Summary of Contents for MediTek MT-PAC
- Page 1 MT-PAC DIGITAL PLANT ALARM CONTROLLER INSTALLATION & OPERATING MANUAL S/N #### Hospital Name 8 Park Edge Mews 21 Link Way, Edgemead, 7407 Cape Town RSA Tel (27) (021) 558-7040 gas@mediteksystems.co.za www.mediteksystems.co.za...
-
Page 2: Table Of Contents
INDEX PAGE DESCRIPTION WIRING SCHEMATIC SETTINGS MAINTENANCE SPECIFICATIONS DIMENSIONS TROUBLESHOOTING WARRANTY... -
Page 3: Description
Any other control point, whether it’s a 4-20Ma output, VF Contact, Medbus® or Modbus®, the MT-PAC can monitor it. The MT-PAC can fully read the MT-APN16 Medbus® signal of the Meditek Systems legacy equipment and display all the available information. -
Page 4: Wiring Schematic
SCHEMATIC WIRING DIAGRAM Page 2... -
Page 5: Settings
SETTINGS Each alarm system is programmed and calibrated before leaving the factory and no maintenance or adjustment should be required. If any of the alarm levels needs to be changed, this may be done by qualified personnel only. Press on the “Settings” touch screen button and enter the password. All alarm setting relevant to that system will be displayed and changes can be made in real-time. -
Page 6: Specifications
SPECIFICATIONS POWER SUPPLY • 80 to 240 Volt ac 50 Hz supply 36W. • Resettable surge suppressers. • 12V standby charger with Li battery (optional). • 12VDC 3A output • Fuse 22mm 3A glass cartridge. INPUTS • Multiple 8 input channels. •... -
Page 7: Dimensions
DIMENSIONS Page 5... -
Page 8: Troubleshooting
TROUBLESHOOTING The MT-PAC Alarm System contains no user serviceable components. All repairs and maintenance must be carried out by qualified, Meditek Systems’ appointed personnel. Failure to comply may render any warranty null and void. All panels are factory set and configured prior to installation. Changing any settings may cause the entire alarm network to malfunction. -
Page 9: Warranty
Warning: Dealers, installers and/ or other selling, distributing Meditek Systems product (s) are not authorized to modify this warranty or make any additional warranties. Meditek Systems may change the terms of its limited warranty, without notice, as its discretion. Limitations of Alarm Systems: It must be understood that while your Meditek Systems product is highly advanced and sophisticated, it does not offer any guaranteed protection in case of emergency.
