Avsl av:link USC401 Installation Manual

Item No.:USC401
2
12
400x400 30kg 26"-55" 55-390mm
A1 A2 A3 A4 A5
x4 x4 x4 x4 x4
M4x20mm M5x20mm M6x20mm M8x30mm
B1 B2 B3
x3 x3 x3
x1 x1
x1
M6 M8
5x5 Allen Key
Bracket
x1
x1
x2
Wall plate
Wall plate cover
M6x12mm
Cable cover
B2 B3
Notice: Please ensure you
B1
fasten the self-tapping
screws so that the fixing
plate is tight to the wall.
Failure to do this could
result in damage to
persons or property.
B3 B1
STEP2-A
A6
x4
TV plate
STEP2-B
Spirit Level
STEP3
Spirit Level
Notice: Please ensure you
fasten the self-tapping
screws so that the fixing
plate is tight to the wall.
Failure to do this could
result in damage to
persons or property.
A5
Tighten or loosen the M6 screws on the TV plate to
keep it level
Bracket
M6
TV plate
1
M6x12mm
M8
2
Tighten or loosen the M8 screws on the TV plate
to adjust the tilting function
A5
A6
A1/A2/A3/A4
A6
A1/A2/A3/A4
Tighten
M6x12mm
