WFM/WVR 7200/8200/8300
Power Supply Replacement Instructions
Installation safety summary
Terms in this manual
Telestream support
P00010811A
The Installation safety summary section contains additional information required
to safely perform installation on the product. Read this Installation safety
summary before performing any installation procedures.
Do not perform installation alone. Do not perform installation or adjustments
of this product unless another person capable of rendering first aid and
resuscitation is present.
Disconnect power. To avoid electric shock, switch off the product power and
disconnect the power cord from the mains power before removing any covers or
panels, or opening the case for servicing.
Installation questions. If you have any questions about the installation
procedure described in this document, please contact Telestream Support.
These terms appear in this manual:
WARNING.
Warning statements identify conditions or practices that could result
in injury or loss of life.
CAUTION.
Caution statements identify conditions or practices that could result in
damage to this product or other property.
NOTE.
Note statements are for conveying additional information about a topic. In
general, there are no safety or product related issues with a Note statement.
To obtain technical support contact us using our website, email, or phone number
listed.
Website: www.telestream.net/telestream-support
Email: videosupport@telestream.net
US and Canada Toll-free: 1-844-219-5329
Outside of US and Canada: 1-503-967-9833
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Telestream WFM 7200
Summary of Contents for Telestream WFM 7200
- Page 1 Installation questions. If you have any questions about the installation procedure described in this document, please contact Telestream Support. Terms in this manual These terms appear in this manual: WARNING.
-
Page 2: Kit Parts List
T-10 and T-15 TORX tips Used for removing and installing instrument screws Anti-static wrist strap Replacing the Power Supply For instructions on how to replace the power supply: • See Page 3 for WFM 7200/8200/8300 • See Page 11 for WVR 7200/8200/8300 P00010811A... - Page 3 WFM/WVR 7200/8200/8300 Power Supply Replacement Instructions Replace WFM 7200/8200/8300 Power Supply WARNING. Dangerous voltages may be present. To prevent electrical shock, disconnect the power cord from the unit before starting the upgrade procedure. Failure to do so could cause serious injury or death.
- Page 4 WFM/WVR 7200/8200/8300 Power Supply Replacement Instructions … and slide the shell off the back of the instrument. 4. Remove the top cover from the instrument by removing the 4 screws in the back and 2 screws in the top. Slide the top cover to the rear of the instrument and lift off. P00010811A...
- Page 5 WFM/WVR 7200/8200/8300 Power Supply Replacement Instructions 5. Remove the screws that secure the two cross braces and remove them. 6. Note the location of the Power Supply, AC Line Filter, Line cable, Load cable, and Load Control cable. After you change the components in your instrument, it is important to put them back in the same configuration.
- Page 6 (such as a needle-nose pliers) to reach in and press the latch. Instructions for removing the Option board can be found in the following instruction manual at telestream.net or contact Telestream Support. 075-1001-04 WFM720UP, WFM820UP, and WFM830UP Upgrades...
- Page 7 WFM/WVR 7200/8200/8300 Power Supply Replacement Instructions 10. Remove the screws that hold the power supply to the sled (there may be 2 or 4 screws depending on your configuration). Remove the old power supply and attached cables from the instrument. You will no longer need the old Power Supply and attached cables.
- Page 8 WFM/WVR 7200/8200/8300 Power Supply Replacement Instructions 11. Install the new power supply from the kit onto the sled using the same screws. Attach the Load (P00010671) and Load Control (P00010573) cables from the kit to the Power Supply. 12. Install the Supply/Sled assembly back into the instrument. It is easiest to install in the following order: a.
- Page 9 WFM/WVR 7200/8200/8300 Power Supply Replacement Instructions c. Secure the Supply/Sled assembly to the instrument using the same 4 screws from before. d. Connect the Line cable to the Power Supply. Secure the Line cable to the Sled if there are hold-downs features on the Sled. 13.
- Page 10 15. Replace the cross braces (step 5) and the top cover (step 4) before connecting the AC cable and turning on the instrument. NOTE: If the instrument does not power on or behaves in an unexpected manner, remove the AC power cord and contact Telestream Support. P00010811A...
- Page 11 WFM/WVR 7200/8200/8300 Power Supply Replacement Instructions Replace WVR 7200/8200/8300 Power Supply WARNING. Dangerous voltages may be present. To prevent electrical shock, disconnect the power cord from the unit before starting the upgrade procedure. Failure to do so could cause serious injury or death. CAUTION.
- Page 12 WFM/WVR 7200/8200/8300 Power Supply Replacement Instructions 4. Note the location of the Power Supply, AC Line Filter, Line cable, Load cable, and Load Control cable. After you change the components in your instrument, it is important to put them back in the same configuration. It is recommended to take photos of your instrument since there may be slight variations in the instrument configurations.
- Page 13 WFM/WVR 7200/8200/8300 Power Supply Replacement Instructions WARNING. Do not remove the plastic insulation sheet under the Power Supply. This is needed to ensure that the Power Supply remains electrically isolated from the chassis. P00010811A...
- Page 14 WFM/WVR 7200/8200/8300 Power Supply Replacement Instructions 8. Install the Power Supply and cables in the instrument. It is easiest to install in the following order: a. Mount the Power Supply on the chassis studs. b. Install mounting screws to secure the Power Supply to the chassis. There will be 2 or 4 mounting screws depending on your instrument.
- Page 15 10. Replace the top cover (step 3) before connecting the AC cable and turning on the instrument. NOTE: If the instrument does not power on or behaves in an unexpected manner, remove the AC power cord and contact Telestream Support. P00010811A...
