Philips GreenVision Xceed Gen2 BRP381 54LED448 Mounting Instruction

GreenVision Xceed Gen2
Mounting instruction
Technial Description
BRP381 54LED448
BRP382 72LED420
BRP382L 108LED290
BRP383 144LED220
BRP384 180LED178
Product Size
1. Switch off power before operation.
操作前请务必关闭电源。
2. It's not appropriate to install luminaires on interface with normal combustible material.
灯具不适宜直接安装在普通可燃材料表面。
3. The luminaire shall be installed by a qualified electrician and wired in accordance with the
latest IEE electrical regulations or the national requirements .
灯具应由有资格的电工安装，接线要符合IEE 电气标准或国家标准。
4. The light source of this luminaire is not replaceable; when the light source reaches its end
of life the whole luminaire shall be replaced.
灯具内光源不可以更换，当光源达到寿命时需要进行整个灯具的更换。
5. Controlgear shall be SELV (Uout:60Vdc).
控制装置应为SELV(Uout:60Vdc)。
IP66
RoHS
IK08
Power/W
LEDs
（max.）
54
72
108
144
180
Data subject to change without notice
Weight/
kg
≈5.3
140
173 ≈6
174
≈6.4
≈10
174
≈15.5
174
Philips and the Philips shield emblem are registered trademarks of Koninklijke Philips N.V.
444170264731
Wind force
area (m² )
0.14
0.16
0.19
0.23
0.33
≈5.3KG
≈6KG
≈6.4KG
≈10KG
≈15.5KG
Unit: mm
