inch of the Pressure on page 492.
Page 490 Intended Outboard Sidewall: The side of an Normal Occupant Weight: The number of asymmetrical tire, that must always face outward occupants a vehicle is designed to seat multiplied when mounted on a vehicle. by 150 lbs (68 kg). See Loading Your Vehicle on page 387.
Page 491 Radial Ply Tire: A pneumatic tire in which the UTQGS (Uniform Tire Quality Grading ply cords that extend to the beads are laid at Standards): A tire information system that 90 degrees to the centerline of the tread. provides consumers with ratings for a tire’s traction, temperature, and treadwear.
Page 492: Inflation - Tire Pressure
Inﬂation - Tire Pressure A Tire and Loading Information label is attached to the vehicle’s center pillar (B-pillar), below Tires need the correct amount of air pressure to the driver’s door lock post (striker). This label lists operate effectively. your vehicle’s original equipment tires and their recommended cold tire inﬂation pressures.
Page 493: Tire Pressure Monitor System
How to Check Tire Pressure Monitor System Use a good quality pocket-type gage to check The Tire Pressure Monitor System (TPMS) uses tire pressure. You cannot tell if your tires are radio and sensor technology to check tire pressure properly inﬂated simply by looking at them. levels.
Page 494 For additional information and details about the As an added safety DIC operation and displays see DIC Operation and feature, your vehicle has Displays (With DIC Buttons) on page 243 or DIC been equipped with a Operation and Displays (Without DIC Buttons) tire pressure monitoring on page 249 and DIC Warnings and Messages system (TPMS) that...
Page 495 Your vehicle has also been equipped with a TPMS The Tire and Loading Information label (tire malfunction indicator to indicate when the system information placard) shows the size of your is not operating properly. The TPMS malfunction vehicle’s original tires and the correct inﬂation indicator is combined with the low tire pressure pressure for your vehicle’s tires when they telltale.
Page 496 DIC buttons, press the trip odometer driver’s side rear tire using a TPMS diagnostic tool. reset stem located on the instrument panel See your GM dealer for service. cluster until the RELEARN TIRE POSITIONS The TPMS sensors may also be matched to each message displays.
Page 497 5. Start with the driver’s side front tire. 10. After hearing the conﬁrming horn chirp for the driver’s side rear tire, the horn chirp will sound 6. Remove the valve cap from the valve cap two more times to signal the tire learning stem.
Page 498: Tire Inspection And Rotation
Federal Communications Commission Tire Inspection and Rotation (FCC) and Industry and Science Tires should be rotated every 5,000 to 8,000 miles Canada (8 000 to 13 000 km). The Tire Pressure Monitor System (TPMS) Any time you notice unusual wear, rotate your operates on a radio frequency and complies with tires as soon as possible and check wheel Part 15 of the FCC Rules.
Page 499 Make certain that all wheel nuts are properly tightened. See “Wheel Nut Torque” under Capacities and Speciﬁcations on page 547. CAUTION: Rust or dirt on a wheel, or on the parts to which it is fastened, can make wheel nuts become loose after a time.
Page 500: When It Is Time For New Tires
If you need replacement tires, have only 1/16 inch GM strongly recommends that you get tires with (1.6 mm) or less of the same TPC Spec rating. This way, your vehicle tread remaining. Some...
Page 501 CAUTION: CAUTION: Mixing tires could cause you to lose If you use bias-ply tires on your vehicle, control while driving. If you mix tires of the wheel rim ﬂanges could develop different sizes, brands, or types (radial cracks after many miles of driving. A tire and bias-belted tires), the vehicle may not and/or wheel could fail suddenly, causing handle properly, and you could have a...
Page 502: Different Size Tires And Wheels
If you add wheels or tires that are a different size that you will crash and suffer serious than your original equipment wheels and tires, injury. Only use GM speciﬁc wheel and this may affect the way your vehicle performs, tire systems developed for your vehicle,...
Page 503: Uniform Tire Quality Grading
Uniform Tire Quality Grading Treadwear The treadwear grade is a comparative rating Quality grades can be found where applicable on based on the wear rate of the tire when tested the tire sidewall between tread shoulder and under controlled conditions on a speciﬁed maximum section width.
Page 504: Wheel Alignment And Tire Balance
Temperature – A, B, C Wheel Alignment and Tire Balance The temperature grades are A (the highest), The tires and wheels on your vehicle were aligned B, and C, representing the tire’s resistance to and balanced carefully at the factory to give you the generation of heat and its ability to dissipate the longest tire life and best overall performance.
