- Page 1 13.56M RFID Reader U-60x Manual pper Co. mbH Quick-Ohm Kü & 13.56M RFID Reader QU-60x Serial Manual (version 1.6) ISO15693 ● English Web: www. uio-rfid.de EMAIL: onta t@ uio-rfid.de Phone/Fax: +49 – (0)202 404329 RFID module,RFID Reader/Writer RFID Tags 1 /23...
-
Page 2: Table Of Contents
13.56M RFID Reader U-60x Manual pper Co. mbH Quick-Ohm Kü & Content Introduction..........................4 QU-605 Serial ..........................4 Feature............................4 Specifications..........................5 Program Manual........................5 DLL API and functions......................5 Get the version of DLL..................5 DES.........................5 3DES........................6 3DES with vector....................6 Initial Serial Port..................7 Free Serial port....................7 Initial HID Port....................8... - Page 3 13.56M RFID Reader U-60x Manual pper Co. mbH Quick-Ohm Kü & SAM PPS Baud.....................22 Order Infomation........................23 RFID module,RFID Reader/Writer RFID Tags 3 /23...
-
Page 4: Introduction
13.56M RFID Reader U-60x Manual pper Co. mbH Quick-Ohm Kü & 1 Introduction YW-605 RFID reader/Writer is the 13.56M HF tags Reader and Writer.She Can support ISO14443A, ISO14443B and ISO15693 RFID tags. 2 YW-605 Serial 13.56M RFID Reader/Writer Protocol: A：14443A B：14443A+14443B... -
Page 5: Specifications
13.56M RFID Reader U-60x Manual pper Co. mbH Quick-Ohm Kü & 4 Specifications ☞ Baud：19200BPS ☞ Power： DC5V ± 10% ☞ Max Con： 1.5W ☞ Temp： -30℃ ～ +70℃ ☞ Humidity： 35% ～ 95% ☞ Size： 120 * 84 * 25 (mm) ☞... -
Page 6: Des
13.56M RFID Reader U-60x Manual pper Co. mbH Quick-Ohm Kü & cModel unsigned Direction: char Encryption ，1 Decryption pkey unsigned Key , 8 Bytees char* unsigned Data ,8 bytes char* unsigned Data after Des, 8bytes char* Return：0 3. 3DES prototype：intstdcall DES3(unsigned char cModel, unsigned char *pKey, unsigned char *In, unsigned char *Out);... -
Page 7: Initial Serial Port
13.56M RFID Reader U-60x Manual pper Co. mbH Quick-Ohm Kü & *pKey,unsigned char *In, unsigned char *Out, unsigned char *pIV); Param： Param Type cModel unsigned Direction: Encryption Decryption char ，1 pkey unsigned Key, 16Bytes char* unsigned Data ,8 bytes char*... -
Page 8: Initial Hid Port
13.56M RFID Reader U-60x Manual pper Co. mbH Quick-Ohm Kü & Return：1 success，0 fail 7. Initial HID Port prototype：int stdcall YW_USBHIDInitial(void); Param： Return：1 success，0 fail 8. Free HID Port prototype：int stdcall YW_USBHIDFree(void); Param： Return：1 success，0 fail 9. Change the serial port baud prototype：int... -
Page 9: Get Reader Id
13.56M RFID Reader U-60x Manual pper Co. mbH Quick-Ohm Kü & prototype：int stdcall YW_SetReaderID(int OldID, NewID); Param： Param Type OldID Old Reader ID NewID New Read ID Return：1 success，0 fail 11. Get Reader ID prototype：int stdcall YW_GetReaderID(int ReaderID); Param： Param... -
Page 10: Beep Control
13.56M RFID Reader U-60x Manual pper Co. mbH Quick-Ohm Kü & 14. Beep control prototype：int stdcall YW_Buzzer(int ReaderID,int Time_ON, Time_OFF, Cycle); Param： Param Type ReaderID Reader ID Time_ON Beep on time, unit:100ms Time_OFF Beep off time, unit:100ms Cycle The weeks of the beep on and off Return：1 success，0 fail... -
Page 11: Set Content Of 8 Led Display
13.56M RFID Reader U-60x Manual pper Co. mbH Quick-Ohm Kü & 04：Yellow Return：1 success，0 fail 16. Set Content of 8 LED display prototype：intstdcall YW_LEDDisplay(int ReaderID,int Alignment,char *LEDText); Param： Param Type Reader ID ReaderID Alignment Alignment 1：Left 2：Center 3：Right LEDText Char *... -
Page 12: Functions About Tags Of Iso15693
