YN8405

3-Port HDMI KVM

Docking Station

Instruction Manual

Table of Contents

Need help?

Do you have a question about the YN8405 and is the answer not in the manual?

Questions and answers

Summary of Contents for Nextech YN8405

Page 1 YN8405 3-Port HDMI KVM Docking Station Instruction Manual...
Page 2: Table Of Contents
CONTENTS CONTENTS Before First Use ....................... 2 Box Contents ........................3 Features ..........................3 Product Diagram ......................3 Connection ........................4 Application .........................5 Usage Instructions ......................7 Troubleshooting ......................8 Specifications ........................9 Warranty Information ....................10 BEFORE FIRST USE Prior to using your product, please read all the safety and operating instructions thoroughly.
Page 3: Box Contents
BOX CONTENTS 1x Combo KVM Switch 1x USB-C cable 2x HDMI cable 1x User Manual 2x USB-A cable FEATURES • Support Power Deliver 3.0 charge • HDMI 2.0 standard, HDCP 2.2 format. compliant • Support All PD 3.0 device charging. •...
Page 4: Connection
NOTE: YN8405 power input must connect PD power adaptor that came with the laptop or source device. Make sure the source device power adaptor supports the PD charge format. CONNECTION Laptop...
Page 5: Application
APPLICATION KVM mode • Shared Web cam, USB mouse, keyboard and monitor device. • Shared files on your USB flash drive. • Shared printer equipment, Web cam. Installation Steps Connecting HDMI input device (A) HDMI input device : PC, NB, Streaming player, PS4 Pro, Xbox one, OTT box, Set Top Box Connecting USB-C input device (B) USB-C input : Android phone, Android tablet, Windows NB/PC, iPad Pro, MacBook Air, Pro, Surface, Chromebook...
Page 6 Mirror mode Display phone, tablet , PC device screen on big screen. Installation Steps Connecting USB-C input device (A) USB-C input : Android phone, tablet, Windows NB/PC, iPad Pro, MacBook Air, Pro, Surface, Chromebook Connecting output device (B) Connecting external signal source PD power adaptor (C)
Page 7: Usage Instructions
If your source is support keyboard and mouse: Connect a USB-A to A cable to your source device’s USB port and connect another end to YN8405 input USB port 2 to 3. Step 2: Connect a HDMI cable to your display device’s HDMI port and connect another end to YN8405 output port.
Page 8: Troubleshooting
• Check if the connection is correct. • Check if the USB-C cable is damaged. • Check if the HDMI cable is damaged. • Check if YN8405 is powered on, or restart YN8405 Only video output, but • Check if the HDMI cable is well connected.
Page 9: Specifications
SPECIFICATIONS Input Port 1 USB–C DP Alt mode (Type C 24-pin female) Input Port 2 HDMI Receiver (Type A 19-pin female) USB-A Transmitter (USB 2.0 TYPE A) Input Port 3 HDMI Receiver (Type A 19-pin female) USB-A Transmitter (USB 2.0 TYPE A) Output Port HDMI Transmitter (Type A 19-pin female) USB-A Transmitter (USB 2.0 TYPE A)
Page 10: Warranty Information
WARRANTY INFORMATION Our product is guaranteed to be free from manufacturing defects for a period of 12 Months. If your product becomes defective during this period, Electus Distribution will repair, replace, or refund where a product is faulty; or not fit for intended purpose. This warranty will not cover modified product;...