Page 505 GM original equipment parts. This way, See Changing a Flat Tire on page 508 for more you will be sure to have the right wheel, wheel information.
Page 506: Tire Chains
Tire Chains CAUTION: (Continued) CAUTION: To help avoid damage to your vehicle, drive slowly, readjust or remove the device if it is contacting your vehicle, If your vehicle has P265/65R18 or and do not spin your vehicle’s wheels. P275/55R20 size tires, do not use tire chains.
Page 507: If A Tire Goes Flat
If a Tire Goes Flat CAUTION: It is unusual for a tire to blowout while you are driving, especially if you maintain your vehicle’s tires properly. If air goes out of a tire, it is Lifting a vehicle and getting under it to much more likely to leak out slowly.
Page 508: Changing A Flat Tire
Changing a Flat Tire CAUTION: (Continued) If a tire goes ﬂat, avoid further tire and wheel damage by driving slowly to a level place. 3. If you have a four-wheel-drive vehicle, Turn on your hazard warning ﬂashers. be sure the transfer case is in a drive See Hazard Warning Flashers on page 190 gear —...
Page 509: Removing The Spare Tire And Tools
Removing the Spare Tire and Tools When your vehicle has a ﬂat tire, use the following example as a guide to assist you in the placement The equipment you will need to change a ﬂat of wheel blocks. tire is stored under the storage tray, which is located on the driver’s side trim panel (over the rear wheelhouse).
Page 510 2. Remove the wing nut (B) used to retain the The tools you will be using include the following: tool bag by turning it counterclockwise. A. Jack D. Jack Handle 3. Turn the knob (A) on the jack B. Wheel Blocks Extensions counterclockwise to release the jack and C.
Page 511 To access the spare tire, refer to the following 1. Open the hoist shaft access door (C) on the graphics and instructions: bumper to access the spare tire lock (K). 2. Insert the ignition key, turn it clockwise and then pull it to remove the spare tire lock. 3.
Page 512 5. Turn the wheel wrench (E) counterclockwise 7. Tilt the tire to lower the spare tire (H) to the ground. retainer (G) at the Continue to turn the wheel wrench until the end of the cable spare tire can be pulled out from under when the tire the vehicle.
Page 513: Removing The Flat Tire And Installing The Spare Tire
Removing the Flat Tire and If the wheel has bolt-on wheel covers, loosen the plastic nut caps by turning the wheel wrench Installing the Spare Tire counterclockwise. If needed, ﬁnish loosening them by hand. The nut caps will not come off. Use the following pictures and instructions to Using the ﬂat end of the wheel wrench, pry remove the ﬂat tire and raise the vehicle.
Page 514 CAUTION: Getting under a vehicle when it is jacked up is dangerous. If the vehicle slips off the jack you could be badly injured or killed. Never get under a vehicle when it is supported only by a jack. CAUTION: Jacking Locations (Overall View) Raising your vehicle with the jack A.
Page 515 Position the jack on the frame behind the ﬂat tire where the frame sections overlap (E). Turn the wheel wrench (D) clockwise to raise the vehicle. Raise the vehicle far enough off the ground so there is enough room for the spare tire to clear the ground.
Page 516 Use the jacking pad provided on the rear axle. Turn the wheel wrench (D) clockwise to raise the vehicle. Raise the vehicle far enough off the ground so there is enough room for the spare tire to clear the ground. 4.
Page 517 CAUTION: CAUTION: Rust or dirt on the wheel, or on the parts Never use oil or grease on studs or nuts. to which it is fastened, can make the If you do, the nuts might come loose. wheel nuts become loose after a time. Your wheel could fall off, causing a The wheel could come off and cause an serious accident.
Page 518 This could lead to an accident. Be sure to use the correct wheel nuts. If you have to replace them, be sure to get new GM original equipment wheel nuts. Stop 10. Tighten the nuts ﬁrmly in a crisscross...
Page 519: Secondary Latch System
Secondary Latch System To release the spare tire from the secondary latch, do the following: Your vehicle has an underbody-mounted tire hoist 1. Check under the assembly which has a secondary latch system. vehicle to see if It is designed to stop the spare tire from suddenly the cable end falling off your vehicle.
Page 520 3. Loosen the cable by turning the wheel wrench counterclockwise three or four turns. 4. Repeat this procedure at least two times. If the spare tire lowers to the ground, continue with Step 5 of Removing the Spare Tire and Tools on page 509. 5.
