Summary of Contents for MSI PRO Z690-A DDR4
- Page 1 PRO Z690-A DDR4 PRO Z690-A WIFI DDR4 Motherboard User Guide Benutzerhandbuch Manuel d’utilisation Руководство пользователя 取扱説明書 사용 명서 使用手冊 使用手册...
- Page 2 English Deutsch Français Русский 日本語 한국어 繁體中文 简体中文...
-
Page 3: Table Of Contents
JBAT1: Clear CMOS (Reset BIOS) Jumper ...............24 JRAINBOW1~2: Addressable RGB LED connectors ..........24 JRGB1: RGB LED connector ..................25 EZ Debug LED ......................25 Installing OS, Drivers & MSI Center .............. 26 Installing Windows® 10 .....................26 Installing Drivers ......................26 MSI Center ........................26... - Page 4 UEFI BIOS ....................... 27 BIOS Setup ........................28 Entering BIOS Setup ....................28 BIOS User Guide .......................28 Resetting BIOS ......................29 Updating BIOS......................29 Contents...
-
Page 5: Safety Information
Safety Information ∙ The components included in this package are prone to damage from electrostatic discharge (ESD). Please adhere to the following instructions to ensure successful computer assembly. ∙ Ensure that all components are securely connected. Loose connections may cause the computer to not recognize a component or fail to start. -
Page 6: Specifications
Specifications ∙ Supports 12th Gen Intel® Core™ Processors ∙ Processor socket LGA1700 * Please go to msi.com to get the newest support status as new processors are released. Chipset Intel® Z690 chipset ∙ 4x DDR4 memory slots, support up to 128GB* ∙... - Page 7 Continued from previous page 1x Intel® I225V 2.5Gbps LAN controller Intel® Wi-Fi 6 (Only for PRO Z690-A WIFI DDR4) ∙ The Wireless module is pre-installed in the M.2 (Key-E) slot Wireless LAN & ∙ Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz (160MHz) up to Bluetooth®...
- Page 8 Continued from previous page ∙ Intel® Z690 Chipset ▪ 1x USB 3.2 Gen 2x2 20Gbps Type-C port on the back panel ▪ 2x USB 3.2 Gen 2 10Gbps ports (1 Type-C internal connector and 1 Type-A port on the back panel) ▪...
- Page 9 BIOS Features ∙ ACPI 6.4, SMBIOS 3.4 ∙ Multi-language ∙ Drivers ∙ MSI Center ∙ Intel® Extreme Tuning Utility Software ∙ CPU-Z MSI GAMING ∙ Google Chrome™, Google Toolbar, Google Drive ∙ Norton™ Internet Security Solution Continued on next page Specifications...
- Page 10 Continued from previous page ∙ Mystic Light ∙ LAN Manager ∙ User Scenario ∙ Hardware Monitor MSI Center ∙ Frozr AI Cooling Features ∙ True Color ∙ Live Update ∙ Speed Up ∙ Super Charger ∙ Audio ▪ Audio Boost ∙...
- Page 11 USB 3.2 Gen 2 10G ▪ USB with Type A+C Special ▪ Front USB Type-C Features ∙ Protection ▪ PCI-E Steel Armor ∙ Experience ▪ MSI Center ▪ Frozr AI Cooling ▪ Click BIOS 5 ▪ Flash BIOS Button Specifications...
