Club 3D CSV-1586 Quick Installation Manual

Thank you for purchasing our CSV-1586.
After unpacking the product, please make sure you have all the items provided and checked
for any damages. In case of any missing damaged parts please inform your supplier immediately.
You should have:
• Thunderbolt™ 3 to Dual DisplayPort™ 4K60Hz Adapter
The Club 3D CSV-1586 Thunderbolt™ 3 to Dual DisplayPort™ 4K60Hz Adapter lets users
easily connect two Displayport™ Screens @ 4K60Hzto any device with a Thunderbolt™ 3
interface.The output resolution supported is up to dual 4K60Hz or 8K60Hz/4K120Hz for a
single display. It is fully Plug & Play, so no need for driver installation. This stylish adapter
has a beautiful Brushed Aluminum Casing making it strong and light. This unique adapter
is compatible with both Mac™ OS Sierra and Windows™ 10. It is also very slim (15 mm /
0.59") making it easy to carry with you. Multiply your screen area with your tablet, desktop
PC or Ultrabook. With multiple monitors your computer will become more useful and
you will become more efficient and accomplish more. With 2 displays delivering 4K60Hz
performance, you can have four times the screen space compared to 1080p.
Connections
Upstream:
• 1x TB3™(40G) USB Type-C connector Female ( connection to Host)
• Support Thunderbolt™ 3 up to 40Gbps, compatible with
Thunderbolt™ 3, USB4™, DP Alt mode
• Support TB4™/USB4™/TB3™/DP-Alt-mode Hosts
Downstream:
• When connecting 2x displays - DP™ (4K60Hz) Female
Video1: DisplayPort™
Video2: DisplayPort™
• DisplayPort™ 1 + DisplayPort™ 2
• Support max 4K60Hz
• Support RGB
• Support 8bit deep color
• Support DP++
When connecting 1x Single display DisplayPort
it can support 3840*2160 at 120Hz or 8K30Hz
Above all video ports, allow to output max 2 videos when connected to Mac and Windows based Hosts
The actual resolution supported is determined by the Host and the Display together.
Highest resolutions are supported when Host and display Support DSC function
Warning Safe Usage: Only to be used at altitude 2000 meters/6562 feet and below.
Disclaimer: While we endeavour to provide the most accurate, up-to-date information available, the content on this document may be out of date or include omissions, inaccuracies or other errors. Products might obtain a certification during their lifetime. This doesn't change
or alter the product specifications and/or performance in any way. Club 3D will provide the updated information on their website www. Club-3d.com at her discretion. Therefore Club 3D does not accept any rights claimed on the content of this document. Please refer to a full
overview of our Legacy Terms and Conditions on www.club-3d.com. All other brand names are trademarks or registered trademarks and are the property of their respective owners. All content is subject to change without prior notice.
CSV-1586 QIG July 2024
CSV-1586 QUICK INSTALLATION GUIDE
Thunderbolt™ 3 to Dual DisplayPort™ 4K60Hz Adapter
Thunderbolt™ 3 Male
22 cm / 8.66"
0.67 cm
/ 0,26"
3.1 cm / 1.22"
In this document you can find:
Meassurements are approx.
Input:
DisplayPort™ 2X Female
10.8 cm / 4.25"