Page 521 CAUTION: Someone standing too close during the procedure could be injured by the jack. If the spare tire does not slide off the jack completely, make sure no one is behind you or on either side of you as you pull the jack out from the spare.
Page 522: Storing A Flat Or Spare Tire And Tools
Storing a Flat or Spare Tire 15. Tilt the tire retainer (G) at the and Tools end of the cable and pull it through the wheel opening. Pull CAUTION: the tire out from under the vehicle. Storing a jack, a tire, or other equipment in the passenger compartment of the vehicle could cause injury.
Page 523 Store the tire under the rear of the vehicle in the G. Tire Retainer J. Hoist End of spare tire carrier. Refer to the following graphics H. Spare Tire/Flat Tire Extension Tool and instructions to help you: (Valve Stem K. Spare Tire Lock Pointed Down) I.
Page 524 2. Tilt the retainer 4. Insert the open end downward and of the extension (I) through the wheel through the hole opening. Make in the rear sure the retainer bumper (J) (hoist is fully seated shaft access hole). across the underside of the wheel.
Page 525 To store the tools, do the following. 7. Make sure the tire is stored securely. Push, pull (A), and then try to turn (B) the tire. If the A. Wheel Blocks E. Jack tire moves, use the wheel wrench to tighten B.
Page 526 2. Assemble wheel blocks (A) and jack (E) together with the wing nut (F). 3. Position the jack (E) and wheel blocks (A) in the driver’s side trim panel over the wheelhouse. 4. Turn the wing nut (G) clockwise until the jack is secured tight in the mounting bracket.
Page 527: Spare Tire
Spare Tire Notice: If your vehicle has four-wheel drive and the different size spare tire is installed Your vehicle, when new, had a fully-inﬂated on your vehicle, do not drive in four-wheel spare tire. A spare tire may lose air over time, drive until you can have your ﬂat tire repaired so check its inﬂation pressure regularly.
Page 528: Appearance Care
Appearance Care Do not use any of these products unless this manual says you can. In many uses, these will Cleaning products can be hazardous. Some are damage the vehicle: toxic. Other cleaning products can burst into ﬂames • Alcohol if a match is struck near them or if they get on a hot •...
Page 529 Should it become necessary, vehicle’s interior. you can also obtain a product from your GM dealer When cleaning your vehicle’s interior, only use to remove odors from your vehicle’s upholstery. cleaners speciﬁcally designed for the surfaces Do not clean your vehicle using the following being cleaned.
Page 530: Fabric/Carpet
• To clean, use the following instructions: Do not heavily saturate your upholstery while cleaning. 1. Saturate a lint-free, clean white cloth with • water or club soda. Damage to your vehicle’s interior may result from the use of many organic solvents such 2.
Page 531: Leather
Leather Instrument Panel, Vinyl, and Other Plastic Surfaces A soft cloth dampened with water may be used to remove dust. If a more thorough cleaning A soft cloth dampened with water may be used is necessary, a soft cloth dampened with a mild to remove dust.
Page 532: Care Of Safety Belts
Clean safety belts Be sure to rinse the vehicle well, removing all only with mild soap and lukewarm water. soap residue completely. GM-approved cleaning products can be obtained from your dealer. See Vehicle Care/Appearance Materials on page 537. Do not use cleaning agents that are Weatherstrips petroleum based, or that contain acid or abrasives.
Page 533: Cleaning Exterior Lamps/Lenses
You can help to residue from the paint ﬁnish. You can get keep the paint ﬁnish looking new by keeping your GM-approved cleaning products from your vehicle garaged or covered whenever possible. dealer. See Vehicle Care/Appearance Materials on page 537.
Page 534: Windshield, Backglass, And Wiper Blades
Clean not be covered by your warranty. Use only the blade by wiping vigorously with a cloth soaked GM-approved cleaners on aluminum or in full-strength windshield washer solvent. Then chrome-plated wheels. rinse the blade with water.
Page 535: Tires
Tires Notice: Using chrome polish on aluminum wheels could damage the wheels. The repairs To clean the tires, use a stiff brush with tire would not be covered by your warranty. cleaner. Use chrome polish on chrome wheels only. Use chrome polish only on chrome-plated wheels, Notice: Using petroleum-based tire dressing but avoid any painted surface of the wheel, and products on your vehicle may damage the...
Page 536: Finish Damage
Although no defect in the paint job causes this, fuel lines, frame, ﬂoor pan, and exhaust system GM will repair, at no charge to the owner, the even though they have corrosion protection. surfaces of new vehicles damaged by this fallout condition within 12 months or 12,000 miles (20 000 km) of purchase, whichever occurs ﬁrst.