-
Page 12: Rear I/O Panel
USB 3.2 Gen 1 Wi-Fi Antenna connectors 5Gbps Type-A USB 2.0 Type-A USB 3.2 Gen 2x2 USB 3.2 Gen 2 20Gbps Type-C 10Gbps Type-A PRO Z690-A DDR4 Audio Ports USB 2.0 Type-A PS/2 Combo port 2.5 Gbps LAN DisplayPort Flash BIOS Port Flash BIOS Button USB 3.2 Gen 1... -
Page 13: Lan Port Led Status Table
LAN Port LED Status Table Link/ Activity LED Speed LED Status Description Status Description 10 Mbps connection No link Green 100/ 1000 Mbps connection Yellow Linked Orange 2.5 Gbps connection Blinking Data activity Audio Ports Configuration Channel Audio Ports Line-Out/ Front Specker Out Line-In ●... -
Page 14: Overview Of Components
Overview of Components CPU_FAN1 Processor Socket PUMP_FAN1 CPU_PWR2 JSMB1 SYS_FAN1 CPU_PWR1 JRAINBOW2 SYS_FAN2 SYS_FAN3 DIMMB2 ATX_PWR1 50.98mm* (For PRO Z690-A WIFI DDR4) DIMMB1 SYS_FAN6 JUSB4 DIMMA2 JUSB5 M2_1 DIMMA1 JCI1 PCI_E1 M2_4 M2_2 PCI_E2 JBAT1 SATA▼1▲2 PCI_E3 M2_3 SATA▼3▲4 JDASH1 JRAINBOW1 PCI_E4 JFP2... -
Page 15: Cpu Socket
Always unplug the power cord from the power outlet before installing or removing ∙ the CPU. ∙ Please retain the CPU protective cap after installing the processor. MSI will deal with Return Merchandise Authorization (RMA) requests if only the motherboard comes with the protective cap on the CPU socket. ∙... -
Page 16: Dimm Slots
DIMM Slots DIMM Slots Please install the memory module into the DIMM slot as shown below. Please install the memory module into the DIMM slot as shown below. Memory module installation recommendation DIMMA2 DIMMA2 DIMMB2 DIMMA1 DIMMA2 DIMMB1 DIMMB2 Overview of Components... -
Page 17: Pci_E1~4: Pcie Expansion Slots
∙ If you install a large and heavy graphics card, you need to use a tool such as MSI Gaming Series Graphics Card Bolster to support its weight to prevent deformation of the slot. -
Page 18: Jfp1, Jfp2: Front Panel Connectors
JFP1, JFP2: Front Panel Connectors These connectors connect to the switches and LEDs on the front panel. HDD LED + Power LED + Power LED Power Switch HDD LED - Power LED - Reset Switch Power Switch Reserved Reset Switch Power Switch HDD LED Reset Switch... -
Page 19: Sata1~6: Sata 6Gb/S Connectors
SATA1~6: SATA 6Gb/s Connectors These connectors are SATA 6Gb/s interface ports. Each connector can connect to one SATA device. SATA2 SATA1 SATA4 SATA3 SATA6 SATA5 ⚠ Important Please do not fold the SATA cable at a 90-degree angle. Data loss may result ∙... -
Page 20: M2_1~4: M.2 Slot (Key M)
M2_1~4: M.2 Slot (Key M) Please install the M.2 solid-state drive (SSD) into the M.2 slot as shown below. 30º 30º (Optional) Supplied 30º 30º M.2 screw Standoff Overview of Components... -
Page 21: Atx_Pwr1, Cpu_Pwr1~2: Power Connectors
ATX_PWR1, CPU_PWR1~2: Power Connectors These connectors allow you to connect an ATX power supply. +3.3V +3.3V +3.3V -12V Ground Ground PS-ON# Ground Ground Ground ATX_PWR1 Ground Ground PWR OK 5VSB +12V +12V +3.3V Ground Ground +12V Ground +12V CPU_PWR1~2 Ground +12V Ground +12V... -
Page 22: Jusb1~2: Usb 2.0 Connectors
In order to recharge your iPad,iPhone and iPod through USB ports, please install ∙ MSI Center utility. JUSB3~4: USB 3.2 Gen 1 5Gbps Connector This connector allows you to connect USB 3.2 Gen 1 5Gbps ports on the front panel. -
Page 23: Jusb5: Usb 3.2 Gen 2 Type-C Connector
JUSB5: USB 3.2 Gen 2 Type-C Connector This connector allows you to connect USB 3.2 Gen 2 10 Gbps Type-C connector on the front panel. The connector possesses a foolproof design. When you connect the cable, be sure to connect it with the corresponding orientation. JUSB5 USB Type-C Cable USB Type-C port on the... -
Page 24: Cpu_Fan1, Pump_Fan1, Sys_Fan1~6: Fan Connectors
CPU_FAN1, PUMP_FAN1, SYS_FAN1~6: Fan Connectors Fan connectors can be classified as PWM (Pulse Width Modulation) Mode or DC Mode. PWM Mode fan connectors provide constant 12V output and adjust fan speed with speed control signal. DC Mode fan connectors control fan speed by changing voltage. -
Page 25: Jci1: Chassis Intrusion Connector
JCI1: Chassis Intrusion Connector This connector allows you to connect the chassis intrusion switch cable. Normal Trigger the chassis (default) intrusion event Using chassis intrusion detector Connect the JCI1 connector to the chassis intrusion switch/ sensor on the chassis. Close the chassis cover. Go to BIOS >... -
Page 26: Jbat1: Clear Cmos (Reset Bios) Jumper
20% brightness, the connector supports up to 200 LEDs. Always turn off the power supply and unplug the power cord from the power outlet ∙ before installing or removing the RGB LED strip. ∙ Please use MSI’s software to control the extended LED strip. Overview of Components... -
