ASPION L-Track and ASPION Cloud – User manual Table of contents ASPION L-Track IoT transport data logger General description - overview ......................... 3 Technical data ASPION L-Track ........................4 Export data (preliminary - all under review) ..................... 5 Mounting ..............................6 4.1 Mounting direction ..........................
Page 3: Aspion L-Track Iot Transport Data Logger
ASPION L-Track IoT transport data logger General description - overview The ASPION L-Track logs sensor values such as vibrations, shocks and climate data and sends them to the ASPION Cloud IoT platform in real time via mobile communications. The IoT device has many different sen- sors such as a 3-axis acceleration sensor for shock detection, temperature, humidity, pressure, inclination, and light sensors, etc.
Page 4: Technical Data Aspion L-Track
ASPION L-Track and ASPION Cloud – User manual Technical data ASPION L-Track Description Details ▪ Acceleration sensor 3-axis, x, y and z-axis calibrated up to ±16 g, 2.5 % accuracy ▪ up to ±24 g per axis up to ±24 g extendable at 3.5 % accuracy, verified by accred.
Page 5: Export Data (Preliminary - All Under Review)
ASPION L-Track and ASPION Cloud – User manual ▪ Possibly shorter runtime in low temperatures ▪ Battery replacement Housing can be opened via Maximum tightening torque 0.5 Nm Torx screws (T10) ▪ Measurement interval Temperature, humidity, Regular measuring interval of 1 h pressure, light ▪...
Page 6: Mounting
To record temperature and humidity, make sure that the white membrane (red border) on the top of the ASPION L-Track is not covered when packing the device. If lux values are to be recorded via the light sen- sor, keep the adjacent light sensor uncovered.
Page 7: Battery Replacement
Dimensions in millimeters - not to scale Battery replacement The ASPION L-Track uses four AA 1.5V alkaline batteries. These can be replaced by the user. Alternatively, lithium AA 1.5V batteries can be used (hazardous goods guidelines must be observed). Change the batteries as follows: 1.
Page 8: Firmware Updates
The initial synchronization of the device with the ASPION Cloud takes a few minutes. After that, a measure- ment is taken at every full hour and the first data transfer to the ASPION Cloud takes place after 8 hours. Then, you can view the measured values via the ASPION Cloud and configure the device. Please note that a device must be activated within 3 months of delivery.
Page 9: Fcc / Ised Warnings
RED Declaration of Conformity ▪ ASPION GmbH confirms that the L-Track complies with the essential requirements and other relevant provisions of Directive 2014/53/EU. This product can be used in all EU member states. ASPION L-Track User manual – Version 1.1.0 Copyright ©...
Page 10: Aspion Cloud
ASPION L-Track and ASPION Cloud – User manual ASPION Cloud The ASPION Cloud is used to visualize the sensor data and location information. The sensor data is visible immediately after transmission, processed and constantly updated with new data automatically. You can use the ASPION Cloud to set threshold values, set up alarms and evaluate the data.
Page 11: Aspion Cockpit - Home Page
"Administration" areas. Note: The Administration area is only shown if you have the rights to do so. ▪ User: After clicking on the user icon or your user name, you can log out of the ASPION Cloud or edit your user data (e.g. e-mail address, login data, password).
Page 12: Navigation & Groups
Navigation & Groups In the ASPION Cloud, you can use groups - like folder structures in a file system - to sort and manage your devices easily and clearly, e.g. to assign multiple devices to a delivery. The groups allow you to set up views and alarms (via Smart Rules) for all devices in a group.
Page 13 Other manufacturers and especially lithium batteries change the actual battery capacity and thus the runtime. ▪ Last transmission: Time of the last data transfer of the device data to the ASPION Cloud ▪ Transmission interval: Regular interval at which the measurement data of the L-Track is transmitted to the ASPION Cloud ▪...
Page 14: Create A New Group
ASPION L-Track and ASPION Cloud – User manual 14.1 Create a new group To create a new group, use the main navigation bar on the left-hand side to navigate to the group under which the new group is to be created. Now use the tabs at the top to switch to the "Groups and devices"...
Page 15: Device Configuration & Shock Activation
ASPION L-Track and ASPION Cloud – User manual Device configuration & shock activation In the device configuration, activate shock detection and GPS tracking if required and configure the trans- mission and measurement interval. You can access the configuration by selecting a group that contains the device (e.g.
Page 16 ASPION L-Track and ASPION Cloud – User manual ④ Transmission interval (with cell location): Select the interval at which the device transmits data and determines rough location information when there is a cellular connection. The transmission interval is a multiple of the measurement interval and can be between one hour and 3 days.
Page 17: Smart Rules, Alarms & Notifications
If no Smart Rules exist, create a new Smart Rule using the Add Smart Rule button. If there are already any, add a Smart Rule using the button of the same name at the top right-hand edge. The ASPION Cloud offers the following three types of smart rules: ▪...