Page 537: Vehicle Care/Appearance Materials
Vehicle Care/Appearance Materials Description Usage Removes swirl marks, ﬁne Description Usage Swirl Remover Polish scratches, and other light surface contamination. Polishing Cloth Interior and exterior Wax-Treated polishing cloth. Removes light scratches Cleaner Wax and protects ﬁnish. Tar and Road Oil Removes tar, road oil, Remover and asphalt.
Page 538: Vehicle Identification
Vehicle Identiﬁcation Service Parts Identiﬁcation Label You will ﬁnd this label on the inside of the glove box. It is very helpful if you ever need to order Vehicle Identiﬁcation Number (VIN) parts. On this label, you will ﬁnd the following: •...
Page 539: Windshield Wiper Fuses
Windshield Wiper Fuses Fuses and Circuit Breakers The windshield wiper motor is protected by an The wiring circuits in your vehicle are protected internal circuit breaker and a fuse. If the motor from short circuits by a combination of fuses, overheats due to heavy snow, etc., the wiper will circuit breakers and fusible thermal links.
Page 540: Instrument Panel Fuse Block
Instrument Panel Fuse Block Fuses Usage REAR SEAT Rear Seats The instrument panel fuse block access door is located on the driver’s side edge of the AUX PWR2 Rear Cargo Area Power Outlets instrument panel. SWC BKLT Steering Wheel Controls Backlight Driver Door Module Dome Lamps, Driver’s Side Turn CTSY...
Page 541: Center Instrument Panel Fuse Block
Center Instrument Panel Fuse Block Fuses Usage IS LPS Interior Lamps The center instrument panel fuse block is located underneath the instrument panel, to the left of the Power Door Lock 1 UNLCK1 steering column. (Unlock Feature) Top View Ultrasonic Rear Parking Assist, OBS DET Power Liftgate Power Door Lock 1...
Page 542: Underhood Fuse Block
Underhood Fuse Block Fuses Usage HEADLINER 3 Headliner Harness Connector 3 HEADLINER 2 Headliner Harness Connector 2 HEADLINER 1 Headliner Harness Connector 1 BRAKE Brake Clutch Harness Connector CLUTCH Special Equipment Option Upﬁtter SEO/UPFITTER Harness Connector Circuit Breaker Usage Passenger’s Side Power Window Circuit Breaker Passenger’s Seat Circuit Breaker The underhood fuse block is located in the engine...
Page 543 Fuses Usage Fuses Usage Not Used Left Trailer Stop/Turn Lamp Electronic Stability Suspension Engine Controls Control, Automatic Level Control Engine Control Module, Exhaust Throttle Control...
Page 544 Fuses Usage Fuses Usage Right Trailer Stop/Turn Lamp Transmission Controls (Ignition) Front Washer Fuel Pump Oxygen Sensors Not Used Anti-lock Brakes System 2 Rear Washer Trailer Back-up Lamps Fuel Injectors, Ignition Coils (Left Side) Driver’s Side Low-Beam Headlamp Trailer Park Lamps Engine Control Module (Battery) Driver’s Side Park Lamps Fuel Injectors, Ignition Coils...
Page 545 Fuses Usage Fuses Usage Sunroof Instrument Panel Cluster Key Ignition System, Theft Not Used Deterrent System Not Used Windshield Wiper Auxiliary Climate Control (Ignition), SEO B2 Upﬁtter Usage (Battery) Compass-Temperature Mirror Electric Adjustable Pedals Rear Defogger Climate Controls (Battery) Airbag System (Battery) Airbag System (Ignition) SEO B1 Upﬁtter Usage (Battery) Ampliﬁer...
Page 546 J-Case Fuses Usage Relays Usage Cooling Fan 1 FAN HI Cooling Fan High Speed Automatic Level Control Compressor FAN LO Cooling Fan Low Speed Heavy Duty Anti-lock Brake System ENG EXH VLV Not Used Cooling Fan 2 FAN CNTRL Cooling Fan Control Anti-lock Brake System 1 HDLP LO/HID Low-Beam Headlamp...
Page 547: Capacities And Specifications
Capacities and Speciﬁcations The following approximate capacities are given in English and metric conversions. See Recommended Fluids and Lubricants on page 563 for more information. Capacities Application English Metric Air Conditioning Refrigerant R134a Regular 2.5 lbs 0.7 kg Extended 1500 Series 2.8 lbs 1.3 kg Extended 2500 Series...
