- Page 1 User's Guide ELPMB84 Projector Stacking Frame Beta V12H006AW0 email: info@euromet.com...
-
Page 2: Safety Precautions
In order to avoid injuries, it is necessary to comply with the following safety rules: • Use ELPMB84 with a projector only in environments which are not exposed to weather events. • Make sure the projector is compatible with the cage on which it is fitted, as using incompatible projectors could cause serious damages and injuries. - Page 3 • Always fasten ELPMB84 to the TRUSS with a steel safety cord using the specific eyelets: in case of fault or failure, the cord must ensure the cage not to be falling down lower than 5 cm. • Please read the local rules and regulations to comply with any possible additional safety rules for hanging loads.
- Page 4 General information and compatibility ELPMB84 is a support system for EPSON video-projectors. Compatible projectors are: EB-PU2213B, EB-PU2113W (13 000 lumen) EB-PU2216B, EB-PU2116W (16 000 lumen) EB-PU2220B, EB-PU2120W (20 000 lumen) and similar. Furthermore, all series L-1000 projectors are also compatible, yet they require an optional...
- Page 5 (005) in the box. VERTICALLY STACKED POSITION It is possible to stack 2 ELPMB84 (by hanging them) up to maximum 3 ELPMB84 (when on the ground). To stack 2 cages it is necessary to: 3.1 - Place the 4 female upper cage pins onto the 4 male lower cage pins (006), perfectly...
- Page 6 ELPMB84 can also be stacked laterally. In this case it is necessary to: 4.1 – Place 2 ELPMB84 in a parallel way on the ground; 4.2 – Make sure the (upper and rear) lateral eyelet pairs are coaxial; 4.3 – Use the screws, washers and nuts set (009) to fasten the cages to each other;...
- Page 7 ADDITIONAL UPPER/REAR BAR (ELPMB80 – ELPMB83) It is an option that is compatible with ELPMB84 and is used to fasten the cage to a truss by hanging it from the upper or rear side (not compatible with ELPMB76). To fasten the bar (in both cases): 6.1 –...
- Page 8 2) Whereas in the upper position, the possible projections modes are: 2.1) Landscape 2.2) Portrait ADDITIONAL SIDE BAR (ELPMB78) It is based on the same principle as the additional upper/rear bar, although the latter must be fastened laterally and has a single Clamp. To assemble the items, follow the same procedure illustrated in the previous chapter.
- Page 9 STANDARD EUROMET FASTENING (FOR OPT) ELPMB84 has a 100x100 mm centre distance with M8 thread to fasten all Euromet OPT equipped with the same standard fastening system. ELPMB84 has another 100x200 fastening system that can be useful when securing Kite (see chapter 11B).
- Page 10 • Place ELPMB84 with the plate turned upwards; • Apply ELPMB81 to the plate and screw the unlosable handles (015) to the ELPMB84 4 female M8 threaded holes with 100x100 distance (tighten the 4 threads manually with the knob);...
- Page 11 ELPMB76 can be attached via upper bar (ELPMB80/83) using the Exhagon Plate and the ELPMB81 for a micrometric adjustment of the projector.
- Page 12 • Overlap the 2 plates holes (the ones with 100x200 distance) • Fasten them with 4 M8 screws and washers Once ELPMB84 has been secured to ELPMB77, it is also possible stack another cage (this way both cages are secured to each other, but can be adjusted against the ELPMB77 fastening position).
-
Page 14: Maintenance
Maintenance Do not try to service this product yourself, except as specifically explained in this User’s Guide. Refer all other servicing to qualified service personnel. HARDWARE’S INSPECTION The ELPMB79 arm adapter does not require special maintenance, but a visual inspection must be conducted before each installation involving the system.
