Summary of Contents for HOOKE ROAD BXG.8907-S
- Page 1 BXG.8907-S Inter Cargo Rack (1) Contents:...
- Page 2 Part Name Size(mm) Picture Button Head Socket Cap Bolts Screws M10*20 Flange Hex Lock Nuts Split Lock Washer Flat Washer...
- Page 3 About 40 minutes, 1-2 people may be needed. Installation time may differ according to your mechanical skill level. (PLEASE VERIFY ALL PARTS ARE PRESENT AND READ INSTRUCTIONS CAREFULLY BEFORE STARTING INSTALLATION!) To view the electronic version (BXG.8907-S), please scan the QR code.
- Page 4 (4) Installation instruction: Step 1: Put down the rear seats, empty the rear row and prepare to install the luggage rack. Step 2: Install the Left (A1) & Right (A2) Brackets into your vehicle with the factory bolts. As the picture shown.
- Page 5 Button Head Socket Cap Bolts Screws (M8*20), Split Lock Washer (D8), Flat Washer (M8), Flange Hex Lock Nuts (M8). As the picture shown. Step 4: The installation is complete. We hope you enjoy a wonderful off-road life with this quality Hooke Road product!
- Page 6 1.The product parts in this instruction may differ slightly from the actual product contents but generally does not affect the installation of the product. 2.Please feel free to contact your distributor if you have any kind of question about your purchase. Hooke Road to find your parts...