Page 548 Capacities Application English Metric Transmission Fluid 4L70-E Super Duty Transmission and 4L60-E Electronic 3.8 qt 4.0 L Transmission 4L80-E Transmission 7.7 qt 7.3 L Transfer Case Fluid 2.0 qt 1.9 L Wheel Nut Torque 140 lb ft 190 Y †Oil ﬁlter should be changed at every oil change. After reﬁll, the level must be rechecked.
Page 549 Section 6 Maintenance Schedule Maintenance Schedule .........550 At Each Fuel Fill ........560 At Least Once a Month ......561 Introduction ..........550 At Least Once a Year ........561 Maintenance Requirements ......550 Recommended Fluids and Lubricants ..563 Your Vehicle and the Environment .....550 Normal Maintenance Replacement Parts ..566 Using the Maintenance Schedule ....551 Engine Drive Belt Routing ......567...
Page 550: Maintenance Schedule
Your Vehicle and the Environment Proper vehicle maintenance not only helps to keep your vehicle in good working condition, but also Have you purchased the GM Protection Plan? helps the environment. All recommended The Plan supplements your new vehicle maintenance is important. Improper vehicle warranties.
Page 551: Using The Maintenance Schedule
553 should be performed when indicated. you drive. If you have any questions on how to See Additional Required Services on page 556 and keep your vehicle in good condition, see your Maintenance Footnotes on page 558 for further ® GM Goodwrench dealer. information.
Page 552 ® When you go to your GM Goodwrench dealer for your service needs, you will know that GM-trained CAUTION: and supported service technicians will perform the work using genuine GM parts. Performing maintenance work on a vehicle If you want to purchase service information, can be dangerous.
Page 553: Scheduled Maintenance
Required services are described ﬁlter must be changed at least once a year and at in the following for “Maintenance I” and this time the system must be reset. Your GM “Maintenance II.” Generally, it is recommended ®...
Page 554 Maintenance I — Use Maintenance I if the Maintenance II — Use Maintenance II if the CHANGE ENGINE OIL message comes on within previous service performed was Maintenance I. 10 months since the vehicle was purchased or Always use Maintenance II whenever the message Maintenance II was performed.
Page 555 Scheduled Maintenance (cont’d) Service Maintenance I Maintenance II Check engine coolant and windshield washer ﬂuid levels and add ﬂuid as • • needed. Perform any needed additional services. See “Additional Required Services” • • in this section. • Inspect suspension and steering components. See footnote (b). •...
Page 556: Additional Required Services
Additional Required Services The following services should be performed at the ﬁrst maintenance service (I or II) after the indicated miles (kilometers) shown for each item. Additional Required Services 25,000 50,000 75,000 100,000 125,000 150,000 Service and Miles (Kilometers) (40 000) (80 000) (120 000) (160 000)
Page 557 Additional Required Services (cont’d) 25,000 50,000 75,000 100,000 125,000 150,000 Service and Miles (Kilometers) (40 000) (80 000) (120 000) (160 000) (200 000) (240 000) Inspect evaporative control system. • • • An Emission Control Service. See footnotes † and (k). Replace spark plugs and inspect spark •...
Page 558: Maintenance Footnotes
Inspect all pipes, ﬁttings, and clamps; replace with be recorded. genuine GM parts as needed. To help ensure Lubricate the front suspension, steering linkage, proper operation, a pressure test of the cooling transmission shift linkage, and parking brake cable system and pressure cap and cleaning the outside guides.
Page 559 (e) Make sure the safety belt reminder light and all (h) Change automatic transmission ﬂuid and ﬁlter your belts, buckles, latch plates, retractors, and if the vehicle is mainly driven under one or anchorages are working properly. Look for more of these conditions: any other loose or damaged safety belt system −...
Page 560: Owner Checks And Services
Engine Coolant Level Check control performance of your vehicle. Your Check the engine coolant level and add ® GM Goodwrench dealer can assist you with ® DEX-COOL coolant mixture if necessary. these checks and services.
Page 561: At Least Once A Month
3. Try to start the engine in each gear. The vehicle should start only in PARK (P) or NEUTRAL (N). If the vehicle starts in any other position, contact your ® GM Goodwrench dealer for service.
Page 562 When you are doing this inspection, the • The key should come out only in LOCK. vehicle could move suddenly. If the vehicle ® Contact your GM Goodwrench dealer if service is moves, you or others could be injured. required. Parking Brake and Automatic 1.
Page 563: Recommended Fluids And Lubricants
Engine oil which meets • To check the PARK (P) mechanism’s holding GM Standard GM6094M and ability: With the engine running, shift to displays the American Petroleum PARK (P). Then release the parking brake Institute Certiﬁed for Gasoline...
