GETTING STARTED
● Setup instructions
Setup 1 - DESKTOP STAND / BOOM ARM
○
Setup 2 - IMPORTANT
○
Setup 3 - AUDIO CONFIGURATION
○
IMPORTANT - Setup 4 - SCROLL WHEEL
○
Setup 5 - SCROLL WHEEL LED
○
Setup 6 - SMART AUDIO LOCK
○
Setup 7 - DOWNLOAD G HUB
○
Setup 8 - BLUE VO!CE
○
● Specifications
FAQs
How to prevent distortion and maintain mic gain level on my Yeti GX?
●
How to use two Gaming Microphones at the same time on macOS by setting up an
●
aggregate device.
My Gaming mic won't turn on.
●
My Gaming mic does not pick up audio on my macOS computer.
●
My Gaming mic is not picking up audio on my Windows computer.
●
My Gaming mic is not being recognized on my Windows computer.
●
Can I mount Yeti GX on my Boom Arm?
●
Yeti GX
INDEX
Yeti GX FAQs
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Logitech Yeti GX
Summary of Contents for Logitech Yeti GX
- Page 1 Setup 8 - BLUE VO!CE ○ ● Specifications FAQs How to prevent distortion and maintain mic gain level on my Yeti GX? ● How to use two Gaming Microphones at the same time on macOS by setting up an ●...
-
Page 2: Warranty
Do I need Logi G HUB software for my Yeti GX? ● Can I change the colors of the Logi G logo and RGB ring lights on my Yeti GX? ● What does the LED on my Yeti GX scroll wheel indicate? ●... -
Page 3: Connect Your Device
SETUP INSTRUCTIONS SETUP 1 - DESKTOP STAND / BOOM ARM Mount your new Yeti GX microphone to either the included desktop stand or a boom arm. 2. Plug in the USB-C end of the cable to the port at the bottom. - Page 4 Yeti GX FAQs SETUP 2 - IMPORTANT! Be sure the flat part of the windscreen is pointing towards you! SETUP 3 - AUDIO CONFIGURATION Open any streaming or recording software with audio configuration.
- Page 5 Yeti GX FAQs 2. Within the settings of the software, you may need to select Yeti GX as the active microphone. SETUP 4 - SCROLL WHEEL The scroll wheel adjusts your microphone gain. While speaking in a normal voice that you would use while streaming or recording, adjust the gain by scrolling the wheel.
- Page 6 Yeti GX FAQs SETUP 5 - SMART AUDIO LED The LED on the scroll wheel also indicates if the mic is being used. Solid white means your mic is powered on. 2. Solid green means your mic is actively delivering audio.
- Page 7 Yeti GX FAQs SETUP 6 - SMART AUDIO LOCK After you are happy with the gain setting, click the wheel in to enable Smart Audio Lock. The LED on the wheel will turn Cyan when enabled. Smart Audio Lock: smartly adjusts your gain by using an analog limiter to prevent clipping and a downward expander to reduce ambient background noise.
- Page 8 Yeti GX FAQs SETUP 8 - BLUE VO!CE Click the Microphone menu in G HUB to access BlueVo!ce presets, effects, and ● processing like EQ and noise reduction. You can also enable the Smart Audio Lock from this screen. To try different settings, first record a sample of your voice, then press play.
- Page 9 Yeti GX FAQs Click the LIGHTSYNC menu in GHub to ● customize the lighting in the RGB ring and G logo. Choose from easy presets, or use the ● freestyle and animation tabs for full customization.
-
Page 10: Specifications
Yeti GX FAQs SPECIFICATIONS Product Dimensions Component Height Width Depth Cable Length Weight Product 170 mm 100 mm 100 mm 616 g Packaging with product 84 mm 142 mm 310 mm 990 g Technical Specifications Type Of Transducer Dynamic Self-Noise... - Page 11 Yeti GX FAQs Technical Specifications Output Sensitivity -55 dBFS Max Spl 135 dB 0.10% Signal-To-Noise Ratio 78 dB Computer Connectivity Dynamic Range 95 dB Acoustic Principle Dynamic Minimum OS Requirements Mac / Windows that supports USB audio Power supply 5v USB...
- Page 12 Yeti GX FAQs Power, Temperature & Gain Specifications Operational temperature Temperature °C range Power consumption Max Current Gain Gain Slider Range Microphone Preamp Gain...
- Page 13 ● How to prevent distortion and maintain mic gain level on my Yeti GX? Yeti GX comes with a Smart Audio Lock that uses a built in professional quality audio processing to hold your level where it is, preventing it from Clipping and distortion.
- Page 14 Yeti GX FAQs Yeti Nano: 2 devices - select both to aggregate device ● Snowball: 2 devices - select both to aggregate device ● 4. The Aggregate will now act as your Input Device within any software or applications you plan to use. Please set it as the default device in the recording tab of your sound menu, and in your application.
- Page 15 Yeti GX FAQs Avoid using hubs or docks where possible, especially if they have intermediate ● software for device detection and management. Test the device with a USB port directly on the computer. Mobile and tablet adapters may not provide adequate power or recognize the ●...
- Page 16 Yeti GX FAQs On the Recording tab double click on the Gaming Mic to open the Properties Menu. ● Select the Levels tab then select an appropriate volume level (start at midway point of ● the slider & adjust from there) and make sure that the speaker icon is not muted.
- Page 17 ● Can I mount Yeti GX on my Boom Arm? Yes, you can. Your Yeti GX comes with a ¼” thread on the end of the yoke arm and a detachable base with ¼” thread. The package includes an adapter that allows for ¼” to mount to both ⅝”...
- Page 18 Yeti GX FAQs ● Do I need Logi G HUB software for my Yeti GX? You can use your Yeti GX with or without G HUB software. You can adjust the following without installing G Hub: Dedicated Mute button ●...
- Page 19 Yeti GX FAQs...
- Page 20 Yeti GX FAQs ● Can I change the colors of the Logi G logo and RGB ring lights on my Yeti GX? Using GHub, the LED ring and G logo can be customized for decorative lighting purposes. Examples of desired animations/functions include: Boot animation ●...
- Page 21 Yeti GX FAQs The LED colors on the microphone scroll wheel indicates the following functional information: LED Color Description White Mic is powered on (but not currently being used by any program). Green Mic is active and being used by a program.
- Page 22 To learn more about what each effect does, visit the Logitech Blue VO!CE page. ● Logitech G HUB - FAQs VIDEO: Introduction to Installation to Logitech G Hub About G HUB What is G HUB? ● Can I use G HUB offline? ●...
-
Page 23: Troubleshooting
How can I make sure my G HUB Settings are saved? ● Enable On-Board Memory mode on your gaming mouse with G HUB ● Do I need to uninstall Logitech Gaming Software to use G HUB? ● How to create a macro in G HUB that opens a file ●... - Page 24 WARRANTY - YETI GX 2 year limited hardware warranty At Logitech, it is our goal to ensure you are completely satisfied with your Logitech purchase. We take pride in the products and services we offer, and want our customers to enjoy them just as much as we do.
