MOUNTING INSTRUCTIONS
WALLMOUNT ADAPTER
This manual applies to the following products: Wallmount Adapter 100 BK, Wallmount Adapter 100 WH
UNBOXING
Open the package with caution. Remove the adapt-
ers and separate them from the protective film.
DRILLING
Use a drill to drill the hole on the markings.
EQUIPMENT
The following
equipment is required to install the adapter:
✓ Spirit level ✓ Drill
✓ Pencil ✓ Drill attachments
✓ Screwdriver ✓ Dowels (4 × 6 mm, not included)
✓ Ruler ✓ Screws (4 × 6 mm, not included)
✓ Washers (not included)
Depending on the nature of the wall, you may need to use
plasterboard dowels instead.
DETERMINING THE POSITION
OF THE UPPER ADAPTER
To determine the positions of the holes, apply markings
to the wall in advance using the spirit level and a ruler.
Position one of the adapters on the wall as an upper
bracket and align it using the spirit level. Make sure that
the upper adapter points downwards. Use a pencil to
mark the drill holes.