Page 564 SAE 75W-90 Synthetic ® GM Optikleen Washer Solvent. Washer (2500 Series Axle Lubricant Vehicles with (GM Part No. U.S. 12378261, GM Power Steering Fluid Four-Wheel in Canada 10953455) meeting Power Steering (GM Part No. U.S. 89021184, Drive) GM Speciﬁcation 9986115.
Page 565 Fluid/Lubricant Usage Fluid/Lubricant Automatic Outer Tailgate Multi-Purpose Lubricant, Superlube AUTO-TRAK II Fluid Transfer Case Handle Pivot (GM Part No. U.S. 12346241, (GM Part No. U.S. 12378508, (Four-Wheel Points in Canada 10953474). in Canada 10953626). Drive) Weatherstrip Lubricant Front Axle (GM Part No. U.S. 3634770,...
Page 566: Normal Maintenance Replacement Parts
Replacement parts identiﬁed below by name, part number, or speciﬁcation can be obtained from your GM dealer. Normal Maintenance Replacement Parts ® ACDelco Part Part GM Part Number Number Engine Air Cleaner /Filter High Capacity Filter 25313349 A1518C Standard Filter...
Page 567: Engine Drive Belt Routing
Engine Drive Belt Routing...
Page 568: Maintenance Record
Maintenance Record After the scheduled services are performed, record the date, odometer reading, who performed the service, and the type of services performed in the boxes provided. See Maintenance Requirements on page 550. Any additional information from Owner Checks and Services on page 560 can be added on the following record pages.
Page 569 Maintenance Record (cont’d) Odometer Maintenance I or Date Serviced By Services Performed Reading Maintenance II...
Page 570 Maintenance Record (cont’d) Odometer Maintenance I or Date Serviced By Services Performed Reading Maintenance II...
Page 571 Reporting Safety Defects to the Telephone (TTY) Users ......575 Canadian Government ......588 Customer Assistance Offices ......575 Reporting Safety Defects to GM Mobility Reimbursement Program ..576 General Motors ........588 Roadside Assistance Program ....577 Service Publications Ordering Courtesy Transportation ......580 Information ..........589 Vehicle Data Collection and Event Data Recorders ........582...
Page 572: Customer Assistance And Information
Customer Assistance and STEP TWO: If after contacting a member of dealership management, it appears your concern Information cannot be resolved by the dealership without further help, in the U.S., contact the Chevrolet Customer Assistance Center by calling Customer Satisfaction Procedure 1-800-222-1020.
Page 573 STEP THREE — U.S. Owners: Both General You may contact the BBB Auto Line Program Motors and your dealer are committed to making using the toll-free telephone number or write them sure you are completely satisﬁed with your at the following address: new vehicle.
Page 574: Online Owner Center
The program Online Owner Center is designed so that the entire dispute settlement The Owner Center is a resource for your GM process, from the time you ﬁle your complaint ownership needs. Speciﬁc vehicle information can to the ﬁnal decision, should be completed...
Page 575: Customer Assistance For Text Telephone (Tty) Users
United States — Customer Assistance Refer to the web for updated information. Chevrolet Motor Division To register your vehicle, visit www.MyGMLink.com Chevrolet Customer Assistance Center (United States) or My GM Canada within P.O. Box 33170 www.gmcanada.com (Canada). Detroit, MI 48232-5170 www.Chevrolet.com...
Page 576: Gm Mobility Reimbursement Program
(Except Puerto Rico and U.S. Virgin For more details, or to determine your vehicle’s Islands) — Customer Assistance eligibility, visit gmmobility.com or call the GM Mobility Assistance Center at 1-800-323-9935. General Motors de Mexico, S. de R.L. de C.V. Text telephone (TTY) users, call 1-800-833-9935.
Page 577: Roadside Assistance Program
Roadside Assistance Program • Fuel Delivery: Delivery of enough fuel for the customer to get to the nearest service station In the U.S., call 1-800-CHEV-USA (approximately $5 in the U.S. and 10 litres (1-800-243-8872) in Canada). Service to provide diesel may be restricted.
Page 578 • • Flat Tire Change: Installation of your spare Trip Interruption Beneﬁts and Assistance: tire in good condition will be covered at no In the event of a warranty related vehicle charge. The customer is responsible for disablement, while en route and over the repair or replacement of the tire if not 250 kilometres from original point of departure, covered by a warrantable failure.