13.56M RFID Reader U-60x Manual pper Co. mbH Quick-Ohm Kü & prototype：int stdcall YW_SearchCardMode(int ReaderID,int SearchMode); Param： Param Type ReaderID Reader ID SearchMode char Tags 0x41-----ISO14443A 0x42----- ISO14443B 0x31----- ISO15693 0x53------ST Serail 0x52------AT88RF020 Return：1 success，0 fail Functions about Tags of ISO15693 19. -
Page 13: Select Tag Of Iso15693
13.56M RFID Reader U-60x Manual pper Co. mbH Quick-Ohm Kü & Param Type Reader ID ReaderID PUID unsigned UID(8Byte) of Tags char Return：1 success，0 fail 21. Select Tag of ISO15693 prototype：int stdcall YW_ISO15693_Select(int ReaderID, unsigned char Model, unsigned char *PUID);... -
Page 14: Read Block Of Iso15693 Tag
13.56M RFID Reader U-60x Manual pper Co. mbH Quick-Ohm Kü & Model=0x02 Select Tag with PUID unsigned UID(8Byte) of Tags char Return：1 success，0 fail 23. Read Block of ISO15693 Tag prototype：int stdcall YW_ISO15693_Read(int ReaderID,unsigned char Model,unsigned char *PUID,unsigned char StartBlockID,... -
Page 15: Write Block Of Iso15693 Tag
13.56M RFID Reader U-60x Manual pper Co. mbH Quick-Ohm Kü & 24. Write Block of ISO15693 Tag prototype：int stdcall YW_ISO15693_Write(int ReaderID,unsigned char Model, unsigned char *PUID, unsigned char BlockID,unsigned char DataLen, unsigned char *PData); Param： Param Type ReaderID Reader ID... -
Page 16: Write Afi Of Iso15693 Tags
13.56M RFID Reader U-60x Manual pper Co. mbH Quick-Ohm Kü & Bit0=1 Select Tag With Flag Bit1=1 Select Tag with UID Bit2=1 depends on the Tags UID(8Byte) of Tags PUID unsigned char unsigned BlockID The block ID char Return：1 success，0 fail 26. -
Page 17: Write Dsfic Of Iso15693 Tags
13.56M RFID Reader U-60x Manual pper Co. mbH Quick-Ohm Kü & prototype： int stdcallYW_ISO15693_Lock_AFI(intReaderID,unsigned char Model, unsigned char *PUID); Param： Param Type ReaderID Reader ID depends on the Model unsigned This value card . char Bit0=1 Select Tag With Flag... -
Page 18: Lock Dsfic Of Iso15693 Tags
13.56M RFID Reader U-60x Manual pper Co. mbH Quick-Ohm Kü & char Return：1 success，0 fail 29. Lock DSFIC of ISO15693 Tags prototype：int stdcall YW_ISO15693_Lock_DSFID(int ReaderID,unsigned char Model, unsigned char *PUID); Param： Param Type Reader ID ReaderID This value depends on the... -
Page 19: Get Security Of Blocks About Iso15693 Tag
13.56M RFID Reader U-60x Manual pper Co. mbH Quick-Ohm Kü & PUID unsigned UID(8Byte) of Tags char PData unsigned System Infomation char unsigned Length of System PLen char Infomation Return：1 success，0 fail 31. Get Security of Blocks about ISO15693 Tag prototype：int stdcall YW_ISO15693_Get_Block_Security(int... -
Page 20: Multi Inventtory Of Iso15693 Tags
13.56M RFID Reader U-60x Manual pper Co. mbH Quick-Ohm Kü & char Infomation Return：1 success，0 fail 32. Multi Inventtory of ISO15693 Tags prototype：int stdcall YW_ISO15693_Multi_Inventory(int ReaderID, unsigned char AFIEnable, unsigned char AFI, unsigned char *PData, unsigned char *PLen); Param： Param... -
Page 21: Sam Reset
13.56M RFID Reader U-60x Manual pper Co. mbH Quick-Ohm Kü & 0x01->19200 0x02->38400 0x03->55800 0x04->57600 0x05->115200 Return：1 success，0 fail 34. SAM Reset prototype：int __stdcall YW_SAM_Reset(int ReaderID,int SAMIndex, int *rtLen, unsigned char *pData); Param： Param Type ReaderID Reader ID SAMIndex SAM Index... - Page 22 13.56M RFID Reader U-60x Manual pper Co. mbH Quick-Ohm Kü & rtLen unsigned Length of pData char pData unsigned Data return after excution char of COS Command Return：1 success，0 fail 36. SAM PPS Baud prototype：int __stdcall YW_SAM_PPSBaud(int ReaderID,int SAMIndex, int BaudIndex);...
- Page 23 13.56M RFID Reader U-60x Manual pper Co. mbH Quick-Ohm Kü & 6 ISO15693 card operation 7 Order Infomation Quick-Ohm Kü pper Co. GmbH & WEB： www. uio-rfid.de Phone/Fax：+49–(0)202-404329 kontakt@ uio-rfid.de Email： MSN: coodor@126.com RFID module,RFID Reader/Writer RFID Tags 23 /23...
