Summary of Contents for PROCET PT-PSE109GMN-A-S
- Page 1 PT-PSE109GMN-A-S PoE Injector uick Installation Guide www.procetpoe.com...
- Page 2 Ｄｅｃｌａｒａｔｉｏｎ This document belongs to PROCET company. It is not allowed to reproduce and modify without the original author's permission. It is PROCET's policy to improve its products as new technology, components, software, and firmware at any time. PROCET, therefore, reserves the right to change specifications without prior notice.
- Page 3 This manual includes the following chapters: 1. Product Introduction. Including the basic functions and specification of PT-PSE109GMN-A-S, as well as the product appearance and applications introduction. 2. Installation Introduction. Introducing the preparation work and precautions before installing the product.
-
Page 4: Table Of Contents
Table of Contents 1. Introduction 1.1 Introduction.................01 1.2 Appearance.................01 1.3 Specification...............03 1.4 Management Interface...........04 2. Installation Preparation 2.1 Package contents.............06 2.2 Installation tookit..............06 2.3 Inspection................06 3. Installation 3.1 Installation in waterproof case........08 3.2 Installation on wall............09 3.3 Connection................. 11 3.4 Grounding................ -
Page 5: Introduction 01
1. Introduction 1.1 Introduction PT-PSE109GMN-A-S, a single port fiber PoE Injector with Managed Ethernet function. Supports IEEE 802.1Q VLAN and port-based VLAN. We can access and manage the device via web browser, including IP configuration, port configuration, VLAN configuration, PoE configuration, device control, etc. We can also view device information such as switch status, port status, and PoE status etc. - Page 6 Side View Cooling holes Side View Front View PoE Port SFP Fiber Indicator Power Indicator LAN Data Port SFP Port GND Terminal AC Power Port 1-3 Front View Installation...
-
Page 7: Specification
PoE Indicator Display Items Status Descriptions Power Normall PoE Load Indicator Flashing Detecting （Green） Data Good Connection Indicator Flashing Data Transferring （Yellow） Light Off stem abnormal or power off 1.3 Specification Items Descriptions Interface PoE*1 LAN*1 SFP*1 AC*1 GND*1 Input 100-240Vac 2.0A 50/60Hz Output 55Vdc 2.2A... -
Page 8: Management Interface
1.4 Web Management When all network connection is completed, run web browser on the computer, type in the address field, for example, 192.168.1.151, then press ENTER for opening the login page. Log into the system with a username and password. The login page is displayed in the below pic. Caution: Make sure the computer must be set on the same IP subnet address as the PoE managed switch. - Page 9 The current device supports VLAN segmentation function. Users can flexibly segment the VLAN according to demand. This Page supports the PoE configuration function, disables or enables PoE port, displays per PoE port power consumption, voltage, current, and Class level information. Management Interface...
-
Page 10: Installation Preparation
2. Installation Preparation 2.1 Package contents Open the box of the PT-PSE109GMN-A-S and carefully unpack it, the box should contain the following items: Ground PT-PSE109GMN-A-S Operating Manual AC Power Cord lug Wire&2.5 Screw 2.2 Installation toolkit These tools may be needed during equipment installation, and should... - Page 11 9.Do not use with 24V DC PDs. This unit outputs 55V, which may damage 24V DC input devices (due to voltage mis ‐ match). To ensure better lightning protection for outdoor PD,it is recommended to use PROCET Ethernet surge protection products. For more information, please visit http://www.procetpoe.com Installation Preparation...
-
Page 12: Installation
3. Installation This product is safe to use for waterproof case installation and wall-mounted installation. 3.1 Installation in waterproof case If it is placed in an outdoor environment, please install the device in a wa terproof case with a height of 45cm if possible. 3.1.1Install the waterproof case first, and keep the case open. -
Page 13: Installation On Wall
3.1.2 Remove the metal backplate from the waterproof case and fix the product on the backplate with screws. 3-2 Installation on backplate 3.1.3 Reinstall the backplate into the waterproof case. 3.2 Wall-mounted Installation 3.2.1Mark the screw hole positions with marking pens. 3.2.2 Drill 8mm diameter round holes at the marked screw hole locations. - Page 14 Bolt depth ≤ 60mm Bolt depth 3.2.3Pass the protruding screws through the product's mounting holes and tighten them down with nuts. Wall 3-4 Wall-mounted Installation Installation...
-
Page 15: Connection
Waterproof Ethernet cables should be with a protective sheath. CAT5e/6 cables are recommended. 3.4 Grounding PROCET PoE switch PT-PSE109GMN-A-S has the following grounding solutions for reference during construction: If the installation is in the computer room, it can be connected to the dedicated grounding busbar in the room. - Page 16 GND Terminal 2.5 Screw Grounding Busbar 3-5 Grounding For the safety of personnel and equipment in an environment without dedicated grounding equipment, a simple grounding device can be constructed as follows: a. Prepare a 6mm 2 grounding wire or a braided soft copper wire. b.
-
Page 17: Inspection
GND Terminal 2.5Screw Ground Soil 2200 3-6 Simple Grounding 3.5 Inspection Inspect the installed equipment before putting it into operation： · Make sure the PD can be powered by 44-57Vdc PoE. · Make sure the Ethernet cable connection is correct. Make sure all connections are correct, and turn on the power, inspect all the indicators. - Page 18 Qualification Card PASS Creative Lianjie Network Technology Co.Ltd www.procetpoe.com...
