- Page 1 ENERGY LINE CB522-3 Dealer ISTRUZIONI D’USO USER’S MANUAL INSTRUCTIONS D’EMPLOI BEDIENUNGSANLEITUNG ed. 12/2018 cod. 000245A Rev.01 ELECTRONICS FOR CARAVANNING...
-
Page 2: General Information
SWITCH-MODE BATTERY CHARGER GENERAL INFORMATION The CB5 22-3 switch-mode battery charger has T he battery charger is protected against been expressly designed for the caravanning and overtemperature and the 12V outputs are boating sector and can automatically charge 12V protected against short circuit and polarity inversion. lead batteries, with different charging values The high frequency switching technology allows according to the position set using the selector... - Page 3 - 12V supply SIGNAL Net signal «S» ( +12V (To connect to CBE equipment) CONNECTION BATTERY TEMPERATURE SENSOR Temperature sensor (mod. “C TCB”) to be placed close to the battery , where it cannot be affected by other heat sources...
-
Page 4: Specifications
SPECIFICATIONS INPUT TECHNICAL DATA Nominal voltage 230V ± Frequency 50÷60 Hz Maximum power 320 W Protection fuse ref. F2 T 3.15 glass 5x20) Safety switch 230V Lumino us OUTPUT TECHNICAL DATA 14, V ( ) - 14, V B - 14,7V Bulk voltage ... -
Page 5: Installation
4 sides. > Exhausted batteries shall be disposed in - T he battery charger can be installed together with accordance with existing environmental CBE 12V and 230V distribution panels, using the protection regulations. appropriate modular joints. - Page 6 CBE S.r.l. Via Vienna 4 z.i. Spini (settore D) 121 Trento - Italy Tel. +39 0461 991598 Fax +39 0461 960009 cbe@cbe.it www.cbe.it ELECTRONICS FOR CARAVANNING...