Page 579 • • Alternative Service: There may be times, Model, year, color, and license plate number. when Roadside Assistance cannot provide • Odometer reading, Vehicle Identiﬁcation timely assistance, your advisor may authorize Number (VIN), and delivery date of the vehicle. you to secure local emergency road service, •...
Page 580: Courtesy Transportation
Towing and Road Service Exclusions Courtesy Transportation is not a part of the New Vehicle Limited Warranty and is available only Speciﬁcally excluded from Roadside Assistance at participating dealers. A separate booklet entitled coverage are towing or services for vehicles “Warranty and Owner Assistance Information”...
Page 581 However, if you are unable to wait, expenses may be available. Claim amounts should GM helps to minimize your inconvenience by reﬂect actual costs and be supported by original providing several transportation options.
Page 582: Vehicle Data Collection And Event Data Recorders
Additional Program Information Some information may be stored during regular operations to facilitate repair of detected All program options, such as shuttle service, may malfunctions; other information is stored only in a not be available at every dealer. Please contact crash event by computer systems, such as those your dealer for speciﬁc information about commonly called event data recorders (EDR).
Page 583: Collision Damage Repair
GM will not access information if they have access to the vehicle information about a crash event or share it with or the device that stores the data.
Page 584 Aftermarket parts are not covered by your designed appearance, durability and safety are GM New Vehicle Limited Warranty, and any preserved. The use of Genuine GM parts can help vehicle failure related to such parts are not maintain your GM New Vehicle Warranty.
Page 585 Insuring Your Vehicle If an Accident Occurs Protect your investment in your GM vehicle with Here is what to do if you are involved in an comprehensive and collision insurance coverage. accident. There are signiﬁcant differences in the quality •...
Page 586 • Choose a reputable collision repair facility for from the other driver. Things like name, your vehicle. Whether you select a GM dealer address, phone number, driver’s license or a private collision repair facility to ﬁx the number, vehicle license plate, vehicle make, damage, make sure you are comfortable with model and model year, Vehicle Identiﬁcation...
Page 587 If another party’s insurance company is paying or recycled original GM parts. Remember, recycled for the repairs, you are not obligated to accept a parts will not be covered by your GM vehicle repair valuation based on that insurance warranty.
Page 588: Reporting Safety Defects
Reporting Safety Defects Reporting Safety Defects to the Canadian Government Reporting Safety Defects to the If you live in Canada, and you believe that your United States Government vehicle has a safety defect, you should immediately notify Transport Canada, in addition If you believe that your vehicle has a defect which to notifying General Motors of Canada Limited.
Page 589: Service Publications Ordering
In Canada, the service bulletin reference number Service Publications Ordering can be obtained by contacting your General Motors Information dealer or by calling 1-800-GM-DRIVE (1-800-463-7483). This reference number is Service Manuals needed to order the service bulletin from Helm, Inc.
Page 590 Current and Past Model Order Forms quoted in U.S. funds. Canadian residents are Service Publications are available for current to make checks payable in U.S. funds. and past model GM vehicles. To request an order form, please specify year and model name of the vehicle.
Page 591 Airbag System (cont.) When Should an Airbag Inﬂate? ....95 Accessories and Modiﬁcations ...... 424 Where Are the Airbags? ......92 Accessory Power Outlet(s) ......209 Antenna, Rear Side Window ......332 Adding a Snow Plow or Similar Antenna, XM™ Satellite Radio Antenna Equipment ..........
Page 592 Ashtray(s) ............. 210 Audio System(s) ........... 271 Battery ............468 Audio Steering Wheel Controls ....330 Run-Down Protection ........ 205 Care of Your CD and DVD Player ..... 332 Before Leaving on a Long Trip ..... 376 Care of Your CDs and DVDs ....332 Bench Seat, Split (60/40) .......
Page 593 Child Restraints (cont.) Lower Anchors and Tethers for Calibration ..........157, 161 Children ..........73 California Fuel ..........427 Older Children ..........60 California Proposition 65 Warning ....425 Securing a Child Restraint in a Canadian Owners ..........3 Rear Seat Position ........82 Capacities and Speciﬁcations .......
Page 594 Telephone (TTY) Users ......575 Locks ............120 Customer Assistance Offices ..... 575 Power Door Locks ........121 Customer Satisfaction Procedure ....572 Programmable Automatic Door Locks ..121 GM Mobility Reimbursement Program ..576 Rear Door Security Locks ......122...