Page 18 ASPION L-Track and ASPION Cloud – User manual 16.1.1 On measurement explicit threshold create alarm This Smart Rule can be applied to all measurement data. They can be used to monitor the following param- eters: ▪ Temperature: in degrees Celsius; suitable for detecting temperature overshoots/undershoots ▪...
Page 19 ASPION L-Track and ASPION Cloud – User manual Alarm type: The alarm type is primarily relevant for a possi- ble e-mail dispatch. Optionally, it is possible to assign the same alarm type to different Smart Rules and thus group the alarms (example description: "Temperature exceeded"...
Page 20 ASPION L-Track and ASPION Cloud – User manual 16.1.2 Generate alarm on geofence violation Create this smart rule to check whether a device has en- tered or left a certain area. This type of Smart Rule con- tains the following elements: At the top is the button for activating or deactivating the Smart Rule with the text "Switched on".
Page 21 ASPION L-Track and ASPION Cloud – User manual Alarm name: The name of this alarm should show which threshold value has been exceeded or fallen below and is displayed in the alarm overview as the title of the alarm. You should therefore use unique names and no duplications (example: "Warehouse left Karlsruhe").
Page 22 ASPION L-Track and ASPION Cloud – User manual 16.1.3 On alarm send email The third type of smart rule allows an e-mail to be sent automatically when an alarm occurs. The prerequi- site for this smart rule is another smart rule that generates an alarm for an event (either " Generate alarm at explicit threshold value "...
Page 23 ASPION L-Track and ASPION Cloud – User manual Severity of the alarm: #{severity} ▪ CRITICAL: Alarm with critical severity. Is the default value for Smart Rules with an explicit threshold value. ▪ MAJOR: Alarm with important severity ▪ MINOR: Alarm with less important severity ▪...
Page 24 ASPION L-Track and ASPION Cloud – User manual 16.1.4 Editing smart rules: To make it easier to create Smart Rules, there is a selection of templates in the "All devices" group on the Smart Rules tab that you can adapt to your requirements and activate for individual devices. You can edit or delete the templates using the three dots on the right.
Page 25: Alarms
Example: A smart rule for monitoring a temperature exceeding 30 degrees Celsius has been set up for the device. The L-Track carries out the following measured values and data transmissions: ▪ 8:01 a.m.: Last data transmission ▪...
Page 26 ASPION L-Track and ASPION Cloud – User manual ▪ 4:00 p.m.: 29,8 °C ▪ 4:01 p.m.: Next data transmission In this case, the alarm that was active at 15:00 is added directly to the alarm history with the data transmis- sion at 16:01 and does not appear in the active alarms.
Page 27: Device Details & Analysis
ASPION L-Track and ASPION Cloud – User manual Device details & analysis Clicking on a device takes you to the Overview page for that device. ① The main navigation is located on the left-hand side. The selected device is highlighted in green.
Page 28 ASPION L-Track and ASPION Cloud – User manual ① Use the selection list on the right to determine which data is displayed in the Data Overview. The axes with the units for all selected measured values are located to the left and right of the graph.
Page 29: Shock, Shock Details And Evaluation
ASPION L-Track and ASPION Cloud – User manual 17.1 Shock, shock details and evaluation Clicking on the Shock tab displays a diagram with data on all shocks and an extended list with the associ- ated shock details. These are important for the evaluation of a shock event, taking the location into ac- count.
Page 30: Tracking With Map
ASPION L-Track and ASPION Cloud – User manual 17.2 Tracking with map Click on the Tracking tab to display a map view with the location history. ① In the top bar on the left, set the time period to be displayed on the map. To do this, either select a freely selectable period on the left or a time span on the right starting from today's date (e.g.
Page 31: Administration
Administration At the start of using the ASPION Cloud, there is only one administrator for each company. His or her email is provided to the manufacturer in advance. The initial login link for the ASPION Cloud is sent to this email.
Page 32: Manage Users
ASPION L-Track and ASPION Cloud – User manual 18.1 Manage users The user administration shows your own user in the top entry. Click on the ">" arrow to the left of the username to display all subordinate users. ① Similar to the groups in the main navigation, you can see the structure of the subordinate users here.
Page 33: Add New User
The username cannot be changed once the user has been created. The username cannot contain spaces or certain special characters (/ + : $). The username is requested when logging into the ASPION Cloud. Note: For the automatically created administrator, the username is assigned automatically and consists of a com- bination of numbers.
Page 34: Edit Users And Assign Inventory Roles
ASPION L-Track and ASPION Cloud – User manual ③ User manager: Users with the user manager permission have access to the ASPION Admin view and can create new users. A user can only assign permissions to new users that they themselves have. The email address, password and authorizations for subordinate users can also be edited.
Page 35: Audit Logs
