FORM #92690.04-111115
Superlift Dual Steering Stabilizer system for 2005 and Newer
INTRODUCTION
Installation requires a professional mechanic. Prior to beginning, inspect the vehicles steering,
driveline, and brake systems, paying close attention to the suspension link arms and bushings,
anti-sway bars and bushings, tie rod ends, pitman arm, ball joints and wheel bearings. Also check
the steering sector-to-frame and all suspension-to-frame attaching points for stress cracks. The
overall vehicle must be in excellent working condition; repair or replace all worn parts.
Read instructions several times before starting. Be sure you have all needed parts and
know where they install. Read each step completely as you go.
NOTES:
An arrow on diagrams indicates which direction is toward the front of the vehicle.
A foot-pound torque reading is given in parenthesis ( ) after each appropriate fastener.
Do not fabricate any components to gain additional suspension height.
Prior to attaching components, be sure all mating surfaces are free of grit, grease,
undercoating, etc.
A factory service manual should be on hand for reference.
Use the check-off box "" found at each step to help you keep your place. Two ""
denotes that one check-off box is for the driver side and one is for the passenger side.
Unless otherwise noted, always start with the driver side.
PARTS LIST ... The part number is stamped into each part or printed on an adhesive label.
Identify each part and place the appropriate mounting hardware with it.
PART NO
55-10-92690 ................ stabilizer mount, driver side ......... (2) 3/8" x 1-1/2" x 2-1/2" U-bolt
55-20-92690 ................ stabilizer mount, ........................... (2) 3/8" x 1-1/2" x 2-1/2" U-bolt
55-30-92690 ............... stabilizer mount, center ................ (2) 3/8" x 1" bolt
PRINTED IN U.S.A.
Ford F-250 / F-350 Super Duty 4WD
INSTALLATION INSTRUCTIONS
DESCRIPTION
(Qty.- if more than one)
passenger side
NEW ATTACHING HARDWARE
(Qty.- if more than one)
(4) 3/8" flange nut
(1) 1/2" x 2-3/4" bolt
(1) 1/2" USS washer
(1) 1/2" stover nut
(4) 3/8" flange nut
(1) 1/2" x 2-3/4" bolt
(1) 1/2" USS washer
(1) 1/2" stover nut
(2) 3/8" SAE washer
PAGE 1 OF 5