Page 595 Driver Position, Safety Belt ........43 Electrical System Driver Information Center (DIC) ....242 Add-On Equipment ........538 DIC Operation and Displays ....243, 249 Center Instrument Panel Fuse Block ..541 DIC Vehicle Customization ......262 Fuses and Circuit Breakers ....... 539 DIC Warnings and Messages ....
Page 596 Engine (cont.) Fuel ............. 426 Overheating ..........451 Additives ........... 428 Starting ............. 138 California Fuel .......... 427 Entry Lighting ..........205 E85 (85% Ethanol) ........429 Event Data Recorders (EDR) ....... 582 Filling a Portable Fuel Container ....433 Exit Lighting ..........
Page 597 Speciﬁcations ..........427 Horn ............190 Glove Box ............ 176 How to Use This Manual ......... 3 GM Mobility Reimbursement Program ... 576 How to Wear Safety Belts Properly ....43 Ignition Positions .......... 137 Hazard Warning Flashers ......190 Infants and Young Children, Restraints ...
Page 598 Light (cont.) Oil Pressure ..........239 Labeling, Tire Sidewall ......... 485 Passenger Airbag Status Indicator ..... 228 Lamps Passenger Safety Belt Reminder ....227 Auxiliary Roof Mounted Lamp ....204 Safety Belt Reminder ........ 226 Battery Run-Down Protection ....205 Security ............
Page 599 Mirrors (cont.) Automatic Dimming Rearview with Maintenance Schedule ® OnStar , Compass and Temperature Additional Required Services ..... 556 Display ..........157 At Each Fuel Fill ........560 Outside Automatic Dimming Mirror .... 167 At Least Once a Month ......561 Outside Convex Mirror ......
Page 600 Engine ............437 Paint, Damage ..........536 Pressure Gage .......... 238 Park Aid ............206 Pressure Light .......... 239 Park (P) Oil, Engine Oil Life System ......440 Shifting Into ..........152 Older Children, Restraints ......60 Shifting Out of .......... 154 Online Owner Center ........
Page 601 Power (cont.) Rainsense™ II Wipers ........194 Seat ............10 Reading Lamps ..........205 Steering Fluid ........... 462 Rear Air Conditioning and Heating System ..221 Windows ........... 131 Rear Air Conditioning and Heating System Pretensioners, Safety Belt ......59 and Electronic Climate Controls ....
Page 602 Recovery Hooks ........... 386 Recreational Vehicle Towing ......398 Safety Belt Remote Keyless Entry System ..... 112 Passenger Reminder Light ......227 Remote Keyless Entry System, Operation ..113 Pretensioners ..........59 Removing the Flat Tire and Installing Reminder Light ......... 226 the Spare Tire ...........
Page 603 Seats (cont.) Setting the Time ........273, 274 Center Seat ..........19 Sheet Metal Damage ........535 Head Restraints .......... 18 Shifting Into Park (P) ........152 Heated Seats ..........12 Shifting Out of Park (P) ........ 154 Heated Seats - Rear ........19 Shoulder Belt Height Adjuster ......
Page 604 Storage Areas (cont.) Tires ............484 Rear Storage Area ........178 Aluminum or Chrome-Plated Wheels, Stuck in Sand, Mud, Ice, or Snow ....384 Cleaning ..........534 Sun Visors ........... 132 Buying New Tires ........500 Sunroof ............183 Chains ............506 Changing a Flat Tire .........
Page 605 Tow/Haul Mode ..........145 Tow/Haul Mode Light ........241 Vehicle Towing Control ............340 Recreational Vehicle ........398 Damage Warnings ........5 Towing a Trailer ........402 Loading ............. 387 Your Vehicle ..........397 Symbols ............5 Traction Vehicle Customization, DIC ......262 ®...
Page 606 Windshield (cont.) Washer ............. 195 Warning Lights, Gages and Indicators ..224 Washer Fluid ..........463 Warnings Wiper Blade Replacement ......483 DIC Warnings and Messages ....252 Wiper Fuses ..........539 Hazard Warning Flashers ......190 Wipers ............193 Other Warning Devices ......

This manual is also suitable for:

Chevrolet suburban 2007

GM Chevrolet Tahoe 2007 Owner's Manual

Section 1 Seats and Restraint Systems

Section 2 Features and Controls

Section 3 Instrument Panel

Section 4 Driving Your Vehicle

Section 5 Service and Appearance Care

Quick Links

Chapters

Need help?

Questions and answers

Related Manuals for GM Chevrolet Tahoe 2007

Summary of Contents for GM Chevrolet Tahoe 2007