Page 27: Jrgb1: Rgb Led Connector
∙ Always turn off the power supply and unplug the power cord from the power outlet before installing or removing the RGB LED strip. Please use MSI’s software to control the extended LED strip. ∙ EZ Debug LED These LEDs indicate the status of the motherboard. -
Page 28: Installing Os, Drivers & Msi Center
MSI Center is an application that helps you easily optimize game settings and smoothly use content creation softwares. It also allows you to control and synchronize LED light effects on PCs and other MSI products. With MSI Center, you can customize ideal modes, monitor system performance, and adjust fan speed. -
Page 29: Uefi Bios
UEFI has many new functions and advantages that traditional BIOS cannot achieve, and it will completely replace BIOS in the future. The MSI UEFI BIOS uses UEFI as the default boot mode to take full advantage of the new chipset’s capabilities. -
Page 30: Bios Setup
* When you press F10, a confirmation window appears and it provides the modification information. Select between Yes or No to confirm your choice. BIOS User Guide If you’d like to know more instructions on setting up the BIOS, please refer to http://download.msi.com/manual/mb/Intel600BIOS.pdf or scan the QR code to access. UEFI BIOS... -
Page 31: Resetting Bios
Updating BIOS Updating BIOS with M-FLASH Before updating: Please download the latest BIOS file that matches your motherboard model from MSI website. And then save the BIOS file into the USB flash drive. Updating BIOS: Insert the USB flash drive that contains the update file into the USB port. - Page 32 Please download the latest BIOS file that matches your motherboard model from the MSI® website. Rename the BIOS file to MSI.ROM, and save it to the root of your USB flash drive. Connect the power supply to CPU_PWR1 and ATX_PWR1. (No need to install CPU and memory.)
- Page 33 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: ∙ This device may not cause harmful interference. ∙ This device must accept any interference received, including interference that may cause undesired operation. MSI Computer Corp. 901 Canada Court, City of Industry, CA 91748, USA (626)913-0828 www.msi.com...
- Page 34 Compliance with these directives is assessed using applicable European Harmonized Standards. The point of contact for regulatory matters is MSI, MSI-NL Eindhoven 5706 5692 ER Son. Products with Radio Functionality (EMF) This product incorporates a radio transmitting and receiving device. For computers in nor- mal use, a separation distance of 20 cm ensures that radio frequency exposure levels comply with EU requirements.
- Page 35 Wireless Radio Use This device is restricted to indoor use when operating in the 2.4GHz, 5GHz frequency band. Cet appareil doit être utilisé à l’intérieur. 당해 무선설비는 운용중 전파혼신 가능성이 있음. この製品は 、 周波数帯域 2.4GHz, 5GHz で動作しているときは 、 屋内においてのみ使用可能です 。 NCC無線設備警告聲明...
- Page 36 KC인증서 PRO Z690-A WIFI DDR4 상호: (주)엠에스아이코리아 제품명: 메인보드 모델명: Z690AW4 제조년월: 2021년 제조자 및 제조국가: MSI/중국 R-R-MSI-Z690AW4 PRO Z690-A DDR4 상호: (주)엠에스아이코리아 제품명: 메인보드 모델명: 10-7D25 제조년월: 2021년 제조자 및 제조국가: MSI/중국 R-R-MSI-10-7D25...
- Page 37 Chemical Substances Information In compliance with chemical substances regulations, such as the EU REACH Regulation (Regulation EC No. 1907/2006 of the European Parliament and the Council), MSI provides the information of chemical substances in products at: https://csr.msi.com/global/index Environmental Policy ∙...
- Page 38 MSI will comply with the product take back requirements at the end of life of MSI-branded products that are sold into the EU. You can return these products to local collection points.
- Page 39 MSI će poštovati zahtev o preuzimanju ovakvih proizvoda kojima je istekao vek tra- janja, koji imaju MSI oznaku i koji su prodati u EU. Ove proizvode možete vratiti na lokalnim mestima za prikupljanje.
- Page 40 Việt Nam RoHS Kể từ ngày 01/12/2012, tất cả các sản phẩm do công ty MSI sản xuất tuân thủ Thông tư số 30/2011/TT-BCT quy định tạm thời về giới hạn hàm lượng cho phép của một số hóa chất độc hại có...
- Page 41 MS-7D25主板产品中有害物质的名称及含量 有害物质 部件名称 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) 印刷电路板组件* ╳ ○ ○ ○ ○ ○ 纽扣电池 ○ ○ ○ ○ ○ ○ 外部信号连接头 ╳ ○ ○ ○ ○ ○ 其他 (例: 线材等) ╳ ○...
- Page 42 Copyright and Trademarks Notice Copyright © Micro-Star Int’l Co., Ltd. All rights reserved. The MSI logo used is a registered trademark of Micro-Star Int’l Co., Ltd. All other marks and names mentioned may be trade- marks of their respective owners. No warranty as to accuracy or completeness is expressed or implied.
