Cair Connect Programming Manual

Programming
Guide
V 1.1
Specifications
Compatibility Tunstall / TeleAlarm / Custom
Operating Frequency 869 MHz / Custom
Dimensions H115 x W69 x D28 mm
2 x RJ12 inputs (some RJ11 connections are compatible - contact us for more
Input
information)
Selectable Options Via easy to select rotary switch
Selectable Audio Option for audio reassurance
Power Supply AA batteries (User replaceable)
Battery Life 3 years under the following conditions - 5 alarms transmission per day
Wireless Range Up to 600m line of sight
Compliance CE / RoHS 2 / RED
Warranty 24 months
Battery Replacement
Two 'Energizer L91 Ultimate Lithium AA' Batteries (Part no
M115-110) should be used to ensure maximum battery life. It is
important that the batteries are inserted correctly. Please note the
polarity markings within the battery compartment. Once the
batteries have been replaced, ensure the programmed settings are
still correct.
Note: When replacing batteries, it is important to completely drain
any residual power before new batteries are inserted. To do this,
simply remove the old batteries, press and hold the on/off switch
for 5 seconds, then insert the new batteries.
Packing for shipment
The equipment containing cells or batteries must be packed in
strong rigid packaging and must be secured against movement
within the outer packaging to prevent accidental activation. The
sender's name and return address must be clearly visible on the
outer packaging.
Safety
Do not dismantle or alter the unit. Do not open the case. Indoor
use in dry location only.
Disposal
All electronic waste should be disposed of in accordance with
the latest legislation.
It must be disposed of within the electrical and electronic waste
stream and not be disposed of in the normal waste stream.
Recycling electrical waste products help to conserve natural
resources and prevent adverse effects on the environment.
Contact your supplier should you require more information.
Declaration of Conformity:
Hereby, Cair (UK) Ltd declares that the radio equipment type, Cair
Connect is in compliance with Directive 2014/53/EU
Hanson Lane, Halifax, West Yorkshire, HX1 4SD
T: 01422 399 155 E: sales@we-cair.com W: www.we-cair.com
Connect
Intelligent Universal Transmitter
The Cair Connect is an intelligent universal transmitter.
Simple and easy to use, the versatile Cair Connect can turn any hard wired device into a radio trigger. It
works as an interface between hard wired devices and telecare enabled systems. Two RJ12 terminal
inputs are provided for multiple device connections.
Cair (UK) Ltd.
Smart Technology, Made to Care
Programming
Guide
V 1.0
