Summary of Contents for Logitech TS100
- Page 1 TS100 日程显示屏 Setup Guide | 设置指南...
-
Page 2: What's In The Box
WHAT’S IN THE BOX 包装内容... - Page 3 TS100 日程显示屏 Setup Guide | 设置指南 Touch panel Multi-surface mount Bridge and cover Mullion mount bracket Documentation 简体中文 简体中文 简体中文 简体中文 多表面安装配件 连接件和盖板 竖框安装支架 文档 简体中文 触控面板...
-
Page 4: Before You Begin
BEFORE YOU BEGIN 开始之前 简体中文 You will need 您需要 - Scheduling Service Credentials - 日程服务凭证 - Ethernet Cable(s) - 以太网线缆 - PoE enabled network OR - 支持 PoE 的网络， 或者 - PoE Injector and network (Ethernet or WiFi) - PoE 电源适配器和网络 （以太网或 WiFi）... -
Page 5: Recommended Placement
RECOMMENDED PLACEMENT 建议安装位置 48” - 60” 1.2 米 - 1.5 米... -
Page 6: Wall Mount
WALL MOUNT 墙面安装配件... - Page 7 WALL MOUNT 墙面安装配件...
- Page 8 GLASS MOUNT 玻璃安装配件...
- Page 9 GLASS MOUNT 玻璃安装配件...
- Page 10 MULLION MOUNT 竖框安装配件...
- Page 11 MULLION MOUNT 竖框安装配件...
-
Page 12: Junction Box Mount
JUNCTION BOX MOUNT 接线盒安装配件 1 - Gang 2 - Gang 3 - 60mm 简体中文 简体中文 简体中文 1 - 连接孔 2 - 连接孔 3 - 60 毫米... - Page 13 CONNECT TO POE 连接 POE电源适配器 Connect to PoE enabled network or PoE Injector 简体中文 连接到支持 PoE 的网络或 PoE 接头...
-
Page 14: Configure Device
CONFIGURE DEVICE 配置设备 Follow on-screen prompts to complete setup 简体中文 按照屏幕上的提示完成设置... -
Page 15: Factory Reset
FACTORY RESET 恢复出厂设置 Press and hold (A) Pinhole Button for 5 seconds, press (B) Reset button, release (B) then release (A) 简体中文 按住 (A) 针孔按钮 5 秒钟， 按下 (B) 重置按钮， 松开 (B) 然后松开 (A) - Page 16 © 2021 Logitech. Logitech, Logi, 罗技 and the Logitech Logo are trademarks or registered trademarks of Logitech Europe S.A. and/ or its affiliates in the U.S. and other countries. All other trademarks are the property of their respective owners. Logitech assumes no responsibility for any errors that may appear in this manual. Information contained herein is subject to change without notice.
